bolt on e-bike kits?

Notices
Electric Bikes Here's a place to discuss ebikes, from home grown to high-tech.

bolt on e-bike kits?

Old 12-11-21, 03:01 PM
  #1
thook
(rhymes with spook)
Thread Starter

thook's Avatar

Join Date: Aug 2009
Location: Winslow, AR
Posts: 2,784

Bikes: '83 univega gran turismo x2, '85 schwinn super le tour,'89 miyata triple cross, '91 GT tequesta, '90 yokota grizzly peak, '94 GT backwoods, '95'ish scott tampico, '98 bonty privateer, '93 mongoose crossway 625, '98 parkpre ariel, 2k'ish giant fcr3

Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 914 Post(s)
Liked 733 Times in 540 Posts
bolt on e-bike kits?

i have a client (i do home/odds and ends repair) that's looking to sell his truck after i getting it running and then build an e-bike with a 26" mtb. i know nothing about e-bikes, but been working manual bikes for decades. iow's, if there's a universal type kit, i'm sure i can put it together for him. i suspect any kit will have fitment parameters, and perhaps in the next few days i can get a few photos together for the thread so ya'll can better help. but, are there kits that bolt on like there are for motorized bikes?? where should i look and what should i look for in terms of quality and best frame fit?

thanks,
matthew
thook is offline
Likes For thook:
Old 12-11-21, 04:04 PM
  #2
cat0020
Ride more, eat less

cat0020's Avatar

Join Date: Feb 2007
Location: Philla PA, Hoboken NJ, Brooklyn NY
Posts: 1,478

Bikes: Too many but never enough.

Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 433 Post(s)
Liked 313 Times in 212 Posts
Depending on budget and intended usage, bolt-on kits may eventually cost just as much as a complete ebike that may suit their purpose; without the time spent on installing & troubleshooting the bolt-on kit.
Maybe with more detail of budget, intended use and rider criteria; better suggestions can be made from the collective.
cat0020 is offline
Likes For cat0020:
Old 12-11-21, 09:01 PM
  #3
2old
Senior Member

Join Date: Jul 2014
Location: socal
Posts: 3,422
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 678 Post(s)
Liked 466 Times in 355 Posts
In the meantime read the tutorials at ebikesca (very expensive kits, but good info) and look at a YouTube video on installing a Bafang BBS02 or BBSHD. My first kit six + years ago was a Dillenger 36V, and it's still in use by my daughter.
2old is offline
Likes For 2old:
Old 12-14-21, 03:12 PM
  #4
Pridedog
Gone Biking!

Pridedog's Avatar

Join Date: Dec 2009
Location: Indiana
Posts: 144

Bikes: Orbea Gain, Lynskey, Redline Conquest Disc, Bike Friday, Cannnondale T2 Tandem.

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 39 Post(s)
Liked 46 Times in 25 Posts
As ebike prices come down, kits are not that much cheaper. I have built up 4 bikes with kits. Everyone needed some level of modification to the kit and bike to work. As a long time cyclist, I am very comfortable with any bicycle maintenance, but the electronic stuff is out of my knowledge base. For the 1st three kits this was not a problem. The last one tested my patience and knowledge at every step. For instance I needed a 2 ft battery wire and a 6 inch motor cable. The kit came with a 6 inch battery wire and a 3 ft motor cable.

For what I ended up paying in bike parts upgrades (tires,chain,freewheel, crankset, etc) and electrical wire and XT60 caps and other things to make the ebike work I had roughly $1200 invested.

So think carefully, for a few dollars more you can have an ebike that was actually manufactured as an ebike.
Pridedog is offline
Likes For Pridedog:
Old 12-14-21, 04:49 PM
  #5
linberl
Senior Member

linberl's Avatar

Join Date: Jun 2014
Location: SF Bay Area
Posts: 3,220

Bikes: 2017 BF pakiT & Dahon Mu Uno (both for sale); current ride - Trident Spike trike w/ e-assist

Mentioned: 25 Post(s)
Tagged: 0 Thread(s)
Quoted: 1224 Post(s)
Liked 248 Times in 199 Posts
An alternative view is that kits let you use a bike that you know fits you well, the end result will likely be lighter, and often the kit can be moved to a new bike if you get one.
linberl is offline
Likes For linberl:
Old 12-14-21, 05:36 PM
  #6
2old
Senior Member

Join Date: Jul 2014
Location: socal
Posts: 3,422
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 678 Post(s)
Liked 466 Times in 355 Posts
To add, building (for me) is a fun hobby; if there are problems, you probably can detect & correct them; the system usually doesn't require proprietary parts (check the price to replace a battery on some completes if you can locate one); and you have the ability to design it for your purpose.
2old is offline
Likes For 2old:
Old 12-15-21, 07:56 AM
  #7
Velo Mule
Senior Member

Velo Mule's Avatar

Join Date: Dec 2016
Location: Long Island, NY
Posts: 1,520

Bikes: Trek 800 x 2, Schwinn Heavy Duti, Schwinn Traveler, Schwinn Le Tour Luxe, Schwinn Continental, Cannondale M400 and Lampert

Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 544 Post(s)
Liked 480 Times in 355 Posts
At a bike show in 2019, I saw the Alizeti kit. At first I dismissed it, however, the kit is well thought out and easy to install. It even has traction control. One other thing that I like about this kit is if I have a bike I like, for instance a vintage Peugeot mixte, it doesn't' change it much.

Velo Mule is offline
Likes For Velo Mule:
Old 12-15-21, 05:05 PM
  #8
Doc_Wui
Senior Member

Doc_Wui's Avatar

Join Date: Jul 2015
Location: Chicago Suburbs
Posts: 1,269

Bikes: GT Transeo & a half dozen ebike conversions.

Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 312 Post(s)
Liked 177 Times in 128 Posts
I have built a kit with a 750W mid drive Bafang BBS02 ($450-500 today). My original battery was $550 in 2016. so my kit cost over $1000, but it lets this old man climb any hill that a strong biker on a regular bike can handle and is faster (28 mph) than I ever go., and that's good enough for me. Battery prices have dropped too, so I could probably but that battery for $400. You won't find a import ebike for $1000 that can do that.

Here is a different bike. Rear hub motor and electrics about $250. , I'm using a custom pack under the seat I had built for $250.I don't think there is a 20" electric folder on the market with front and rear suspension. That's the nice thing about kits. You can electrify a bike that you like. Keep it light and it handles like the original bike, but a bit heavier.


Last edited by Doc_Wui; 12-15-21 at 05:12 PM.
Doc_Wui is offline
Likes For Doc_Wui:
Old 12-16-21, 08:09 AM
  #9
sloppy12
Senior Member

Join Date: Oct 2020
Posts: 480
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 166 Post(s)
Liked 247 Times in 145 Posts
Originally Posted by thook View Post
i have a client (i do home/odds and ends repair) that's looking to sell his truck after i getting it running and then build an e-bike with a 26" mtb. i know nothing about e-bikes, but been working manual bikes for decades. iow's, if there's a universal type kit, i'm sure i can put it together for him. i suspect any kit will have fitment parameters, and perhaps in the next few days i can get a few photos together for the thread so ya'll can better help. but, are there kits that bolt on like there are for motorized bikes?? where should i look and what should i look for in terms of quality and best frame fit?

thanks,
matthew
Hub drives are the easier to build up and cheaper. mid drives are easier in the field. for full blown commuter I think hub drives are totally adequate. Get a good battery for a good source(skip amazon and ebay unless you know for sure its a trusted source).

its been mentioned but ebikes.ca has a ton of info he is pretty hub drive focused but the info is valuable either way. endless-sphere is a pretty active ebike forum.

If you have worked on bikes the hardest part of the conversion will be wading threw the endless interwebs BS about whats better and what wont work.
sloppy12 is offline
Likes For sloppy12:
Old 12-16-21, 11:21 AM
  #10
mclewis1
Member

Join Date: Dec 2020
Posts: 43
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Liked 28 Times in 20 Posts
Just a few comments about commercial ebike vs. DIY. I've built up a few bikes from scratch and do most of my own maintenance but I'm by no means some professional bike mechanic. Last summer I started looking for a replacement for an all season hybrid bike for commuting and shopping, and I also wanted to explore an assisted setup (ebike). The two thoughts were separate, I wanted to continue to ride a bike (and I'm quite picky about fit and performance) and not have the idea of an ebike totally take over (didn't want a moped style setup). So I purchased a solid dependable replacement for the old hybrid that had the additional features I wanted/needed (primarily larger tires with room for fenders) plus using standard (older) dimensions for dropouts and such so the upgrade to an ebike would be easier.

The bike is a steel framed 27.5" Surly Bridge Club (considered an adventure touring type of bike) - about $1300 CAD (on sale)
The kit was from Grin (ebikes.ca). 500w geared hub, 750w 52v battery - also about $1300 CAD (the premium battery was about half the kit).
About 1/2 a day of my time for the conversion.

With new tires, fenders, etc. I ended up around $3K CAD invested. Yes I could have found a commuter style ebike for about the same price but for that price I have a customized setup that is sized well for me, has lower weight, a larger battery, better tires (winter studded), and generally better components. Plus I learned a ton about ebike technology, efficiencies and tuning for a precise feel (from the Grin Cycle Analyst display). So in the long run I came out well ahead of buying a commercial ebike.
mclewis1 is offline
Likes For mclewis1:
Old 12-16-21, 11:35 AM
  #11
thook
(rhymes with spook)
Thread Starter

thook's Avatar

Join Date: Aug 2009
Location: Winslow, AR
Posts: 2,784

Bikes: '83 univega gran turismo x2, '85 schwinn super le tour,'89 miyata triple cross, '91 GT tequesta, '90 yokota grizzly peak, '94 GT backwoods, '95'ish scott tampico, '98 bonty privateer, '93 mongoose crossway 625, '98 parkpre ariel, 2k'ish giant fcr3

Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 914 Post(s)
Liked 733 Times in 540 Posts
Thank you all for the input. things I haven't considered and didn't think to. I'll see where the guy's at with regards to all the info here and reply back soon. Probably with some questions.
thook is offline
Old 12-17-21, 07:53 AM
  #12
cat0020
Ride more, eat less

cat0020's Avatar

Join Date: Feb 2007
Location: Philla PA, Hoboken NJ, Brooklyn NY
Posts: 1,478

Bikes: Too many but never enough.

Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 433 Post(s)
Liked 313 Times in 212 Posts
For $1600 complete ebike, this is hard to beat:
https://electrek.co/2021/12/16/ride1...w-entry-price/
cat0020 is offline
Likes For cat0020:
Old 12-17-21, 08:20 AM
  #13
sloppy12
Senior Member

Join Date: Oct 2020
Posts: 480
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 166 Post(s)
Liked 247 Times in 145 Posts
Originally Posted by cat0020 View Post
For $1600 complete ebike, this is hard to beat:
https://electrek.co/2021/12/16/ride1...w-entry-price/
I dont think I would even attempt to build a bike for commuting with this option...

Well for a customer anyway.
sloppy12 is offline
Old 12-17-21, 10:03 AM
  #14
mclewis1
Member

Join Date: Dec 2020
Posts: 43
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Liked 28 Times in 20 Posts
That's indeed a nice new option.
A couple of comments ... while it's common "lawyerese" I wouldn't be happy with a bike for commuting that has the disclaimer of "While we do not recommend leaving the bikes out in the rain or riding in the rain or other hazardous conditions due to personal safety, the bikes can handle water exposure." So while it is highly unlikely to leave you stranded it would weigh on my mind.
The other wet weather related issue - that front fender is too short. It will allow the front wheel to spray water all over your feet in the rain.
mclewis1 is offline
Old 12-17-21, 10:10 AM
  #15
linberl
Senior Member

linberl's Avatar

Join Date: Jun 2014
Location: SF Bay Area
Posts: 3,220

Bikes: 2017 BF pakiT & Dahon Mu Uno (both for sale); current ride - Trident Spike trike w/ e-assist

Mentioned: 25 Post(s)
Tagged: 0 Thread(s)
Quoted: 1224 Post(s)
Liked 248 Times in 199 Posts
One other consideration between types of kits/commercial bikes - will you ever want to ride unmotored? You can't drop the weight on a commercial ebike, so that's not an option. Some kits will allow you to swap out the front wheel and eliminate the hub motor and remove the battery. Some kits are easily removable (Alizetii, Onemotor, etc.). And some kits (mid-drives, rear wheel) are not. If you have a stable of bikes, it's probably. not a consideration. If you've one bike, it might be something to think about as well. I love my bike and don't want to spend the $ to buy two of them so I can ride one unmotored, so an easily removable kit is a priority. It also helps with the theft issue as well =)..
linberl is offline
Likes For linberl:
Old 12-17-21, 03:34 PM
  #16
2old
Senior Member

Join Date: Jul 2014
Location: socal
Posts: 3,422
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 678 Post(s)
Liked 466 Times in 355 Posts
Friction kits make a lot of sense (to me) when the bike has road tires, dirt not so much.
2old is offline
Old 12-17-21, 07:59 PM
  #17
Lastmohecken
Member

Join Date: Nov 2021
Posts: 35

Bikes: CB4 COGBURN FAT TIRE MOUNTAIN BIKE, with severe modifications

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 17 Post(s)
Liked 6 Times in 5 Posts
I am in kind of in the same boat. I want an ebike, because of the hills around me, and at 64 and 50 lbs overweight, I need a little help getting up some hills. I test road several ebikes at one shop. Most were pedal assist only and ranges from 350 Kw up to 650 Kw. They would have been all right in town on paved streets but not where I live. I also rode a KOA brand fat tire ebike with a 750 rear drum motor, with throttle, and I think it had more power and might have worked for me. However, all of these bikes were rated for less weight than I weight. The Radrover, which I have not seen or ridden, has a higher weight rating, so I am leaning towards one of those for around $1600.00

However, I am also considering converting my existing fat bike with a Bafang 1000 Kw mid mount motor, but this set up will still yet cost me probably $1200.00 However, I would have considerably more power, but it would also be considered illegal for the street and bike trail use, but I doubt that's a problem for me, since I don't ride there anyway. I have to go to the 1000 Kw HD, anyway, because my lower bracket is too wide for the Bafang 750 Kw, but after riding the KOA, I kind of want more power, anyway.

Last edited by Lastmohecken; 12-17-21 at 08:02 PM.
Lastmohecken is offline
Old 12-19-21, 10:41 AM
  #18
Sempervee
Senior Member

Sempervee's Avatar

Join Date: Feb 2020
Location: Olympia WA
Posts: 97

Bikes: Cannondale Quick Disk 5 & Rad Power Mini

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 30 Post(s)
Liked 26 Times in 23 Posts
LOVE the idea of this and considering getting one! Thanks for letting us know.
Sempervee is offline
Old 12-19-21, 10:42 AM
  #19
Sempervee
Senior Member

Sempervee's Avatar

Join Date: Feb 2020
Location: Olympia WA
Posts: 97

Bikes: Cannondale Quick Disk 5 & Rad Power Mini

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 30 Post(s)
Liked 26 Times in 23 Posts
Originally Posted by Velo Mule View Post
At a bike show in 2019, I saw the Alizeti kit. At first I dismissed it, however, the kit is well thought out and easy to install. It even has traction control. One other thing that I like about this kit is if I have a bike I like, for instance a vintage Peugeot mixte, it doesn't' change it much.

Alizeti e-bike kit into
LOVE the idea of this and considering getting one! Thanks for letting us know.
Sempervee is offline
Old 12-19-21, 11:54 AM
  #20
Chinghis
Senior Member

Join Date: Jul 2013
Location: Southern California
Posts: 387

Bikes: Historical: Schwinn Speedster; Schwinn Collegiate; 1981 Ross Gran Tour; 1981 Dawes Atlantis; 1991 Specialized Rockhopper. Current: 1987 Ritchey Ultra; 1987 Centurion Ironman Dave Scott Master; 1992 Specialized Stumpjumper FS

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 156 Post(s)
Liked 117 Times in 68 Posts
Originally Posted by Sempervee View Post
LOVE the idea of this and considering getting one! Thanks for letting us know.
Yeah, that's an interesting solution. I always have a rack on my commuting bike, so this would fit right in. Pretty cool.
Chinghis is offline
Old 12-19-21, 12:01 PM
  #21
northernjeep
Senior Member

Join Date: Feb 2016
Posts: 50
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked 25 Times in 11 Posts
Bbshd

Originally Posted by Lastmohecken View Post
I am in kind of in the same boat. I want an ebike, because of the hills around me, and at 64 and 50 lbs overweight, I need a little help getting up some hills. I test road several ebikes at one shop. Most were pedal assist only and ranges from 350 Kw up to 650 Kw. They would have been all right in town on paved streets but not where I live. I also rode a KOA brand fat tire ebike with a 750 rear drum motor, with throttle, and I think it had more power and might have worked for me. However, all of these bikes were rated for less weight than I weight. The Radrover, which I have not seen or ridden, has a higher weight rating, so I am leaning towards one of those for around $1600.00

However, I am also considering converting my existing fat bike with a Bafang 1000 Kw mid mount motor, but this set up will still yet cost me probably $1200.00 However, I would have considerably more power, but it would also be considered illegal for the street and bike trail use, but I doubt that's a problem for me, since I don't ride there anyway. I have to go to the 1000 Kw HD, anyway, because my lower bracket is too wide for the Bafang 750 Kw, but after riding the KOA, I kind of want more power, anyway.
I believe a BBSO2 now is offered in a wider bottom bracket version. I installed the HD version on my fat bike over 4 years ago and it has been trouble free. So far the only thing that broke was the freehub once. If you get the HD make sure to buy an E bike specific chain
northernjeep is offline
