Fork Crown Race Setter Tool My Version

I know this has been done before.......

Fork Crown Race Setter Tool $5.73 + Tax

1" Copper Coupling $1.88
1" X 12" Black Nipple $3.85

It worked perfect. I taped them together just so I would not loose both pieces.


__________________
Originally Posted by iab View Post
Why do you mock the cycling gods?

Your only hope is reciting 10 hail campagnolos to our lady of the duraace.


I'm happy to say that I own more Steel then Carbon. My Stable! ---> https://flic.kr/s/aHsmVZBep7
Frogbutter is offline
Old 07-28-14, 05:17 PM
  #2
Bianchigirll
Bianchi Goddess

Bianchigirll's Avatar

Join Date: Apr 2009
Location: Shady Pines Retirement Fort Wayne, In
Posts: 28,396

Bikes: Too many to list here check my signature.

Mentioned: 156 Post(s)
Tagged: 2 Thread(s)
Quoted: 2359 Post(s)
Liked 1,425 Times in 841 Posts
We used something very similar at the first shop I worked at. If you turn an old crown race upside down it gives a larger surface to 'tap' on then you don't even really need the copper tube.
__________________
One morning you wake up, the girl is gone, the bikes are gone, all that's left behind is a pair of old tires and a tube of tubular glue, all squeezed out"

Sugar "Kane" Kowalczyk
Bianchigirll is offline
Old 07-28-14, 05:29 PM
  #3
oldskoolwrench
自転車整備士

oldskoolwrench's Avatar

Join Date: Apr 2012
Location: Denver, Colorado USA
Posts: 898

Bikes: '86 Moots Mountaineer, '94 Salsa Ala Carte, '94 S-Works FSR, 1983 Trek 600 & 620

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 3 Post(s)
Likes: 0
Liked 1 Time in 1 Post
Originally Posted by Bianchigirll View Post
We used something very similar at the first shop I worked at. If you turn an old crown race upside down it gives a larger surface to 'tap' on then you don't even really need the copper tube.
And I still use your method (and tools) today. If it ain't broke, don't fix it.
oldskoolwrench is offline
Old 07-28-14, 08:22 PM
  #4
nlerner
Senior Member

Join Date: Dec 2005
Posts: 15,747
Mentioned: 404 Post(s)
Tagged: 0 Thread(s)
Quoted: 2996 Post(s)
Liked 3,843 Times in 1,692 Posts
I just use the 1 x 12 steel pipe. Wouldn't the copper be too soft for whacking a steel crown race into position?
nlerner is offline
Old 07-28-14, 09:23 PM
  #5
CV-6
If I own it, I ride it

CV-6's Avatar

Join Date: Nov 2005
Location: Cardinal Country
Posts: 5,456

Bikes: Lejeune(14), Raleigh, Raysport, Jan De Reus, Gazelle, Masi, B. Carré(4), Springfield, Motobecane(2), Greg Lemond, Andre Bertin, Schwinn Paramount

Mentioned: 55 Post(s)
Tagged: 0 Thread(s)
Quoted: 547 Post(s)
Likes: 0
Liked 504 Times in 244 Posts
PVC pipe. Does not damage the race. You have to replace it eventually, but if you do you are installing a lot of crown races.
__________________
Please do not "like" my posts. This isn't Facebook.

Lynn Travers

Photos

CV-6 is offline
Old 07-28-14, 10:12 PM
  #6
zukahn1
Senior Member

zukahn1's Avatar

Join Date: Oct 2011
Location: Fairplay Co
Posts: 8,678

Bikes: Current 79 Nishiki Custum Sport, Jeunet 620, notable previous bikes P.K. Ripper loop tail, Kawahara Laser Lite, Paramount Track full chrome, Raliegh Internatioanl, Motobecan Super Mirage. 59 Crown royak 3 speed

Mentioned: 21 Post(s)
Tagged: 1 Thread(s)
Quoted: 597 Post(s)
Liked 681 Times in 332 Posts
A old upside down junk fork and a couple upside races and and a small mallet work's.
zukahn1 is offline
Old 07-29-14, 04:27 AM
  #7
rootboy
Senior Member

rootboy's Avatar

Join Date: Apr 2005
Location: Wherever
Posts: 16,755
Mentioned: 90 Post(s)
Tagged: 0 Thread(s)
Quoted: 552 Post(s)
Likes: 0
Liked 122 Times in 71 Posts
Originally Posted by Frogbutter View Post

Fork Crown Race Setter Tool $5.73 + Tax
Plus the cost of the pizza of course.

Nice, cheap fix, FB.
As you know, I went way overkill on my tool.
But it was fun to make.
rootboy is offline
Old 07-29-14, 05:39 AM
  #8
SJX426
Senior Member

SJX426's Avatar

Join Date: May 2008
Location: Fredericksburg, Va
Posts: 8,610

Bikes: '73 Bottecchia Giro d'Italia, '83 Colnago Superissimo, '84 Trek 610, '84 Trek 760, '88 Pinarello Veneto, '88 De Rosa Pro, '89 Pinarello Montello, '94 Burley Duet, 97 Specialized RockHopper, 2010 Langster, Tern Link D8

Mentioned: 62 Post(s)
Tagged: 0 Thread(s)
Quoted: 1250 Post(s)
Liked 1,252 Times in 689 Posts
Good approach! I used a steel pipe. It really doesn't take much force to place one. Tap gently! Before installation, measure both ID and OD. Should not be more than .002 interference. Paint will impact the OD on the crown so clean it off. The installer of the Super Record Crown race wherever the it happened failed to clean the paint off resulting in a broken race. The SR race is not as robust as the NR race and are subject to failure upon installation.
SJX426 is offline
Old 07-29-14, 10:37 AM
  #9
Lascauxcaveman
Senior Member

Lascauxcaveman's Avatar

Join Date: Nov 2011
Location: Port Angeles, WA
Posts: 7,911

Bikes: A green one, "Ragleigh," or something.

Mentioned: 190 Post(s)
Tagged: 0 Thread(s)
Quoted: 1587 Post(s)
Liked 507 Times in 295 Posts
Originally Posted by Frogbutter View Post
I don't recommend pounding on too hard in that position; it's a bit hard on the leather sofa
__________________
● 1971 Grandis SL ● 1972 Lambert Grand Prix frankenbike ● 1972 Raleigh Super Course fixie ● 1973 Nishiki Semi-Pro ● 1980 Apollo "Legnano" ● 1984 Peugeot Vagabond ● 1985 Shogun Prairie Breaker ● 1986 Merckx Super Corsa ● 1987 Schwinn Tempo ● 1988 Schwinn Voyageur ● 1989 Trek 400 ● 1989 Bottechia Team ADR replica ● 1990 Cannondale ST600 ● 1993 Technium RT600 ● 1996 Kona Lava Dome ●
Lascauxcaveman is offline
Old 07-29-14, 12:50 PM
  #10
daf1009
Senior Member

daf1009's Avatar

Join Date: Mar 2010
Location: Alpharetta, GA
Posts: 3,178

Bikes: LESS than I did a year ago!

Mentioned: 17 Post(s)
Tagged: 0 Thread(s)
Quoted: 70 Post(s)
Likes: 0
Liked 3 Times in 2 Posts
How about a cheap crown race removal tool?
daf1009 is offline
Old 07-29-14, 01:16 PM
  #11
Frogbutter
King of the Obscure
Thread Starter

Frogbutter's Avatar

Join Date: Dec 2010
Location: Eau Claire, Wisconsin. USA
Posts: 715

Bikes: It's a SICKNESS!

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 28 Times in 18 Posts
Originally Posted by daf1009 View Post
How about a cheap crown race removal tool?
Not much of a saving if ya have to buy one but I used a Bearing Separator. We had one like this at our shop. https://www.summitracing.com/parts/wm...FQ5gMgodCTgAzg
Harbor Freight may have one for less.
__________________
Originally Posted by iab View Post
Why do you mock the cycling gods?

Your only hope is reciting 10 hail campagnolos to our lady of the duraace.


I'm happy to say that I own more Steel then Carbon. My Stable! ---> https://flic.kr/s/aHsmVZBep7
Frogbutter is offline
Old 07-29-14, 01:26 PM
  #12
nlerner
Senior Member

Join Date: Dec 2005
Posts: 15,747
Mentioned: 404 Post(s)
Tagged: 0 Thread(s)
Quoted: 2996 Post(s)
Liked 3,843 Times in 1,692 Posts
Originally Posted by daf1009 View Post
How about a cheap crown race removal tool?
I use a hammer and a punch and a bench vise. Yeah, pretty crude.
nlerner is offline
Old 07-29-14, 01:40 PM
  #13
CV-6
If I own it, I ride it

CV-6's Avatar

Join Date: Nov 2005
Location: Cardinal Country
Posts: 5,456

Bikes: Lejeune(14), Raleigh, Raysport, Jan De Reus, Gazelle, Masi, B. Carré(4), Springfield, Motobecane(2), Greg Lemond, Andre Bertin, Schwinn Paramount

Mentioned: 55 Post(s)
Tagged: 0 Thread(s)
Quoted: 547 Post(s)
Likes: 0
Liked 504 Times in 244 Posts
Originally Posted by nlerner View Post
I use a hammer and a punch and a bench vise. Yeah, pretty crude.
But it works and that's all you need.
__________________
Please do not "like" my posts. This isn't Facebook.

Lynn Travers

Photos

CV-6 is offline
Old 07-29-14, 02:09 PM
  #14
lostarchitect
incazzare.

lostarchitect's Avatar

Join Date: Mar 2010
Location: Catskills/Brooklyn, NY
Posts: 6,966

Bikes: See sig

Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 40 Post(s)
Liked 47 Times in 30 Posts
My crown race setter tool is a 1" hole drilled into my wood workbench. I put the race on the fork, and I put the steerer into the hole. Bang on the underside of the fork crown with a mallet. Done.
__________________
1964 JRJ (Bob Jackson), 1973 Wes Mason, 1974 Raleigh Gran Sport, 1986 Schwinn High Sierra, 2000ish Colian (Colin Laing), 2011 Dick Chafe, 2013 Velo Orange Pass Hunter
lostarchitect is offline
Old 07-30-14, 02:56 PM
  #15
southpawboston
Senior Member

southpawboston's Avatar

Join Date: Aug 2008
Location: Somerville, MA and Catskill Mtns
Posts: 4,147
Mentioned: 33 Post(s)
Tagged: 0 Thread(s)
Quoted: 77 Post(s)
Liked 159 Times in 72 Posts
Originally Posted by nlerner View Post
I use a hammer and a punch and a bench vise. Yeah, pretty crude.
Crude, maybe, but I've yet to damage a race or a crown using this race removal method. Whereas the one time I tried to use an actual purpose-built tool I ended up gouging the paint on the crown!
southpawboston is offline
Old 07-30-14, 03:24 PM
  #16
rootboy
Senior Member

rootboy's Avatar

Join Date: Apr 2005
Location: Wherever
Posts: 16,755
Mentioned: 90 Post(s)
Tagged: 0 Thread(s)
Quoted: 552 Post(s)
Likes: 0
Liked 122 Times in 71 Posts
Overkill. I know.
But I like the way it works. And was fun to make.

rootboy is offline
Old 07-30-14, 03:26 PM
  #17
rootboy
Senior Member

rootboy's Avatar

Join Date: Apr 2005
Location: Wherever
Posts: 16,755
Mentioned: 90 Post(s)
Tagged: 0 Thread(s)
Quoted: 552 Post(s)
Likes: 0
Liked 122 Times in 71 Posts
But I drew the line at making one of these.
rootboy is offline
Old 07-30-14, 04:05 PM
  #18
Frogbutter
King of the Obscure
Thread Starter

Frogbutter's Avatar

Join Date: Dec 2010
Location: Eau Claire, Wisconsin. USA
Posts: 715

Bikes: It's a SICKNESS!

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 28 Times in 18 Posts
Originally Posted by rootboy View Post
Overkill. I know.
But I like the way it works. And was fun to make.

__________________
Originally Posted by iab View Post
Why do you mock the cycling gods?

Your only hope is reciting 10 hail campagnolos to our lady of the duraace.


I'm happy to say that I own more Steel then Carbon. My Stable! ---> https://flic.kr/s/aHsmVZBep7
Frogbutter is offline
