John Bull brake pads? or modern ones that will fit old Raleigh brakes?

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

John Bull brake pads? or modern ones that will fit old Raleigh brakes?

Old 03-29-10, 07:13 PM
  #1
rustmyrtle
Senior Member
Thread Starter

Join Date: Jul 2008
Location: Washington, DC
Posts: 59

Bikes: 48cm gitane reynolds 501 road bike; 1992 specialized rockhopper with slicks

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
John Bull brake pads? or modern ones that will fit old Raleigh brakes?

I have an old made by Raleigh ladies bike, from 1954.

the brake pads were shot, and so I was trying to replace them with regular modern brake pads, but the post on the modern pads was too wide to fit in the slots on the old brakes.

Thoughts? Solutions?
rustmyrtle is offline
Old 03-29-10, 07:45 PM
  #2
bernardmarx
Hair Club Member

bernardmarx's Avatar

Join Date: May 2009
Location: East Tennessee
Posts: 127

Bikes: '86 Miyata 310 '78 Raleigh Sports 3-Speed

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Rod or cable? Old Roads is the first place I think of for rod-brake pads.
bernardmarx is offline
Old 03-29-10, 08:29 PM
  #3
Coreyk
Birotate Charioteer

Coreyk's Avatar

Join Date: Sep 2008
Location: Greenland-on-The-Mississippi
Posts: 220

Bikes: 1978 Raleigh Competition GS, 1980 Raleigh DL-1, 2012 Bianchi Volpe, 1995-8 Caloi "Semi-Otto" homage thingy

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
If I am not mistaken (and somebody here will surely correct me if I am),
Kool Stop makes a brake pad insert for vintage Campagnolo brake pads that will insert in the older Raleigh and similar steel brake pad mounts.

https://www.koolstop.com/brakes/index.php

They also make a pad called "The Continental" farther down the page that is supposed to be a direct replacement for these types of pads, without the chrome holder. I believe some of our English 3-speed nuts have used them and like them. I am planning to get a set each for my wife's 1949 (Phillips) Indian Princess and 1960 Hercules sports 3-speeds.

Corey K
Coreyk is offline
Old 03-29-10, 08:41 PM
  #4
bernardmarx
Hair Club Member

bernardmarx's Avatar

Join Date: May 2009
Location: East Tennessee
Posts: 127

Bikes: '86 Miyata 310 '78 Raleigh Sports 3-Speed

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Coreyk, I've got Continentals on my '78 Sports, and they're great. The pads on the Sports weren't original, so the holders were already gone. That said, if the OP's talking about rod brakes on a roadster (28" tires, etc.) Continentals won't work. The pads on rod brakes contact the inside of the rim, not the sides. Hence the raised center ridge to protect the spokes.
bernardmarx is offline
Old 03-29-10, 09:03 PM
  #5
choteau
Senior Member

Join Date: Dec 2008
Location: Oregon
Posts: 366
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
I'm running these on my Phillips roadster, much better than old dried out shoes it came with. Tim https://www.bikepartsusa.com/bikepart...?item=01-90442

Last edited by choteau; 03-29-10 at 09:07 PM. Reason: oops
choteau is offline
Old 03-29-10, 09:41 PM
  #6
John E
feros ferio

John E's Avatar

Join Date: Jul 2000
Location: www.ci.encinitas.ca.us
Posts: 19,859

Bikes: 1959 & 1960 Capo; 1982 Bianchi; 1988 Schwinn KOM-10;

Mentioned: 33 Post(s)
Tagged: 0 Thread(s)
Quoted: 821 Post(s)
Liked 175 Times in 140 Posts
If KoolStop makes a salmon colored brake pad for your application, buy it.
__________________
"Far and away the best prize that life offers is the chance to work hard at work worth doing." --Theodore Roosevelt
Capo: 1959 Modell Campagnolo, S/N 40324
Capo: 1960 Sieger (2), S/N 42624, 42597
Peugeot: 1970 UO-8, S/N 0010468
Bianchi: 1982 Campione d'Italia, S/N 1.M9914
Schwinn: 1988 Project KOM-10, S/N F804069
John E is offline
Old 03-29-10, 10:22 PM
  #7
gna
Count Orlok Member

gna's Avatar

Join Date: May 2009
Location: St. Paul, MN
Posts: 1,615

Bikes: Raleigh Sports, Raleigh Twenty, Raleigh Wyoming, Schwinn Le Tour Luxe Frankenbike

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Likes: 0
Liked 8 Times in 6 Posts
Originally Posted by coreyk View Post
i believe some of our english 3-speed nutters have used them and like them.

Corey k
FTFY
gna is offline
Old 03-30-10, 07:01 AM
  #8
nlerner
Senior Member

Join Date: Dec 2005
Posts: 13,108
Mentioned: 288 Post(s)
Tagged: 0 Thread(s)
Quoted: 1583 Post(s)
Liked 671 Times in 393 Posts
You can find John Bull replacement pads (using the same old holders). What model # pads are on there now?

Neal
nlerner is offline
Old 03-30-10, 01:36 PM
  #9
rustmyrtle
Senior Member
Thread Starter

Join Date: Jul 2008
Location: Washington, DC
Posts: 59

Bikes: 48cm gitane reynolds 501 road bike; 1992 specialized rockhopper with slicks

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Thanks a lot guys (OP here). the brakes aren't rod brakes, but old side pull brakes. I"ll try koolstop
rustmyrtle is offline
Old 03-30-10, 04:19 PM
  #10
Coreyk
Birotate Charioteer

Coreyk's Avatar

Join Date: Sep 2008
Location: Greenland-on-The-Mississippi
Posts: 220

Bikes: 1978 Raleigh Competition GS, 1980 Raleigh DL-1, 2012 Bianchi Volpe, 1995-8 Caloi "Semi-Otto" homage thingy

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Good luck, rustmyrtle. I've heard they do a great job on the steel rims. Let us know how they work for you.

gna, thanks for the tech assistance.

Bernard, I assumed from the original post that they were sidepulls. I have both.

Chotoeau, how do those Pyramid shoes work? If they're any good for your application, I have a 1950s Phillips double-bar roadster here with original John Bull brake shoes. They are pretty darn hard by now, and could use replacing...



The ones on the DL-1 are still decent, thank goodness.



Corey K
Coreyk is offline
Old 03-30-10, 04:40 PM
  #11
noglider
aka Tom Reingold

noglider's Avatar

Join Date: Jan 2009
Location: High Falls, NY, USA
Posts: 38,973

Bikes: 1962 Rudge Sports, 1971 Raleigh Super Course, 1971 Raleigh Pro Track, 1974 Raleigh International, 1975 Viscount Fixie, 1982 McLean, 1996 Lemond (Ti), 2002 Burley Zydeco tandem

Mentioned: 472 Post(s)
Tagged: 0 Thread(s)
Quoted: 6411 Post(s)
Liked 956 Times in 628 Posts
I just widened the slot with a taper reamer. You could use a file or a drill bit instead.

__________________
Tom Reingold, tom@noglider.com
New York City and High Falls, NY
Blogs: The Experienced Cyclist; noglider's ride blog

“When man invented the bicycle he reached the peak of his attainments.” — Elizabeth West, US author

Please email me rather than PM'ing me. Thanks.
noglider is online now
Old 04-05-10, 11:24 AM
  #12
rustmyrtle
Senior Member
Thread Starter

Join Date: Jul 2008
Location: Washington, DC
Posts: 59

Bikes: 48cm gitane reynolds 501 road bike; 1992 specialized rockhopper with slicks

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
We used a drill and widened it--worked perfectly!
rustmyrtle is offline
Old 04-05-10, 12:50 PM
  #13
gna
Count Orlok Member

gna's Avatar

Join Date: May 2009
Location: St. Paul, MN
Posts: 1,615

Bikes: Raleigh Sports, Raleigh Twenty, Raleigh Wyoming, Schwinn Le Tour Luxe Frankenbike

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Likes: 0
Liked 8 Times in 6 Posts
Originally Posted by Coreyk View Post

...I have a 1950s Phillips double-bar roadster here with original John Bull brake shoes. They are pretty darn hard by now, and could use replacing...



The ones on the DL-1 are still decent, thank goodness.



Corey K
We need more pictures of these bicycles.
gna is offline
Old 04-05-10, 01:59 PM
  #14
choteau
Senior Member

Join Date: Dec 2008
Location: Oregon
Posts: 366
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Sorry for the delay, Corey K, the shoes work better than the old dried up ones it had on, and WAY better than the Flying pigeon ones I tried.... Have to ride and use'm to see how long they last tho... Tim
choteau is offline
Old 04-05-10, 07:34 PM
  #15
Coreyk
Birotate Charioteer

Coreyk's Avatar

Join Date: Sep 2008
Location: Greenland-on-The-Mississippi
Posts: 220

Bikes: 1978 Raleigh Competition GS, 1980 Raleigh DL-1, 2012 Bianchi Volpe, 1995-8 Caloi "Semi-Otto" homage thingy

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Okay, that's good to hear, choteau. I took the steed out for a run about 4 days back and got caught in a downpour. All thought of these things *actually being brakes* went out the window! I'll see about the Pyramids.

GNA, I'll get some pics together this weekend and post them in a new thread.

Rustmyrtle, please keep us posted on how the Kool Stops work for you.

Corey K
Coreyk is offline
Old 04-06-10, 07:56 AM
  #16
gna
Count Orlok Member

gna's Avatar

Join Date: May 2009
Location: St. Paul, MN
Posts: 1,615

Bikes: Raleigh Sports, Raleigh Twenty, Raleigh Wyoming, Schwinn Le Tour Luxe Frankenbike

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Likes: 0
Liked 8 Times in 6 Posts
Originally Posted by gna View Post
We need more pictures of these bicycles.
Rustmyrtle, this includes you--we need pictures of your Raleigh, too.
