Repair a bike chain.

Notices
General Cycling Discussion Have a cycling related question or comment that doesn't fit in one of the other specialty forums? Drop on in and post in here! When possible, please select the forum above that most fits your post!

Repair a bike chain.

Old 08-10-17, 12:25 PM
  #1
Desmond56
Junior Member
Thread Starter

Join Date: Aug 2017
Posts: 11
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Repair a bike chain.

My chain broke. I am not a biker and no nothing about this. I looked on the internet and bought a chain link remover/repairer. The chain might be old as it didn't fit comfortably in the remover. I couldn't do the repair. I was also considering buying a new chain but wasn't sure if there is a standard chain size.

My bike has 9 cocks on back wheel and 3 in the centre of the bike, so this is 27 speed.

I saw this on ebay.
SHIMANO HG53 9 Speed Deore / Tiagra MTB MTN Road Bike Chain CNHG53
Attached Images
File Type: jpg
Desmond56 is offline
Old 08-10-17, 12:28 PM
  #2
manapua_man
Senior Member

Join Date: Sep 2010
Posts: 1,023
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 223 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Sounds like you have a 9spd chain.

Youtube is your friend. Seriously, there's hundreds of videos for stuff like this and most of them are easier to understand than a mountain of descriptive text on a forum.

Also, Park Tool has a lot of repair videos that will help a lot too.
manapua_man is offline
Old 08-10-17, 12:35 PM
  #3
doctor j
Senior Member

Join Date: Aug 2006
Location: Central Louisiana
Posts: 3,055
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 41 Post(s)
Likes: 0
Liked 4 Times in 1 Post
I've been using KMC chains for a few years now, and they use a "missing link" that makes the two ends easy to join together. Good service from them. Yes, check out Youtube. You can replace a chain.
doctor j is offline
Old 08-10-17, 12:47 PM
  #4
Shimagnolo
Senior Member

Shimagnolo's Avatar

Join Date: May 2008
Location: Zang's Spur, CO
Posts: 8,896
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 2089 Post(s)
Liked 994 Times in 575 Posts
All you need is to replace the broken link with this: 9 SPEED CHAIN KMC Missing Link 9 Speed missinglink
Shimagnolo is online now
Old 08-10-17, 12:51 PM
  #5
manapua_man
Senior Member

Join Date: Sep 2010
Posts: 1,023
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 223 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Forgot to mention- OP, you might want to read up on when you need to replace chains, cassettes, and chain rings. Those parts do wear out and need replacing every so often.
manapua_man is offline
Old 08-10-17, 12:54 PM
  #6
WNCGoater
Senior Member

WNCGoater's Avatar

Join Date: Jun 2015
Location: Western NC mountains
Posts: 925

Bikes: Diamondback Century 3. Marin Four Corners

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 414 Post(s)
Likes: 0
Liked 3 Times in 2 Posts
The fact that the chain "broke" sort of makes one assume it was badly worn and in need of a replacement. Some chains use a "master" link at the end and are simple to replace, requiring no special tools. Others use a breakaway pin and need that little link tool you have posted (Or similar) I have a park tool multi-tool that has that link tool built in and it saved our bacon one day back in the woods on mtn bikes when one of our group broke his chain. A chain tool can prove handy to have, it's one of those things that is a requirement if you need to push out or reseat a chain pin. Nothing else will work.
WNCGoater is offline
Old 08-10-17, 12:58 PM
  #7
fietsbob
Banned

Join Date: Jun 2010
Location: NW,Oregon Coast
Posts: 43,598

Bikes: 8

Mentioned: 197 Post(s)
Tagged: 0 Thread(s)
Quoted: 7607 Post(s)
Liked 1,284 Times in 801 Posts
No longer can the pin be pressed back in and be secure,, buy a new chain shorten it to length.

save that section, get a couple spare quick links*, if you break another chain that spare section and those 2 quick links
is how you will repair it.

there is no extra pin length , they are flush to get more 'speeds' (cogs) in that narrow space.


*Whipperman and KMC..





....

Last edited by fietsbob; 08-10-17 at 01:06 PM.
fietsbob is offline
Old 08-10-17, 01:02 PM
  #8
VegasTriker
Senior Member

Join Date: Feb 2006
Location: Sin City, Nevada
Posts: 2,338

Bikes: Catrike 700, Greenspeed GTO trike, , Linear LWB recumbent, Haluzak Horizon SWB recumbent, Balance 450 MTB, Cannondale SM800 Beast of the East

Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 373 Post(s)
Likes: 0
Liked 63 Times in 52 Posts
Most modern bike chains have the pins mushroomed at the ends so that the plates almost never let go resulting in a broken chain. It also means that it is harder to put back together a chain once a link has been opened. That's why a lot of newer chains come with the master link that you can open easily, especially if you buy one of the $10 master link openers. New chains have either 114 or 116 links. You can use your chain tool to remove extra links to make it match your current chain. The KMC 9X.93 chain is used on a lot of new bikes. I have a 10 speed version of this chain with many thousands of miles on it. Don't buy the master link shown above because it will only connect the outer plate link. It's also way overpriced since you can buy an entire 116 link chain including the master link for $12.40 and have it in your mailbox at the latest by next Friday, Aug 18.
KMC X9.93 Road MTB Hybrid Bike 9 Speed Chain fit Shimano SRAM Campagnolo Bulk 116 links including the master link $12.40 postpaid KMC X9.93 Road MTB Hybrid Bike 9 Speed Chain fit Shimano SRAM Campagnolo Bulk | eBay


And if you want to buy some spare master links, use overseas sellers where the exact same master link costs under $1 including shipping. Be sure to specify "9 speed" when ordering 2pcs KMC Missing Link Bike Master Chain Link Connector 6/7/8/9/10 Speed | eBay
VegasTriker is offline
Old 08-10-17, 01:12 PM
  #9
CliffordK
Senior Member

CliffordK's Avatar

Join Date: Nov 2014
Location: Eugene, Oregon, USA
Posts: 24,731
Mentioned: 197 Post(s)
Tagged: 0 Thread(s)
Quoted: 11771 Post(s)
Liked 1,074 Times in 835 Posts
Originally Posted by Desmond56 View Post
SHIMANO HG53 9 Speed Deore / Tiagra MTB MTN Road Bike Chain CNHG53
HG53, HG73, and HG93 Shimano chains are all similar, and will work on your bike. Some come with quick links, some come with a pin pushed halfway in, and all you have to do is splice, and push the pin the rest of the way in.

I've got dirt cheap HG73 chains on E-Bay shipped from China, and I've never been certain whether they are genuine Shimano products, or some clone product. They do wear out with between 1000 and 2000 miles riding which seems quick.

There are other brands worth considering too.

Periodically I'll push out a pin (90%) and re-use it on the 9s chains without problems. The 10s and 11s seem to rely heavier on peened pins.
CliffordK is online now
Old 08-10-17, 01:37 PM
  #10
smarkinson
Senior Member

Join Date: May 2015
Posts: 1,003
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 332 Post(s)
Liked 13 Times in 7 Posts
If your chain is old enough that it broke chances are you will also need to replace the cogs at the rear. As the chain wears it stretches. A stretched chain will cause the teeth on the cogs to wear. If you put a new chain on and leave the worn cogs it is likely the chain will start skipping which is not good or safe.

Replacing the cassette is possible by a hme mechanic but it requires a few more tools, a chain whip, cassette removal tool and a big spanner.

Replacing the chain and cassette it be worth getting a quote from your local bike store.
smarkinson is offline
Old 08-10-17, 02:01 PM
  #11
Doctor Morbius
Interocitor Command

Doctor Morbius's Avatar

Join Date: Oct 2003
Location: The adult video section
Posts: 3,374

Bikes: 3 Road Bikes, 2 Hybrids

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 586 Post(s)
Liked 55 Times in 33 Posts
Take your bike to a bike shop ASAP! Any bike with 9 cocks needs immediate attention. No what I mean?
Doctor Morbius is offline
Old 08-10-17, 02:04 PM
  #12
ptempel
Senior Member

Join Date: Feb 2005
Location: New Jersry the beautiful Garden State
Posts: 1,917

Bikes: 2007 Ridley Excalibur, 2003 Orbea Orca, 199? Cannondale Headshock MTB hardtail

Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 515 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
I agree with @VegasTriker to just replace the chain with a cheap and cheerful KMC. If it skips in any of the back gears, then also replace the 9 speed cassette. If you're doing this yourself, then you'll need the chaintool you referred to above, a cassette removal tool, a chain whip (or channel lock plier) and an adjustable wrench. Check out the youtube.com vids on chain and cassette removal to see if you want to tackle it or not. Its not too hard, really. And these two jobs are right behind replacing tires and break pads in terms of wearable items. So worth the time and effort if you're so inclined.
ptempel is offline
Old 08-10-17, 02:05 PM
  #13
Shimagnolo
Senior Member

Shimagnolo's Avatar

Join Date: May 2008
Location: Zang's Spur, CO
Posts: 8,896
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 2089 Post(s)
Liked 994 Times in 575 Posts
Originally Posted by Doctor Morbius View Post
Take your bike to a bike shop ASAP! Any bike with 9 cocks needs immediate attention. No what I mean?
I imagine those cocks make a hell of a lot of noise around dawn every morning!
Shimagnolo is online now
Old 08-10-17, 02:10 PM
  #14
ptempel
Senior Member

Join Date: Feb 2005
Location: New Jersry the beautiful Garden State
Posts: 1,917

Bikes: 2007 Ridley Excalibur, 2003 Orbea Orca, 199? Cannondale Headshock MTB hardtail

Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 515 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
Originally Posted by Doctor Morbius View Post
Take your bike to a bike shop ASAP! Any bike with 9 cocks needs immediate attention. No what I mean?
Am getting bad images in my head. Must... shake... them... off...

Edit: I never know what an Interocitor was. Just looked it up: https://en.wikipedia.org/wiki/Interocitor I wonder if "This Island Earth" was one of the inspirations for Carl Sagan's "Contact."

Last edited by ptempel; 08-10-17 at 02:20 PM.
ptempel is offline
Old 08-10-17, 02:21 PM
  #15
BlazingPedals
Senior Member

BlazingPedals's Avatar

Join Date: Dec 2004
Location: Middle of da Mitten
Posts: 11,584

Bikes: Trek 7500, RANS V-Rex, Optima Baron, Velokraft NoCom, M-5 Carbon Highracer, Catrike Speed

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 1175 Post(s)
Liked 253 Times in 179 Posts
These days, the tool you pictured is only used to shorten a new chain to the correct length for your bike. With Shimano chains, you replace a pin -- you can't re-use the current pin. With virtually all other brands of chain, you use a master link (various trademarked names for them. Even the Shimano chains should accept a master link, as long as you get one for the right width of chain -- 7/8, 9, 10, or 11 speed.

BlazingPedals is offline
Old 08-10-17, 02:30 PM
  #16
Milton Keynes
Senior Member

Milton Keynes's Avatar

Join Date: May 2016
Posts: 2,991

Bikes: Trek 1100 road bike, Roadmaster gravel/commuter/beater mountain bike

Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 1341 Post(s)
Liked 286 Times in 156 Posts
Originally Posted by Doctor Morbius View Post
Take your bike to a bike shop ASAP! Any bike with 9 cocks needs immediate attention. No what I mean?
Milton Keynes is offline
Old 08-10-17, 02:37 PM
  #17
Milton Keynes
Senior Member

Milton Keynes's Avatar

Join Date: May 2016
Posts: 2,991

Bikes: Trek 1100 road bike, Roadmaster gravel/commuter/beater mountain bike

Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 1341 Post(s)
Liked 286 Times in 156 Posts
Originally Posted by ptempel View Post
Am getting bad images in my head. Must... shake... them... off...

Edit: I never know what an Interocitor was. Just looked it up: https://en.wikipedia.org/wiki/Interocitor I wonder if "This Island Earth" was one of the inspirations for Carl Sagan's "Contact."
Milton Keynes is offline
Old 08-11-17, 06:33 AM
  #18
Desmond56
Junior Member
Thread Starter

Join Date: Aug 2017
Posts: 11
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Hi. As I said I am not a biker and new to this.

I have looked at some chains in the UK. Amazon has this.
SRAM PC-951 9 Speed Mountain Bike Chain 114 Links Nickel Plated 1/2" x 11/128

This looks ok as mine is a mountain bike and has nine rear cogs.
It is 7.38

The shop I spoke to said Chain is 18 and 10 to fit. Will probably need the cassett changing @ 25 + 10 to fit.

Total cost 43. He also said if I use it just to commute then I would need to do this every year and a half.

P.S. what do these 3 figures mean. 1/2" x 11/128
Desmond56 is offline
Old 08-11-17, 08:08 AM
  #19
Maelochs
Senior Member

Maelochs's Avatar

Join Date: Oct 2015
Posts: 12,269

Bikes: 2015 Workswell 066, 2014 Dawes Sheila, 1983 Cannondale 500, 1984 Raleigh Olympian, 2007 Cannondale Rize 4, 2017 Fuji Sportif 1 LE

Mentioned: 142 Post(s)
Tagged: 0 Thread(s)
Quoted: 5880 Post(s)
Liked 570 Times in 347 Posts
Get a chain break tool for 5, chains for 12-15 or less, a chain whip and lockring tool for at max 25 total, some quicklinks (shop on Ebay, get the best deal ...)

I spent another 20 and got opening and closing tools for the quicklinks but that is an extravagance.

For "fitting" the chain, make sure the chain is the same length as the one which came off the bike. Then thread it through (park Tools or YouTube video if you are unsure) ... and for the rest of the time you ride bicycles you will never need to go to the shop for any of that.

Oh ... 1/2" long links by 11/128 wide plates, i believe.
Maelochs is offline
Old 08-11-17, 08:13 AM
  #20
indyfabz
Senior Member

indyfabz's Avatar

Join Date: Jan 2010
Posts: 27,519
Mentioned: 194 Post(s)
Tagged: 1 Thread(s)
Quoted: 11741 Post(s)
Liked 3,570 Times in 1,899 Posts
Originally Posted by Doctor Morbius View Post
No what I mean?

Know. I don't.
indyfabz is offline
Old 08-11-17, 12:13 PM
  #21
BlazingPedals
Senior Member

BlazingPedals's Avatar

Join Date: Dec 2004
Location: Middle of da Mitten
Posts: 11,584

Bikes: Trek 7500, RANS V-Rex, Optima Baron, Velokraft NoCom, M-5 Carbon Highracer, Catrike Speed

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 1175 Post(s)
Liked 253 Times in 179 Posts
Originally Posted by indyfabz View Post
Know. I don't.
Ya beat me to it.

To answer the subsequent questions, you can have the shop do it or you can invest in a few tools and do it yourself. Replacing the chain is one of the easiest maintenance jobs. You need a chain whip, the cassette tool, and a 8-10" crescent wrench to get the cassette off, and one of those chain tools to correctly size the chain. Lay the old chain alongside the new one to see the proper size. The old one will be longer, but only by a fraction of an inch. If you replace the chain before it's totally worn, a single cassette will last through several chain replacements.

Chains are 1/2" pitch, which means there is a roller every 1/2 inch. You can measure chain wear with a go/no go tool, which I regard as highly inaccurate, or you can simply measure from pin to pin across 12 full links (24 rollers.) I replace my chain when it measures 12 1/16" across 12 links. The width of the chain you need depends on how many gears on the cassette. 11/128 is a 9-speed chain. Tighter spacing for 10-11 speeds requires narrower chains while old 5-speed freewheels require wider ones.
BlazingPedals is offline
Old 08-11-17, 12:23 PM
  #22
indyfabz
Senior Member

indyfabz's Avatar

Join Date: Jan 2010
Posts: 27,519
Mentioned: 194 Post(s)
Tagged: 1 Thread(s)
Quoted: 11741 Post(s)
Liked 3,570 Times in 1,899 Posts
Originally Posted by BlazingPedals View Post
Ya beat me to it.

Sadly, thanks to increased activity of a certain nature in this forum, I am disinclined to believe the sincerity of threads started by new members when those threads contain wild stories and/or things like confusing "cogs" with "cocks" and "no" with "know."
indyfabz is offline
Old 08-11-17, 01:02 PM
  #23
rachel120
Senior Member

Join Date: Jul 2017
Posts: 711
Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 622 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by indyfabz View Post
Sadly, thanks to increased activity of a certain nature in this forum, I am disinclined to believe the sincerity of threads started by new members when those threads contain wild stories and/or things like confusing "cogs" with "cocks" and "no" with "know."
Those are likely to be a phone's autocorrect. When I post via phone in a forum the initial draft makes me wonder if my phone knows English.

Could also be someone as new as me, who has to Google the proper terms and hope I'm not getting them mixed up whenever I need mechanical help.
rachel120 is offline
Old 08-11-17, 03:08 PM
  #24
Doctor Morbius
Interocitor Command

Doctor Morbius's Avatar

Join Date: Oct 2003
Location: The adult video section
Posts: 3,374

Bikes: 3 Road Bikes, 2 Hybrids

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 586 Post(s)
Liked 55 Times in 33 Posts
Originally Posted by rachel120 View Post
Those are likely to be a phone's autocorrect. When I post via phone in a forum the initial draft makes me wonder if my phone knows English.
Do you have an X-Rated autocorrect? Cogs is a fairly common word, although perhaps not as common as the other.
Doctor Morbius is offline
Old 08-11-17, 03:30 PM
  #25
Retro Grouch
Senior Member

Retro Grouch's Avatar

Join Date: Feb 2004
Location: St Peters, Missouri
Posts: 29,936

Bikes: Catrike 559 I own some others but they don't get ridden very much.

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 1450 Post(s)
Liked 357 Times in 219 Posts
Originally Posted by WNCGoater View Post
The fact that the chain "broke" sort of makes one assume it was badly worn and in need of a replacement. Some chains use a "master" link at the end and are simple to replace, requiring no special tools.
That's not right.

When you buy a new chain it will be too long for your bike when it comes. It always has to be custom shortened to fit your bike. It's not hard to do but it does require a chain tool.

I do agree with WNCGoater that since one link has broken the whole chain is suspect. Bicycle chains don't last forever. If it was my bike, I'd definitely replace it.
__________________
My greatest fear is all of my kids standing around my coffin and talking about "how sensible" dad was.
Retro Grouch is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright 2018 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
