..lets tawk bike fitting-long torso, short legs
I was born with a very long torso and a very short pair of legs....
Golf equipment and bikes have been hard to fit me.
I can fit on a frame that is 52cm and the balls of my feet just touch the ground..... however, when I ride, the length of the bike feels too short.
Can I buy a few extra-long handlebar stems, or a few seat post that allows the seats to go way, way back?
thx...
Golf equipment and bikes have been hard to fit me.
I can fit on a frame that is 52cm and the balls of my feet just touch the ground..... however, when I ride, the length of the bike feels too short.
Can I buy a few extra-long handlebar stems, or a few seat post that allows the seats to go way, way back?
thx...
#2
Guest
Join Date: Sep 2020
Posts: 2,888
Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 1346 Post(s)
Liked 3,261 Times
in
1,437 Posts
Maybe tawk about it in the "Fitting Your Bike" subforum: https://www.bikeforums.net/fitting-your-bike/
#3
Senior Member
Join Date: Feb 2015
Location: Mission Viejo
Posts: 5,445
Bikes: 1986 Cannondale SR400 (Flat bar commuter), 1988 Cannondale Criterium XTR, 1992 Serotta T-Max, 1995 Trek 970
Mentioned: 20 Post(s)
Tagged: 0 Thread(s)
Quoted: 1815 Post(s)
Liked 1,955 Times
in
1,200 Posts
When you say the balls of you feet just touch the ground on a 52cm, you are referring to stand over and not on the saddle.
You can go with a bit longer stem to get more stretch. I’m not a fan of moving the seat back beyond what is the outside the optimal range for comfort and performance, but there is probably a little bit to be gained.
Over 30 years ago I was at a weekend event and rode a lot more miles than I usually do. When I had to drive home I had to use my left leg because the right hip was throbbing so much. It turned out my left leg was a cm shorter and I was stressing my right hip trying to fully extend while riding.
Over the years I fashioned a 1/4” shim under the left cleat that worked well enough. But then I made a DIY insole from cheap EVA flip flops from Walmart. It really works great.
The real solution is getting a frame made for you, but you may b able to add an insole to both cycling shoes, lengthen the stem a bit and find the longest ETT bike that allows you to stand over, even If you have to lean it a bit.
I have a long torso for my leg length and ride a frame that is technically too big for me but I have just gotten used to leaning the bike when I come to a stop.
John
You can go with a bit longer stem to get more stretch. I’m not a fan of moving the seat back beyond what is the outside the optimal range for comfort and performance, but there is probably a little bit to be gained.
Over 30 years ago I was at a weekend event and rode a lot more miles than I usually do. When I had to drive home I had to use my left leg because the right hip was throbbing so much. It turned out my left leg was a cm shorter and I was stressing my right hip trying to fully extend while riding.
Over the years I fashioned a 1/4” shim under the left cleat that worked well enough. But then I made a DIY insole from cheap EVA flip flops from Walmart. It really works great.
The real solution is getting a frame made for you, but you may b able to add an insole to both cycling shoes, lengthen the stem a bit and find the longest ETT bike that allows you to stand over, even If you have to lean it a bit.
I have a long torso for my leg length and ride a frame that is technically too big for me but I have just gotten used to leaning the bike when I come to a stop.
John
#4
Senior Member
Join Date: Oct 2009
Location: Sherwood, OR
Posts: 1,265
Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 329 Post(s)
Liked 293 Times
in
172 Posts
The setback of your saddle should be independent of stem length. They accomplish different things.
I recommend that you see a fitter if you are having problems. I have long torso, short legs, but long femurs. My femur length dictates the seatpost setback and the length of my torso (and my flexibility) dictate the stem length.
If I hurt my back, I see my doctor or a physical therapist. If my neck hurts, same. If my knees hurt, I see a physical therapist. If my neck, back, and knees hurt while I ride a bike, why do we all flock to the bike shop? Seeing a doctor or physical therapist for pain while performing a physical activity is covered by insurance. My bike fit from a PT was covered 100%. If you have even halfway decent insurance, it is worth looking into.
I recommend that you see a fitter if you are having problems. I have long torso, short legs, but long femurs. My femur length dictates the seatpost setback and the length of my torso (and my flexibility) dictate the stem length.
If I hurt my back, I see my doctor or a physical therapist. If my neck hurts, same. If my knees hurt, I see a physical therapist. If my neck, back, and knees hurt while I ride a bike, why do we all flock to the bike shop? Seeing a doctor or physical therapist for pain while performing a physical activity is covered by insurance. My bike fit from a PT was covered 100%. If you have even halfway decent insurance, it is worth looking into.
#5
Drip, Drip.
Join Date: Oct 2020
Location: Southern Ontario
Posts: 1,574
Bikes: Trek Verve E bike, Felt Doctrine 4 XC, Opus Horizon Apex 1
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 1032 Post(s)
Liked 190 Times
in
160 Posts
If your feet touch the ground when you are sitting on the saddle, you got the seat set too low. Your toes pretty much shouldn't be able to touch the ground.
Likes For Moisture:
#6
Sunshine
Join Date: Aug 2014
Location: Des Moines, IA
Posts: 15,100
Bikes: '18 class built steel roadbike, '19 Fairlight Secan, '88 Schwinn Premis , Black Mountain Cycles Monstercross V4, '89 Novara Trionfo
Mentioned: 120 Post(s)
Tagged: 0 Thread(s)
Quoted: 9425 Post(s)
Liked 5,785 Times
in
3,347 Posts
I was born with a very long torso and a very short pair of legs....
Golf equipment and bikes have been hard to fit me.
I can fit on a frame that is 52cm and the balls of my feet just touch the ground..... however, when I ride, the length of the bike feels too short.
Can I buy a few extra-long handlebar stems, or a few seat post that allows the seats to go way, way back?
thx...
Golf equipment and bikes have been hard to fit me.
I can fit on a frame that is 52cm and the balls of my feet just touch the ground..... however, when I ride, the length of the bike feels too short.
Can I buy a few extra-long handlebar stems, or a few seat post that allows the seats to go way, way back?
thx...
2- don't move the saddle around to make the bike feel longer as that isnt what saddle movement is for.
if your bike does fit for height, then measure the reach(Google how for a video) and go find a bike with the same height(stack height) but longer reach.
#7
Drip, Drip.
Join Date: Oct 2020
Location: Southern Ontario
Posts: 1,574
Bikes: Trek Verve E bike, Felt Doctrine 4 XC, Opus Horizon Apex 1
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 1032 Post(s)
Liked 190 Times
in
160 Posts
1- if you can stand while on the saddle, the saddle is too low or the bike is too small.
2- don't move the saddle around to make the bike feel longer as that isnt what saddle movement is for.
if your bike does fit for height, then measure the reach(Google how for a video) and go find a bike with the same height(stack height) but longer reach.
2- don't move the saddle around to make the bike feel longer as that isnt what saddle movement is for.
if your bike does fit for height, then measure the reach(Google how for a video) and go find a bike with the same height(stack height) but longer reach.
#8
Sunshine
Join Date: Aug 2014
Location: Des Moines, IA
Posts: 15,100
Bikes: '18 class built steel roadbike, '19 Fairlight Secan, '88 Schwinn Premis , Black Mountain Cycles Monstercross V4, '89 Novara Trionfo
Mentioned: 120 Post(s)
Tagged: 0 Thread(s)
Quoted: 9425 Post(s)
Liked 5,785 Times
in
3,347 Posts
Let's Discuss Frame Geometry
You tell us. You are the geometry expert.
You tell us. You are the geometry expert.
#9
Senior Member
I recommend using https://www.competitivecyclist.com/S...ulatorBike.jsp or similar to get a set of recommendations.
My torso/arms are relatively long compared to my legs. The typical square bike (54 CM ST, 54 CM ETT) feels wrong to me. I lucked into a 1973 English production frame. It was common then to vary the ST length and use a standard TT, so it's 21" X 22". With an 11 CM stem, it fits me well. That may be what you need - but it depends on your actual dimensions. I recommend the fit calculator, because I don't know ho many BF members can turn dimensions into recommended sizes.
My torso/arms are relatively long compared to my legs. The typical square bike (54 CM ST, 54 CM ETT) feels wrong to me. I lucked into a 1973 English production frame. It was common then to vary the ST length and use a standard TT, so it's 21" X 22". With an 11 CM stem, it fits me well. That may be what you need - but it depends on your actual dimensions. I recommend the fit calculator, because I don't know ho many BF members can turn dimensions into recommended sizes.
#10
Randomhead
Join Date: Aug 2008
Location: Happy Valley, Pennsylvania
Posts: 23,114
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Liked 2,695 Times
in
1,875 Posts
The good news is that bikes are getting longer.
What kind of bike are you interested in?
What kind of bike are you interested in?
#11
Senior Member
I was born with a very long torso and a very short pair of legs....
Golf equipment and bikes have been hard to fit me.
I can fit on a frame that is 52cm and the balls of my feet just touch the ground..... however, when I ride, the length of the bike feels too short.
Can I buy a few extra-long handlebar stems, or a few seat post that allows the seats to go way, way back?
thx...
Golf equipment and bikes have been hard to fit me.
I can fit on a frame that is 52cm and the balls of my feet just touch the ground..... however, when I ride, the length of the bike feels too short.
Can I buy a few extra-long handlebar stems, or a few seat post that allows the seats to go way, way back?
thx...
#12
Drip, Drip.
Join Date: Oct 2020
Location: Southern Ontario
Posts: 1,574
Bikes: Trek Verve E bike, Felt Doctrine 4 XC, Opus Horizon Apex 1
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 1032 Post(s)
Liked 190 Times
in
160 Posts
Let's Discuss Frame Geometry
(Trollol "The Grand Master of Trolling estabilishing his effortless skill" Trollololol
(Trollol "The Grand Master of Trolling estabilishing his effortless skill" Trollololol
Sliding the saddle back or forth has nothing to do with the reach, which is considered based on optimal weight distribution whilst pedalling out of the saddle. Provided that the ETT is a sufficient length according to the optimal seating position within the frame for comfort and power transfer, you can then make some adjustments using the saddle rails as necessary. But that would never work to compensate for an ill fitting frame.
Last edited by Moisture; 12-04-20 at 08:26 PM.
#13
Sunshine
Join Date: Aug 2014
Location: Des Moines, IA
Posts: 15,100
Bikes: '18 class built steel roadbike, '19 Fairlight Secan, '88 Schwinn Premis , Black Mountain Cycles Monstercross V4, '89 Novara Trionfo
Mentioned: 120 Post(s)
Tagged: 0 Thread(s)
Quoted: 9425 Post(s)
Liked 5,785 Times
in
3,347 Posts
#14
Senior Member
Join Date: Apr 2012
Location: Nor Cal
Posts: 6,016
Mentioned: 17 Post(s)
Tagged: 0 Thread(s)
Quoted: 1814 Post(s)
Likes: 0
Liked 919 Times
in
567 Posts
I was born with a very long torso and a very short pair of legs....
Golf equipment and bikes have been hard to fit me.
I can fit on a frame that is 52cm and the balls of my feet just touch the ground..... however, when I ride, the length of the bike feels too short.
Can I buy a few extra-long handlebar stems, or a few seat post that allows the seats to go way, way back?
thx...
Golf equipment and bikes have been hard to fit me.
I can fit on a frame that is 52cm and the balls of my feet just touch the ground..... however, when I ride, the length of the bike feels too short.
Can I buy a few extra-long handlebar stems, or a few seat post that allows the seats to go way, way back?
thx...
So you're saying that a 52cm frame is too small? Try a larger size. How your feet touch the ground has next to nothing to do with bike fit. I also have a long torso & short-ish legs, so end up with more saddle set-back, but also short-ish arms so not a long stem.
I don't know much about golf, but don't you basically need clubs that reach from your hands to the ground?
Also, it's likely that your body proportions developed much later than when you were born. (sorry for the nit-pick)
#15
Happy banana slug
Join Date: Sep 2015
Location: Arcata, California, U.S., North America, Earth, Saggitarius Arm, Milky Way
Posts: 3,181
Bikes: 1984 Araya MB 261, 1992 Specialized Rockhopper Sport, 1993 Hard Rock Ultra, 1994 Trek Multitrack 750, 1995 Trek Singletrack 930
Mentioned: 27 Post(s)
Tagged: 0 Thread(s)
Quoted: 1254 Post(s)
Liked 1,075 Times
in
664 Posts
Sounds perfect for a '90s mountain bike build, with their 26" wheels and stoopid long top tubes.

#16
Full Member
Your leg should be almost fully extended when your foot is on the PEDAL at its lowest position not the ground.
Likes For Biketiger:
#17
Senior Member
Join Date: Oct 2008
Location: Portland, OR
Posts: 3,383
Bikes: Soma Fog Cutter, Volae Team, Focus Mares AL, Nimbus MUni, Trek Roscoe 6, 1987 Centurion SS/FG.
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 690 Post(s)
Liked 1,572 Times
in
806 Posts
French fit on a frame that already has long reach should get you a long way. You can add a long stem if needed.
If that's not enough, do the above on a sloping top tube bike. Technically you don't even have to be able to stand over the frame, but most people consider that necessary. With a sloping top tube, you can stand over a relatively huge frame.
Of course you can get a custom frame if that's in your budget, but the above can work with an off-the-shelf bike.
If that's not enough, do the above on a sloping top tube bike. Technically you don't even have to be able to stand over the frame, but most people consider that necessary. With a sloping top tube, you can stand over a relatively huge frame.
Of course you can get a custom frame if that's in your budget, but the above can work with an off-the-shelf bike.
#18
Advanced Slacker
Join Date: Feb 2017
Posts: 5,820
Bikes: Soma Fog Cutter, Surly Wednesday, Canfielld Tilt
Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 2590 Post(s)
Liked 2,290 Times
in
1,294 Posts
#19
Over forty victim of Fate
I'm (well was in my youth) 5' 8-1/2" with a 29.5" inseam, 18" neck, 34-1/2" sleeve. Yep, I'm built like a short-legged gorilla.
BITD when I was 15 or so, based on my stand-over height, they tried to fit me to a 21" (53.4cm) frame on a traditional 10-speed road bike of the era (1974). I rode it around the block, but was too cramped fore-aft, so I test rode the 23" (58cm) frame and felt that the riding position was much better, even though 'the boys' are somewhat compressed if I stand over the bike flat-footed. Against their better judgement, I have been happily been riding 57/cm/23" frames ever since.
When I'm out riding, I NEVER have put both feet on the ground at the same time at a stop. Also, I've NEVER crushed the boys. 46 years of riding a 'too-tall' frame.
Because of this thread, I just went out and actually measured my trusty old Fuji for the first time ever... 23" c-c from seatube to headtube. 21" from nose of the saddle to the back edge of the bars. (I NEVER ride on the hoods - preferring my hand placement with my palms on the 'shoulders' of the bars where they start to turn forward, or in the drops.

My other bikes are fitted the same. seat height from BB center, and nose of saddle-to-bars. 170mm cranks on all.

The stem on the Miyata is longer to compensate for the slightly smaller 57cm frame...
Just about everyone's fit will likely be different than mine!
.
BITD when I was 15 or so, based on my stand-over height, they tried to fit me to a 21" (53.4cm) frame on a traditional 10-speed road bike of the era (1974). I rode it around the block, but was too cramped fore-aft, so I test rode the 23" (58cm) frame and felt that the riding position was much better, even though 'the boys' are somewhat compressed if I stand over the bike flat-footed. Against their better judgement, I have been happily been riding 57/cm/23" frames ever since.
When I'm out riding, I NEVER have put both feet on the ground at the same time at a stop. Also, I've NEVER crushed the boys. 46 years of riding a 'too-tall' frame.
Because of this thread, I just went out and actually measured my trusty old Fuji for the first time ever... 23" c-c from seatube to headtube. 21" from nose of the saddle to the back edge of the bars. (I NEVER ride on the hoods - preferring my hand placement with my palms on the 'shoulders' of the bars where they start to turn forward, or in the drops.

My other bikes are fitted the same. seat height from BB center, and nose of saddle-to-bars. 170mm cranks on all.

The stem on the Miyata is longer to compensate for the slightly smaller 57cm frame...
Just about everyone's fit will likely be different than mine!
.
__________________
'75 Fuji S-10S bought new, 52k+ miles and still going!
'84 Univega Gran Tourismo
'84 Univega Viva Sport
'86 Miyata 710
'90 Schwinn Woodlands
Unknown brand MTB of questionable lineage aka 'Mutt Trail Bike'
Plus or minus a few others from time-to-time
'75 Fuji S-10S bought new, 52k+ miles and still going!
'84 Univega Gran Tourismo
'84 Univega Viva Sport
'86 Miyata 710
'90 Schwinn Woodlands
Unknown brand MTB of questionable lineage aka 'Mutt Trail Bike'
Plus or minus a few others from time-to-time
#20
Advanced Slacker
Join Date: Feb 2017
Posts: 5,820
Bikes: Soma Fog Cutter, Surly Wednesday, Canfielld Tilt
Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 2590 Post(s)
Liked 2,290 Times
in
1,294 Posts
#21
Happy banana slug
Join Date: Sep 2015
Location: Arcata, California, U.S., North America, Earth, Saggitarius Arm, Milky Way
Posts: 3,181
Bikes: 1984 Araya MB 261, 1992 Specialized Rockhopper Sport, 1993 Hard Rock Ultra, 1994 Trek Multitrack 750, 1995 Trek Singletrack 930
Mentioned: 27 Post(s)
Tagged: 0 Thread(s)
Quoted: 1254 Post(s)
Liked 1,075 Times
in
664 Posts
#22
Over forty victim of Fate
It is VERY battle-scarred after 45 years/54k+ miles of abuse I'd guess closer to 60k miles these days, but no old-school clicker' odometer any more! LOL!

Original components:
Frame/fork
Stem/Bars
Brakes/levers
Saddle
Everything else has been replaced at least once!
.
__________________
'75 Fuji S-10S bought new, 52k+ miles and still going!
'84 Univega Gran Tourismo
'84 Univega Viva Sport
'86 Miyata 710
'90 Schwinn Woodlands
Unknown brand MTB of questionable lineage aka 'Mutt Trail Bike'
Plus or minus a few others from time-to-time
'75 Fuji S-10S bought new, 52k+ miles and still going!
'84 Univega Gran Tourismo
'84 Univega Viva Sport
'86 Miyata 710
'90 Schwinn Woodlands
Unknown brand MTB of questionable lineage aka 'Mutt Trail Bike'
Plus or minus a few others from time-to-time
#23
Newbie racer
Join Date: Feb 2018
Posts: 3,373
Bikes: Propel, red is faster
Mentioned: 34 Post(s)
Tagged: 0 Thread(s)
Quoted: 1566 Post(s)
Liked 1,533 Times
in
953 Posts
Shorter legs? Maybe could gain some millimeters at least with short cranks. Most places make them these days down to 165mm in readily purchasable stock.
That doesn't resolve all of that, just one place to look.
That doesn't resolve all of that, just one place to look.
#24
Zip tie Karen
Join Date: Aug 2009
Location: Fair Oaks Ranch, TX
Posts: 7,005
Bikes: '13 Motobecane Fantom29 HT, '16 Motobecane Turino Pro Disc, '16 Motobecane Gran Premio Elite, '18 Velobuild VB-R-022, '21 Tsunami SNM-100
Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 1464 Post(s)
Liked 1,537 Times
in
804 Posts
Apparently "Tawk" is a trademarked name for some kind of chat application. Who knew that?
I'm also a long torso with average leg length. Longer top tubes can help. With compact geometries and threadless stems, it's a lot easier to experiment and find the right fit.
I'm also a long torso with average leg length. Longer top tubes can help. With compact geometries and threadless stems, it's a lot easier to experiment and find the right fit.
