What did I just buy and...

will I be able to get this seat post out? I took a chance on this bike at a local police auction. It has been abused and neglected, but is still a nice looking bike. The frame and fork are chrome. Here is what I'm guessing is original to the bike: a shimano dropouts, a 3ttt stem, campagnolo cable guides, and a stronglight crank set. It was also set up with suntour barcons, shimano deore fd, and weinmann 605 brake calipers. The biggest clue is a "74" on the written on the fork. The serial # is 52052. Anyone have any idea on what I have?

A previous owner forced in (way in) an SR aluminum seat post. I've resorted to the last of the 15 ways recommended by Sheldon, and I cut a slit in the seat post but I haven't been able to "roll" the seat post up. I'm fearing that it is a very long seatpost. Any insight is greatly appreciated.






Gthoro is offline
Old 10-10-10, 09:39 PM
  #2
noglider
aka Tom Reingold

noglider's Avatar

Join Date: Jan 2009
Location: New York, NY, USA
Posts: 40,146

Bikes: 1962 Rudge Sports, 1971 Raleigh Super Course, 1971 Raleigh Pro Track, 1974 Raleigh International, 1975 Viscount Fixie, 1982 McLean, 1996 Lemond (Ti), 2002 Burley Zydeco tandem

Mentioned: 493 Post(s)
Tagged: 0 Thread(s)
Quoted: 6996 Post(s)
Liked 1,727 Times in 1,075 Posts
I don't know what it is, but it's nice.

Do you think it's worth your trouble? Do you have enough parts on hand to build it up? If not, it won't be cost-effective to make it into a bike.

I imagine that you could ream the seatpost out, with enough reamers, until you hit the steel of the seat tube. Not sure if that's cost-effective, either.

Tom
__________________
Tom Reingold, tom@noglider.com
New York City and High Falls, NY
Blogs: The Experienced Cyclist; noglider's ride blog

“When man invented the bicycle he reached the peak of his attainments.” — Elizabeth West, US author

Please email me rather than PM'ing me. Thanks.
noglider is offline
Old 10-10-10, 09:44 PM
  #3
Gthoro
Senior Member
Thread Starter

Gthoro's Avatar

Join Date: Apr 2007
Location: SW Wisconsin
Posts: 107
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by noglider View Post
I don't know what it is, but it's nice.

Do you think it's worth your trouble? Do you have enough parts on hand to build it up? If not, it won't be cost-effective to make it into a bike.

I imagine that you could ream the seatpost out, with enough reamers, until you hit the steel of the seat tube. Not sure if that's cost-effective, either.

Tom
Hi Tom,

I have bins of parts waiting for a frame such as this. I plan on removing the paint and riding with the chrome frame. Thanks for the reamers idea, I'll keep trying brute force for a while then I may resort to that.
Gthoro is offline
Old 10-10-10, 09:48 PM
  #4
cudak888
www.theheadbadge.com

cudak888's Avatar

Join Date: Sep 2005
Location: Southern Florida
Posts: 26,930

Bikes: https://www.theheadbadge.com

Mentioned: 83 Post(s)
Tagged: 0 Thread(s)
Quoted: 1698 Post(s)
Liked 2,187 Times in 1,224 Posts
The only way to get the remains out are with a reamer or with a tool that will send the appropriate sized bore down the hole, such as the Silva La Combianata; framebuilder Mike Terraferma has one.

-Kurt
__________________







cudak888 is offline
Old 10-10-10, 09:52 PM
  #5
curbtender
Senior Member

curbtender's Avatar

Join Date: Mar 2007
Location: SF Bay Area, East bay
Posts: 7,543

Bikes: Marinoni, Kestral 200 2002 Trek 5200, KHS Flite, Koga Miyata, Schwinn Spitfire 5, Schwinn Speedster, Mondia Special, Univega Alpina, Miyata team Ti, MB3

Mentioned: 45 Post(s)
Tagged: 0 Thread(s)
Quoted: 1204 Post(s)
Liked 1,165 Times in 659 Posts
Try a reciprocal saw with the longest metal blade you can find and then colapse the sides with a channel lock.
curbtender is offline
Old 10-10-10, 09:52 PM
  #6
toytech
Senior Member

toytech's Avatar

Join Date: Feb 2009
Location: san leandro
Posts: 1,453

Bikes: enough bikes to qualify for Hoarders......

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
slit the aluminum on both sides of the seat post, as long as it is not longer than the blade you should be fine. after you have both sides slit it will be easier to break the surface grip and get them out. when you get it out, if it is not too nice inside the tube you can always have it reamed out a size.
toytech is offline
Old 10-10-10, 09:54 PM
  #7
Ira B
Senior Member

Ira B's Avatar

Join Date: Aug 2010
Location: Coupeville, WA
Posts: 890

Bikes: 84 Raleigh Technium- 89 Shogun Mt. Bike-96 Miyata 914

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Liked 0 Times in 0 Posts
I would find or make a slide hammer (like a dent puller) with a long hardened steel rod that is hooked at the end, then hook the bottom end of the seat post and smack away at it. Soaking it with 50/50 ATF Kerosene mix overnight may also help bust it lose.
Ira B is offline
Old 10-10-10, 11:51 PM
  #8
shnibop
Senior Member

shnibop's Avatar

Join Date: Aug 2009
Posts: 856
Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 44 Times in 18 Posts
I've used the following method with great success, just don't get any on the paint or yourself.

Plug one end of the seat tube thoroughly. Fill it with a strong solution of water and lye. It will eat away at the aluminum and leave the steel untouched. Thoroughly rinse the seat tube out with cold water. Deactivate the lye with vinegar. Rinse with water. Usually takes a good day to free the post or stem, a couple days to completely eat it away if it's reeeally stuck.

Lye is dangerous stuff. Pm me if you have any questions.
shnibop is offline
Old 10-11-10, 10:06 AM
  #9
unworthy1
Stop reading my posts!

unworthy1's Avatar

Join Date: Sep 2004
Posts: 11,936
Mentioned: 73 Post(s)
Tagged: 0 Thread(s)
Quoted: 990 Post(s)
Liked 508 Times in 416 Posts
good luck with the post, it's going to be a struggle but you will win...eventually.
As for this bike: I have a feeling it's a high-end Lotus or similar Japanese make. There's a weld-seam on the BB shell. It would help to see a clear close-up of the headlugs and the forkcrown. Also the BB threading and seatpost size (if you get out any remnants with the markings intact!).
unworthy1 is offline
Old 10-11-10, 10:42 AM
  #10
SJX426
Senior Member

SJX426's Avatar

Join Date: May 2008
Location: Fredericksburg, Va
Posts: 8,626

Bikes: '73 Bottecchia Giro d'Italia, '83 Colnago Superissimo, '84 Trek 610, '84 Trek 760, '88 Pinarello Veneto, '88 De Rosa Pro, '89 Pinarello Montello, '94 Burley Duet, 97 Specialized RockHopper, 2010 Langster, Tern Link D8

Mentioned: 62 Post(s)
Tagged: 0 Thread(s)
Quoted: 1259 Post(s)
Liked 1,268 Times in 697 Posts
Are the chain stays damaged? Looks like it from the picture of the BB.
SJX426 is online now
Old 10-11-10, 10:49 AM
  #11
divineAndbright
Senior Member

divineAndbright's Avatar

Join Date: Aug 2005
Location: ontario
Posts: 2,234
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Looks like it had a kickstand torqued a bit too much, should still be alright though.
divineAndbright is offline
Old 10-11-10, 12:09 PM
  #12
Zaphod Beeblebrox
PanGalacticGargleBlaster

Zaphod Beeblebrox's Avatar

Join Date: Apr 2009
Location: Smugglers Notch, Vermont
Posts: 7,536

Bikes: Upright and Recumbent....too many to list, mostly Vintage.

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 19 Post(s)
Likes: 0
Liked 4 Times in 3 Posts
+1 to the above 2 posts, just make sure there's no cracks.
__________________
--Don't Panic.
Zaphod Beeblebrox is offline
Old 10-11-10, 12:26 PM
  #13
3speed
Senior Member

Join Date: Aug 2009
Location: Madison, WI
Posts: 3,473
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 363 Post(s)
Liked 28 Times in 22 Posts
I'm guessing a handlebar stem won't fit into that seat post, correct? If so, you could put one in there just so that you could tighten it and have a hold on the seat post from the inside. It would also be the perfect shape to hold onto to pull the post out.
3speed is offline
Old 10-11-10, 12:28 PM
  #14
ColonelJLloyd
Senior Member

ColonelJLloyd's Avatar

Join Date: Dec 2009
Location: Louisville
Posts: 8,382
Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 110 Post(s)
Liked 9 Times in 8 Posts
Be advised that the chrome under the paint (if it is indeed fully chromed) is not polished and wasn't intended to be the "face" of the bike.

I like the idea of a penetrating solution and the slide hammer.
ColonelJLloyd is offline
Old 10-11-10, 06:33 PM
  #15
sjpitts
Senior Member

Join Date: Feb 2009
Location: Mesa, Arizona
Posts: 567

Bikes: 90 Bridgestone MB2/3, 97 Lemond Zurich, 97 Waterford 2200, 95 Mondonico Futura Leggero

Mentioned: 0 Post(s)
Tagged: 1 Thread(s)
Quoted: 5 Post(s)
Likes: 0
Liked 1 Time in 1 Post
I have had pretty good luck with dry ice. If the seat post is aluminum. My understanding is that the coefficient of thermal expansion for aluminum is much greater than that of steel. So cooling the seat post down will shrink it more than the seat tube will shrink. So I would spend a couple of days with penetrating oil and then pack that seat post with dry ice. Let it cool down and see if you can pull it out.

It probably won't work, but it might be worth the try. Dry ice is pretty cheap.
sjpitts is offline
Old 10-12-10, 09:32 AM
  #16
T-Mar
Senior Member

Join Date: Nov 2004
Posts: 22,907
Mentioned: 613 Post(s)
Tagged: 1 Thread(s)
Quoted: 4548 Post(s)
Likes: 0
Liked 2,699 Times in 1,700 Posts
There's a very good chance that the 74 on the fork may represent the year, making it a 1974 or 1975 model. The total lack of brazed fittings does indicate a 1970s model and I don't believe that Shimano had their forged dropouts prior to Dura-Ace. The forged dropouts suggest at least a mid-range model. BTW, is that the LF model dropout, without the adjuster screw holes? It's hard to tell in the picture. If so, it suggests mid-range as opposed to high end.

The Shimano dropouts also suggest Japanese manufacture, given the timeframe. The hand stamped serial number suggests a small production brand. I've got a pretty good handle on Japanese serial numbers and it does not represent any of the larger Japanese manufactured brands that were importing into the US at the time (i.e. Apollo, Araya, Azuki, Bridgestone, Centurion, Fuji, Kabuki, Kuwahara, Maruishi, Miyata, Nishiki, Panasonic, Sekai, Sekine, Soma, Takara).

The proper seat post diameter may also give us a good indicator of the tubing grade. Unfortunately, removing the current post may distort the tube, making an accurate reading difficult.
T-Mar is offline
Old 10-12-10, 10:54 AM
  #17
tk1971
Senior Member

tk1971's Avatar

Join Date: Sep 2010
Location: San Gabriel, CA
Posts: 273

Bikes: Nishiki Prestige, Reign, IH Warrior, Rockhopper, Brompton, Q-Bike, Forever, Free-Ride, Dahon, Merckx Premium, Litespeed Teramo, Raleigh MTi 1000, Motobecane Fly Ti, OnOne 456, Kona Unit, Transition TransAM

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Looks like you have a little stub of the seat post sticking out. Can't you drill holes through the post, shove a screwdriver in there, and twist it out? If not, the holes make a good place to mount a slide hammer to. Good luck.

tk
tk1971 is offline
Old 10-12-10, 11:06 AM
  #18
cudak888
www.theheadbadge.com

cudak888's Avatar

Join Date: Sep 2005
Location: Southern Florida
Posts: 26,930

Bikes: https://www.theheadbadge.com

Mentioned: 83 Post(s)
Tagged: 0 Thread(s)
Quoted: 1698 Post(s)
Liked 2,187 Times in 1,224 Posts
Originally Posted by tk1971 View Post
Looks like you have a little stub of the seat post sticking out. Can't you drill holes through the post, shove a screwdriver in there, and twist it out? If not, the holes make a good place to mount a slide hammer to. Good luck.
Sounds as if you've never dealt with a stuck (read=chemically bonded) seatpost before.

-Kurt
__________________







cudak888 is offline
Old 10-12-10, 02:22 PM
  #19
Oldpeddaller
Senior Member

Oldpeddaller's Avatar

Join Date: Apr 2008
Location: Maidstone, Kent, England
Posts: 2,636

Bikes: 1970 Holdsworth Mistral, Vitus 979, Colnago Primavera, Corratec Hydracarbon, Massi MegaTeam, 1935 Claud Butler Super Velo, Carrera Virtuoso, Viner, 1953 Claud Butler Silver Jubilee, 1954 Holdsworth Typhoon, 1966 Claud Butler Olympic Road, 1982 Claud

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked 8 Times in 7 Posts
Originally Posted by 3speed View Post
I'm guessing a handlebar stem won't fit into that seat post, correct? If so, you could put one in there just so that you could tighten it and have a hold on the seat post from the inside. It would also be the perfect shape to hold onto to pull the post out.
Never heard of that idea before 3speed, sounds promising! I take it you mean a quill stem with an angled steel wedge expander? Might try that on a couple of mine that still have STEEL seat posts firmly stuck in place.
Oldpeddaller is offline
Old 10-12-10, 06:30 PM
  #20
noglider
aka Tom Reingold

noglider's Avatar

Join Date: Jan 2009
Location: New York, NY, USA
Posts: 40,146

Bikes: 1962 Rudge Sports, 1971 Raleigh Super Course, 1971 Raleigh Pro Track, 1974 Raleigh International, 1975 Viscount Fixie, 1982 McLean, 1996 Lemond (Ti), 2002 Burley Zydeco tandem

Mentioned: 493 Post(s)
Tagged: 0 Thread(s)
Quoted: 6996 Post(s)
Liked 1,727 Times in 1,075 Posts
I doubt any stem is small enough to fit inside a seatpost. But it's food for thought. Maybe there is some sort of expander to use. I don't know what would fit AND exert enough force, though. Remember, the seatpost needs a ton of force.
__________________
Tom Reingold, tom@noglider.com
New York City and High Falls, NY
Blogs: The Experienced Cyclist; noglider's ride blog

“When man invented the bicycle he reached the peak of his attainments.” — Elizabeth West, US author

Please email me rather than PM'ing me. Thanks.
noglider is offline
Old 10-12-10, 08:18 PM
  #21
JohnDThompson
Old fart

JohnDThompson's Avatar

Join Date: Nov 2004
Location: Appleton WI
Posts: 23,650

Bikes: Several, mostly not name brands.

Mentioned: 142 Post(s)
Tagged: 0 Thread(s)
Quoted: 3003 Post(s)
Liked 2,110 Times in 1,255 Posts
Originally Posted by T-Mar View Post
I don't believe that Shimano had their forged dropouts prior to Dura-Ace. The forged dropouts suggest at least a mid-range model. BTW, is that the LF model dropout, without the adjuster screw holes? It's hard to tell in the picture. If so, it suggests mid-range as opposed to high end.

The Shimano dropouts also suggest Japanese manufacture, given the timeframe. The hand stamped serial number suggests a small production brand. I've got a pretty good handle on Japanese serial numbers and it does not represent any of the larger Japanese manufactured brands that were importing into the US at the time (i.e. Apollo, Araya, Azuki, Bridgestone, Centurion, Fuji, Kabuki, Kuwahara, Maruishi, Miyata, Nishiki, Panasonic, Sekai, Sekine, Soma, Takara).
The dropouts look like Shimano SF:


We used them a lot at Trek in the early 80s.
JohnDThompson is offline
Old 10-12-10, 08:41 PM
  #22
Gthoro
Senior Member
Thread Starter

Gthoro's Avatar

Join Date: Apr 2007
Location: SW Wisconsin
Posts: 107
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by JohnDThompson View Post
The dropouts look like Shimano SF:


We used them a lot at Trek in the early 80s.
The dropouts didn't have any SF markings, they have a larger font "SHIMANO" on the top and "Japan" on the bottom. I'll try and get some close ups posted later this week - I'm getting slammed at work this week.
Gthoro is offline
Old 10-12-10, 08:43 PM
  #23
Gthoro
Senior Member
Thread Starter

Gthoro's Avatar

Join Date: Apr 2007
Location: SW Wisconsin
Posts: 107
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by divineAndbright View Post
Looks like it had a kickstand torqued a bit too much, should still be alright though.
Yeah, a previous owner really did a number on this bike. It had an x-mart kickstand torqued on it. I don't see any cracking, so it should be alright.
Gthoro is offline
Old 10-12-10, 08:46 PM
  #24
Gthoro
Senior Member
Thread Starter

Gthoro's Avatar

Join Date: Apr 2007
Location: SW Wisconsin
Posts: 107
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by T-Mar View Post
There's a very good chance that the 74 on the fork may represent the year, making it a 1974 or 1975 model. The total lack of brazed fittings does indicate a 1970s model and I don't believe that Shimano had their forged dropouts prior to Dura-Ace. The forged dropouts suggest at least a mid-range model. BTW, is that the LF model dropout, without the adjuster screw holes? It's hard to tell in the picture. If so, it suggests mid-range as opposed to high end.

The Shimano dropouts also suggest Japanese manufacture, given the timeframe. The hand stamped serial number suggests a small production brand. I've got a pretty good handle on Japanese serial numbers and it does not represent any of the larger Japanese manufactured brands that were importing into the US at the time (i.e. Apollo, Araya, Azuki, Bridgestone, Centurion, Fuji, Kabuki, Kuwahara, Maruishi, Miyata, Nishiki, Panasonic, Sekai, Sekine, Soma, Takara).

The proper seat post diameter may also give us a good indicator of the tubing grade. Unfortunately, removing the current post may distort the tube, making an accurate reading difficult.
Thanks for the good leads T-mar. The dropouts do have adjuster screw holes (with one broken off inside grrrr...). I'll check the seat post diameter once I get it out.
Gthoro is offline
Old 10-12-10, 08:52 PM
  #25
Gthoro
Senior Member
Thread Starter

Gthoro's Avatar

Join Date: Apr 2007
Location: SW Wisconsin
Posts: 107
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Thanks to all for the great ideas on removing a stuck seatpost. This forum is a great resource! This is the first stuck seatpost I've come across, but with your help I feel like I'm up to the challenge. I plan on trying a longer blade for my reciprocating saw. I'll keep you posted on my progress. I likely won't get to it this weekend.
Gthoro is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright © 2021 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
