A "spongy" feeling

Notices
General Cycling Discussion Have a cycling related question or comment that doesn't fit in one of the other specialty forums? Drop on in and post in here! When possible, please select the forum above that most fits your post!

A "spongy" feeling

Old 12-12-20, 06:59 AM
  #1
taylorgeo
Senior Member
Thread Starter

Join Date: Jul 2020
Posts: 128
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 86 Post(s)
Liked 20 Times in 15 Posts
A "spongy" feeling

As I wear down the pads on my linear pull brakes, the levers are getting closer and closer to the grips when I brake. I'm getting a sorta "spongy" feeling.

What adjustments should I be making to get the brakes firmer with less brake lever travel?
taylorgeo is offline
Old 12-12-20, 08:59 AM
  #2
Wileyrat
Senior Member

Join Date: Mar 2013
Location: Tucson Az
Posts: 1,613

Bikes: 2015 Ridley Fenix, 1983 Team Fuji, 2019 Marin Nail Trail 6, and a few dust collectors

Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 321 Post(s)
Liked 167 Times in 110 Posts
Personally, I hate a lot of lever pull in my brakes. If it was my bike, I'd replace the pads and adjust the cables. If you don't want to do that, you can use the barrel adjuster to pull some cable slack out, or just tighten up the cables.
Wileyrat is offline
Likes For Wileyrat:
Old 12-12-20, 09:52 AM
  #3
cxwrench
Senior Member

cxwrench's Avatar

Join Date: Jul 2013
Location: Nor-Cal
Posts: 1,390

Bikes: lots

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 589 Post(s)
Liked 678 Times in 390 Posts
You'll also have to adjust the pad position as it hits the rim. I definitely prefer a bunch of lever pull before the pads hit the rim. I have much better control this way. Having the brakes 'tight' so they actuate with very little lever pull is NOT the right way to do it. I get personal preference but more control is better than less. You should adjust lever pull and pad height fairly often w/ V brakes, the pads will get a helical wear pattern if you don't keep on top of it, this will make it very hard to adjust (unless you have XT or XTR brakes w/ the linkage).
cxwrench is offline
Likes For cxwrench:
Old 12-12-20, 04:17 PM
  #4
taylorgeo
Senior Member
Thread Starter

Join Date: Jul 2020
Posts: 128
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 86 Post(s)
Liked 20 Times in 15 Posts
Originally Posted by Wileyrat View Post
Personally, I hate a lot of lever pull in my brakes. If it was my bike, I'd replace the pads and adjust the cables. If you don't want to do that, you can use the barrel adjuster to pull some cable slack out, or just tighten up the cables.
Tighten up the cables at the pinch bolt, correct? I should take a pic of the pads, cause I'm not even sure just how worn they are. Is it possible to get more lever pull over time without the pads being drastically worn?

Originally Posted by cxwrench View Post
Having the brakes 'tight' so they actuate with very little lever pull is NOT the right way to do it. I get personal preference but more control is better than less.
Now that makes a lot sense. Thank you!
taylorgeo is offline
Old 12-12-20, 07:28 PM
  #5
katsup
Senior Member

katsup's Avatar

Join Date: May 2016
Location: Southern California
Posts: 1,444

Bikes: 2021 Polygon Siskiu T8, Soma Fog Cutter and Vintage Mountain Bikes

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 491 Post(s)
Liked 335 Times in 195 Posts
Originally Posted by taylorgeo View Post
Tighten up the cables at the pinch bolt, correct? I should take a pic of the pads, cause I'm not even sure just how worn they are. Is it possible to get more lever pull over time without the pads being drastically worn?
Turn the barrel adjuster at the end of the brake lever (where the cable exits). You should be turning it counter clockwise, then lock it in place with the washer.

Once you have the lever where you want, make sure the brake pads still fully contact the rim.
katsup is offline
Old 12-12-20, 08:06 PM
  #6
Mojo31
...

Join Date: Jul 2020
Posts: 1,761
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1452 Post(s)
Liked 946 Times in 519 Posts
Originally Posted by taylorgeo View Post
Tighten up the cables at the pinch bolt, correct? I should take a pic of the pads, cause I'm not even sure just how worn they are. Is it possible to get more lever pull over time without the pads being drastically worn?



Now that makes a lot sense. Thank you!
Cables do stretch.
Mojo31 is offline
Old 12-12-20, 08:35 PM
  #7
cxwrench
Senior Member

cxwrench's Avatar

Join Date: Jul 2013
Location: Nor-Cal
Posts: 1,390

Bikes: lots

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 589 Post(s)
Liked 678 Times in 390 Posts
Originally Posted by Mojo31 View Post
Cables do stretch.
No...they don't.
cxwrench is offline
Old 12-12-20, 08:39 PM
  #8
Gresp15C
Senior Member

Gresp15C's Avatar

Join Date: Sep 2014
Posts: 3,544
Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 937 Post(s)
Liked 459 Times in 308 Posts
Also take a close look at the pads. When they're really worn, they can develop a "lip" that hooks over the edge of the rim. You can sometimes get a bit more life out of pads by sanding the lip off.
Gresp15C is offline
Old 12-12-20, 09:00 PM
  #9
Skulking
Senior Member

Join Date: Aug 2020
Posts: 72
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 99 Times in 37 Posts
Originally Posted by cxwrench View Post
No...they don't.
Skulking is offline
Old 12-12-20, 09:00 PM
  #10
Mojo31
...

Join Date: Jul 2020
Posts: 1,761
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1452 Post(s)
Liked 946 Times in 519 Posts
Originally Posted by cxwrench View Post
No...they don't.
Others seem to disagree with you.

https://bicycleuniverse.com/bike-brake-cables-stretch/

https://www.velofix.com/company/news...cable-stretch/

https://cyclingmagazine.ca/sections/...g-and-braking/
Mojo31 is offline
Old 12-12-20, 09:18 PM
  #11
cxwrench
Senior Member

cxwrench's Avatar

Join Date: Jul 2013
Location: Nor-Cal
Posts: 1,390

Bikes: lots

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 589 Post(s)
Liked 678 Times in 390 Posts
Bicycle Universe? Here's what they said:
"The cables have a natural elasticity being metal and will stretch slightly. This is minuscule and you possibly won’t notice this, but only pick up on a change in your brakes. This could mean it’s time to replace the cables and get a fine-tuning."
Uhhhm...no. They said it's 'microscopic' and then go on to make it sound like they are always stretching. This is just not true. Brake housing compresses a TON when new, and is then stable. If the cable did actually stretch you wouldn't notice. Brake flex, pad squish(again, microsopic) would be more noticeable than 'stretch'. You just don't put enough leverage into a brake to end up stretching the cable.

Velofix? They can't even get their descriptions of cables and their sizes right. They're not braided, they're twisted. Brake cables are 1.6mm not 1.5mm. They do however get it right in the middle, I guess you didn't read that part:
"“Cable stretch” is actually a broader term used to describe the action of the WHOLE cabling system settling into place. Your brake and shift cables pass through your brake and shift housing-the other key components in the WHOLE cabling system. When housing is cut and capped with ferules, it may not be fully seated into those ferrules, or fully seated into the frame stops, derailleur, brakes, shifters etc. As you shift and brake, a huge portion of the initial settling that occurs is actually the housing fully seating itself into place. Once settled, you can be left with a considerable amount of slack, causing the symptoms above."

Cycling magazine? Do you actually believe them just because they're a 'cycling magazine'? I've met a ton of magazine 'experts' over the years, mostly during my years as a pro team mechanic. It is stunning how clueless many of them are...absolutely stunning. I've offered my opinion, you can go with whatever you want.
cxwrench is offline
Likes For cxwrench:
Old 12-12-20, 10:01 PM
  #12
Mojo31
...

Join Date: Jul 2020
Posts: 1,761
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1452 Post(s)
Liked 946 Times in 519 Posts
How about something from the industry:

The stretch of a wire rope under load is the result of two components: the structural stretch and the elastic stretch. Structural stretch of wire rope is caused by the lengthening of the rope lay, compression of the core and adjustment of the wires and strands to the load placed upon the wire rope. The elastic stretch is caused by elongation of the wires.

https://bergencable.com/cable-101

Bike cables are wire rope. Elongation due to care compression is “stretch” in layman’s terms. Lots of other sources in the cable and engineering industries disagree with your unequivocal statement.

Last edited by Mojo31; 12-12-20 at 10:38 PM.
Mojo31 is offline
Likes For Mojo31:
Old 12-13-20, 08:01 AM
  #13
Cougrrcj
Over forty victim of Fate

Cougrrcj's Avatar

Join Date: Jul 2011
Location: NE Ohio
Posts: 3,647

Bikes: A few...

Mentioned: 16 Post(s)
Tagged: 0 Thread(s)
Quoted: 521 Post(s)
Liked 249 Times in 171 Posts
The brakes on my '84 Univega Viva sport had that 'spongy' feel, even after I put on new cables when I converted aero brake levers... I looked at what the cause was, and I could actually see the DiaCompe G400 brake arm bending a bit. A set of Tektro dual-pivot brakes solved that issue...

Other causes of 'soft' or spongy brakes:
  • Cable housing ends not cut square
  • not using proper ferrules at housing ends
  • Cheap housing that has some degree of compressing
  • cheap inner cable that allows some degree of stretch
  • Old, hard brake pads - you gotta squeeze harder to get braking effect.

.
__________________
'75 Fuji S-10S bought new, 52k+ miles and still going!
'84 Univega Gran Tourismo
'84 Univega Viva Sport
'86 Miyata 710
'90 Schwinn Woodlands
Unknown brand MTB of questionable lineage aka 'Mutt Trail Bike'
Plus or minus a few others from time-to-time

Cougrrcj is offline
Old 12-13-20, 08:32 AM
  #14
taylorgeo
Senior Member
Thread Starter

Join Date: Jul 2020
Posts: 128
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 86 Post(s)
Liked 20 Times in 15 Posts
Originally Posted by Cougrrcj View Post
The brakes on my '84 Univega Viva sport had that 'spongy' feel, even after I put on new cables when I converted aero brake levers... I looked at what the cause was, and I could actually see the DiaCompe G400 brake arm bending a bit. A set of Tektro dual-pivot brakes solved that issue...

Other causes of 'soft' or spongy brakes:
  • Cable housing ends not cut square
  • not using proper ferrules at housing ends
  • Cheap housing that has some degree of compressing
  • cheap inner cable that allows some degree of stretch
  • Old, hard brake pads - you gotta squeeze harder to get braking effect.

.
Thanks for the info... Would the Tektro dual-pivot brakes fit on my bike? Tire width is 2.00"... Wouldn't mind more stopping power (and less ride-to-ride tweaking) considering I'm a super Clyde.


taylorgeo is offline
Old 12-13-20, 09:04 AM
  #15
ARider2
Senior Member

Join Date: Dec 2009
Posts: 445
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 44 Post(s)
Liked 60 Times in 45 Posts
You mentioned your brakes feel "spongy". If your cables and housing are old the first thing I would do is replace them. I find this can change the feel from spongy to firm. If your brake pads are old they may be hardened or glazed and replacement will also improve your braking. If pads are glazed you can file down the shiny part until you get to good material. If you decide to replace the entire brake set it will generally include new pads.
ARider2 is offline
Old 12-13-20, 09:23 AM
  #16
Wilfred Laurier
Señor Member

Wilfred Laurier's Avatar

Join Date: Feb 2013
Posts: 5,050
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 633 Post(s)
Liked 276 Times in 201 Posts
If the pads are worn so much that the rubber accordian boot is compressing that will give it a spongy feeling.

Direct pull brakes have two different widths of washers and you can flip these from one side of the brake arm to the other to adjust the angle of the arms. If the arms are pointed significantly inward at the top then you should consider swapping washers so the thicker set is on the inside..
Wilfred Laurier is offline
Old 12-13-20, 09:49 AM
  #17
dedhed
SE Wis

dedhed's Avatar

Join Date: Apr 2005
Location: Milwaukee, WI
Posts: 7,471

Bikes: '68 Raleigh Sprite, '02 Raleigh C500, '84 Raleigh Gran Prix, '91 Trek 400, 2013 Novara Randonee, 1990 Trek 970

Mentioned: 27 Post(s)
Tagged: 0 Thread(s)
Quoted: 1535 Post(s)
Liked 1,048 Times in 719 Posts
Originally Posted by taylorgeo View Post
Thanks for the info... Would the Tektro dual-pivot brakes fit on my bike? Tire width is 2.00"... Wouldn't mind more stopping power (and less ride-to-ride tweaking) considering I'm a super Clyde.
Short answer - No.
Different kind of brakes, reach issues, opening issues, lever pull issues. My opinion is V brakes stop as well if not better than dual pivot calipers so you wouldn't gain anything anyway.
dedhed is offline
Old 12-13-20, 10:03 AM
  #18
RGMN
Senior Member

Join Date: Feb 2018
Location: Western 'burbs of TC,MN
Posts: 397
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 181 Post(s)
Liked 116 Times in 82 Posts
Originally Posted by cxwrench View Post
No...they don't.
NEVER argue with cxwrench. He is ALWAYS right. (That's why I have him on my ignore list.)
RGMN is offline
Old 12-13-20, 10:16 AM
  #19
Mojo31
...

Join Date: Jul 2020
Posts: 1,761
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1452 Post(s)
Liked 946 Times in 519 Posts
Originally Posted by RGMN View Post
NEVER argue with cxwrench. He is ALWAYS right. (That's why I have him on my ignore list.)
But, he was a mechanic for a pro race team! Don’t they require degrees in metallurgy and mechanical engineering for those career positions?

Mojo31 is offline
Old 12-13-20, 04:54 PM
  #20
veganbikes
Clark W. Griswold

Join Date: Mar 2014
Location: ,location, location
Posts: 8,073

Bikes: Foundry Chilkoot Ti W/Ultegra Di2, Salsa Timberjack Ti, Cinelli Mash Work RandoCross Fun Time Machine, 1x9 XT Parts Hybrid, Co-Motion Cascadia, Specialized Langster, Phil Wood Apple VeloXS Frame (w/DA 7400), Cilo Road Frame, Proteus frame, Ti 26 MTB

Mentioned: 36 Post(s)
Tagged: 0 Thread(s)
Quoted: 2150 Post(s)
Liked 1,091 Times in 763 Posts
I would replace cables, housing and potentially brake shoes and pads. For cables and housing I want something compressionless for braking. Jagwire I think makes some of the finest cables and housing and their pro and Elite level kits are well worth it. For my shoes, I want a nice stiff shoe that has a replaceable pad, no solid rubber pads, replaceable stuff can end up cheaper in the long run. For my pads I want a really nice high end compound that is good for my riding and generally from someone with Stop in the name like Kool Stop or SwissStop. Those little changes can make a massive difference in your braking and don't cost a lot compared to upgrading the actual calipers or levers or something like that. Refresh your ride and you will be quite happy.

Of course also make sure your pads are installed properly so they hit the rim right.
veganbikes is offline
