Hanging a disc road bike?

Road Cycling “It is by riding a bicycle that you learn the contours of a country best, since you have to sweat up the hills and coast down them. Thus you remember them as they actually are, while in a motor car only a high hill impresses you, and you have no such accurate remembrance of country you have driven through as you gain by riding a bicycle.” -- Ernest Hemingway

Hanging a disc road bike?

Old 06-04-19, 06:50 AM
  #1
Lrdchaos
Senior Member
Thread Starter

Join Date: Feb 2017
Posts: 112
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 45 Post(s)
Likes: 0
Liked 6 Times in 5 Posts
Hanging a disc road bike?

My rim brake, alloy wheeled road bike would always hang upside down by the front and rear wheels feom
the ceiling. With the new hydraulic disc and carbon wheels, what is the best way to store the bike?
Lrdchaos is offline
Old 06-04-19, 07:37 AM
  #2
PepeM
Senior Member

PepeM's Avatar

Join Date: Apr 2015
Posts: 6,718
Mentioned: 179 Post(s)
Tagged: 1 Thread(s)
Quoted: 2612 Post(s)
Likes: 0
Liked 51 Times in 22 Posts
PepeM is offline
Old 06-04-19, 07:48 AM
  #3
MoAlpha
• —

MoAlpha's Avatar

Join Date: Jun 2015
Location: Land of Pleasant Living
Posts: 2,388

Bikes: Occasionally

Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 1348 Post(s)
Liked 57 Times in 42 Posts
Seems like a good way to get air in the brake lines.
MoAlpha is online now
Old 06-04-19, 07:56 AM
  #4
DrIsotope
Non omnino gravis

DrIsotope's Avatar

Join Date: Feb 2015
Location: SoCal, USA!
Posts: 6,739

Bikes: Nekobasu, Pandicorn

Mentioned: 99 Post(s)
Tagged: 0 Thread(s)
Quoted: 3588 Post(s)
Liked 154 Times in 115 Posts
__________________
DrIsotope is offline
Old 06-04-19, 08:00 AM
  #5
MoAlpha
• —

MoAlpha's Avatar

Join Date: Jun 2015
Location: Land of Pleasant Living
Posts: 2,388

Bikes: Occasionally

Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 1348 Post(s)
Liked 57 Times in 42 Posts
Originally Posted by DrIsotope View Post
Or move to the Southern Hemisphere, whichever's easiest.
MoAlpha is online now
Likes For MoAlpha:
Old 06-04-19, 08:03 AM
  #6
DrIsotope
Non omnino gravis

DrIsotope's Avatar

Join Date: Feb 2015
Location: SoCal, USA!
Posts: 6,739

Bikes: Nekobasu, Pandicorn

Mentioned: 99 Post(s)
Tagged: 0 Thread(s)
Quoted: 3588 Post(s)
Liked 154 Times in 115 Posts
Yeah, if you opt for down undah', I always just assumed there would be a huge spiderweb capable of holding up the bike, or maybe some cooperative serpents.

I just rotate our bikes around, so there's never a need for the hydro bike to be hung upside-down.
__________________
DrIsotope is offline
Old 06-04-19, 08:06 AM
  #7
Zaskar
Senior Member

Join Date: Sep 2008
Posts: 331
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 182 Post(s)
Liked 3 Times in 3 Posts
Some will say it'll be fine upside down. And, some bikes will be fine like that. I've had mtn bikes (disc) breaks leak at the MC and leave a puddle when hung upside-down. Now, all of my bikes hang by the front wheel - two of which are disc. They've been fine this way.

Zaskar is offline
Old 06-04-19, 08:07 AM
  #8
WhyFi
Senior Member

WhyFi's Avatar

Join Date: Jan 2010
Location: Got a castle in - er, Minneapolis, that's where I dwell!
Posts: 24,842

Bikes: 2016 Diamondback Haanjo, 2018 Trek Domane SL5 Gravel

Mentioned: 298 Post(s)
Tagged: 1 Thread(s)
Quoted: 8884 Post(s)
Liked 135 Times in 81 Posts
You don't want to hang hydros upside down. I assume that the issue is air in the reservoir making its way in to the line. I don't remember why, but I had to orient my bike somewhat upside down for a short time; I had to pump the brakes for a minute or two to get them to work afterwards. If upside down for longer and a bubble made it someplace where it might "stick" when upright (past a bend in the BB area or maybe a nook or cranny in the caliper itself), it could be a pain in the ass.
WhyFi is offline
Old 06-04-19, 08:11 AM
  #9
OUGrad05
Senior Member

Join Date: Jun 2017
Posts: 180
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 100 Post(s)
Liked 5 Times in 5 Posts
Originally Posted by WhyFi View Post
You don't want to hang hydros upside down. I assume that the issue is air in the reservoir making its way in to the line. I don't remember why, but I had to orient my bike somewhat upside down for a short time; I had to pump the brakes for a minute or two to get them to work afterwards. If upside down for longer and a bubble made it someplace where it might "stick" when upright (past a bend in the BB area or maybe a nook or cranny in the caliper itself), it could be a pain in the ass.
My hydro mtn bike has been hanging upside down for 7 years, no issues, sometimes for extended periods of time. That's interesting that you had a brake issue, not sure it was related but maybe it was? You could hang them against the wall like one of the other posters was doing.
OUGrad05 is offline
Old 06-04-19, 08:13 AM
  #10
WhyFi
Senior Member

WhyFi's Avatar

Join Date: Jan 2010
Location: Got a castle in - er, Minneapolis, that's where I dwell!
Posts: 24,842

Bikes: 2016 Diamondback Haanjo, 2018 Trek Domane SL5 Gravel

Mentioned: 298 Post(s)
Tagged: 1 Thread(s)
Quoted: 8884 Post(s)
Liked 135 Times in 81 Posts
Originally Posted by OUGrad05 View Post
My hydro mtn bike has been hanging upside down for 7 years, no issues, sometimes for extended periods of time. That's interesting that you had a brake issue, not sure it was related but maybe it was? You could hang them against the wall like one of the other posters was doing.
Probably the position of the reservoir given the different ergonomics. FWIW, Shimano explicitly states that road hydro bikes shouldn't be put upside down.

edit:

The disc brake is not designed to work with the bicycle upside down. If the bicycle is turned upside down or on its side, the brake may not work correctly
I haven't had any issues whatsoever transporting my bikes on their sides, though, even with 1500+ mile road trips.

Last edited by WhyFi; 06-04-19 at 08:16 AM.
WhyFi is offline
Old 06-04-19, 08:14 AM
  #11
OUGrad05
Senior Member

Join Date: Jun 2017
Posts: 180
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 100 Post(s)
Liked 5 Times in 5 Posts
Originally Posted by WhyFi View Post
Probably the position of the reservoir given the different ergonomics. FWIW, Shimano explicitly states that road hydro bikes shouldn't be put upside down.
Well damn, I had no clue, glad I read this thread. I don't yet have a hydro road bike but one is in my future.
OUGrad05 is offline
Old 06-04-19, 09:46 AM
  #12
Zaskar
Senior Member

Join Date: Sep 2008
Posts: 331
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 182 Post(s)
Liked 3 Times in 3 Posts
Both mtn bikes that leaked when upside-down had Shimano brakes
Zaskar is offline
Old 06-04-19, 09:56 AM
  #13
cthenn
Senior Member

Join Date: Jan 2010
Location: Walnut Creek, CA
Posts: 2,410

Bikes: 2015 Trek Emonda SLR, 2002 Litespeed Classic, 2005 Bianchi Pista, 2016 Devinci Hatchet, Some BikesDirect MTB I never ride.

Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 536 Post(s)
Liked 39 Times in 21 Posts
Hang it by one of the tiny holes in the disc rotor
cthenn is offline
Old 06-04-19, 10:05 AM
  #14
jackb
Senior Member

Join Date: Apr 2005
Location: Billings, Montana
Posts: 481

Bikes: Trek Domane 5SL Disc; REI Mazama; Specialized Langster

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 52 Post(s)
Likes: 0
Liked 4 Times in 2 Posts
I don't see how air can "work its way" into the brakeline if it is a sealed system. In order for air to get in, there would have to be a leak, in which case fluid would leak out. My wife hangs her bike upside down with no problem.
jackb is offline
Old 06-04-19, 10:06 AM
  #15
superdex
staring at the mountains

superdex's Avatar

Join Date: Mar 2005
Location: Parker, CO
Posts: 4,280

Bikes: Fairdale Goodship, Spesh Crux

Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 277 Post(s)
Liked 19 Times in 15 Posts
Your posts:bikes ratio is way too low.

Originally Posted by Zaskar View Post
Some will say it'll be fine upside down. And, some bikes will be fine like that. I've had mtn bikes (disc) breaks leak at the MC and leave a puddle when hung upside-down. Now, all of my bikes hang by the front wheel - two of which are disc. They've been fine this way.

superdex is offline
Old 06-04-19, 10:51 AM
  #16
WhyFi
Senior Member

WhyFi's Avatar

Join Date: Jan 2010
Location: Got a castle in - er, Minneapolis, that's where I dwell!
Posts: 24,842

Bikes: 2016 Diamondback Haanjo, 2018 Trek Domane SL5 Gravel

Mentioned: 298 Post(s)
Tagged: 1 Thread(s)
Quoted: 8884 Post(s)
Liked 135 Times in 81 Posts
Originally Posted by jackb View Post
I don't see how air can "work its way" into the brakeline if it is a sealed system. In order for air to get in, there would have to be a leak, in which case fluid would leak out. My wife hangs her bike upside down with no problem.
So you're under the impression that reservoirs are always perfectly tippy-topped-off with fluid and that there's no air anywhere inside the system?

Okay, cool.
WhyFi is offline
Likes For WhyFi:
Old 06-04-19, 11:01 AM
  #17
Zaskar
Senior Member

Join Date: Sep 2008
Posts: 331
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 182 Post(s)
Liked 3 Times in 3 Posts
Originally Posted by jackb View Post
I don't see how air can "work its way" into the brakeline if it is a sealed system. In order for air to get in, there would have to be a leak, in which case fluid would leak out. My wife hangs her bike upside down with no problem.
As I said way up ^there^, some bikes do just fine hanging... and some don't. That your wife's is fine in bat-mode, doesn't negate the fact that others leak, drip, get spongey... Maybe it's a Shimano (mine are and they protested) vs SRAM thing.
Zaskar is offline
Old 06-04-19, 11:51 AM
  #18
WhyFi
Senior Member

WhyFi's Avatar

Join Date: Jan 2010
Location: Got a castle in - er, Minneapolis, that's where I dwell!
Posts: 24,842

Bikes: 2016 Diamondback Haanjo, 2018 Trek Domane SL5 Gravel

Mentioned: 298 Post(s)
Tagged: 1 Thread(s)
Quoted: 8884 Post(s)
Liked 135 Times in 81 Posts
Originally Posted by Zaskar View Post
As I said way up ^there^, some bikes do just fine hanging... and some don't. That your wife's is fine in bat-mode, doesn't negate the fact that others leak, drip, get spongey... Maybe it's a Shimano (mine are and they protested) vs SRAM thing.
Thinking about it a little bit, I wouldn't be surprised if some systems have air in the reservoir by design, rather than by accident. There's (at least) two things to consider: fluid expansion/contraction with temp changes and pressure behind the piston when braking.

Expansion/contraction is pretty self-explanatory - if the volume changes, you need to address it somehow. Having a bladder, the back side of which would be open to atmosphere, would do that, but so would bubble of air in the reservoir that can expand/compress.

Pressure behind the piston is an obvious problem too, when you think about it. Once you're braking and the piston cuts off the reservoir from the rest of the system, you'll essentially have two sealed systems - one in front of the piston and one behind. In front of the piston, the pressure increases and the calipers push out, squeezing the disc, obviously. What about behind the piston, though? If that sealed mini-system were rigid and completely filled with fluid, the lever wouldn't move because that fluid wouldn't be able to meaningfully expand. Again, a bladder would address this, and I think that they do this on some MTB systems, but I don't know that they do it on road systems; it would certainly be more complex and costly than leaving an air pocket in the reservoir, though, and the only downside is that you have to tell people not to turn their bikes upside-down.
WhyFi is offline
Old 06-04-19, 12:49 PM
  #19
rumrunn6
Senior Member

rumrunn6's Avatar

Join Date: Jul 2008
Location: 25 miles northwest of Boston
Posts: 22,908

Bikes: Bottecchia Sprint, GT Timberline 29r

Mentioned: 87 Post(s)
Tagged: 0 Thread(s)
Quoted: 3029 Post(s)
Liked 112 Times in 91 Posts
2 hooks in the ceiling, maybe? just measure first to get the spacing correct





rumrunn6 is offline
Old 06-04-19, 01:08 PM
  #20
OUGrad05
Senior Member

Join Date: Jun 2017
Posts: 180
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 100 Post(s)
Liked 5 Times in 5 Posts
Originally Posted by Zaskar View Post
As I said way up ^there^, some bikes do just fine hanging... and some don't. That your wife's is fine in bat-mode, doesn't negate the fact that others leak, drip, get spongey... Maybe it's a Shimano (mine are and they protested) vs SRAM thing.
I reached out to a few friends this morning in light of this thread, they don't hang any of their hydraulic bikes upside down. Air in the reservoir can migrate when hanging.

I would assume hanging vertical against the wall as shown above is ok though? Looks like when I get an hydrualic road bike I'll need to find a different hanging arrangement.
OUGrad05 is offline
Old 06-04-19, 02:02 PM
  #21
Lrdchaos
Senior Member
Thread Starter

Join Date: Feb 2017
Posts: 112
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 45 Post(s)
Likes: 0
Liked 6 Times in 5 Posts
I appreciate the feedback. I have a steady rack for my mountain bike, I’ll buy another for my road bike.
Lrdchaos is offline
Old 06-04-19, 03:19 PM
  #22
velopig
Member

Join Date: Mar 2010
Posts: 37
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Likes: 0
Liked 10 Times in 5 Posts
I can speak from experience after flipping my Dura Ace Hydraulic bike upside down to facilitate a roadside repair a bubble worked its way into the rear braking system and I lost braking and needed to bleed the brakes once home. A thing similar happened to front brake after a flight and needed to find a bike shop to bleed brakes, luckily it was in a location with quality bike shops available to do the work.

It was when the bike was new and perhaps the reservoir was not completely full making the system more susceptible to the problem.
velopig is offline
Old 06-05-19, 08:56 AM
  #23
jackb
Senior Member

Join Date: Apr 2005
Location: Billings, Montana
Posts: 481

Bikes: Trek Domane 5SL Disc; REI Mazama; Specialized Langster

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 52 Post(s)
Likes: 0
Liked 4 Times in 2 Posts
Originally Posted by WhyFi View Post
So you're under the impression that reservoirs are always perfectly tippy-topped-off with fluid and that there's no air anywhere inside the system?

Okay, cool.
I didn't say that. If it is a sealed system, nothing can get in or out unless a leak develops. It there is no leak and air is in the line, it stays until bled out. If there is no air in the line, the line will remain airless unless a leak develops.

As for migrating air bubbles as someone suggested, why wouldn't these migrating bubbles migrate back to where they came from when the inverted bike is placed right side up?
jackb is offline
Old 06-05-19, 09:00 AM
  #24
DrIsotope
Non omnino gravis

DrIsotope's Avatar

Join Date: Feb 2015
Location: SoCal, USA!
Posts: 6,739

Bikes: Nekobasu, Pandicorn

Mentioned: 99 Post(s)
Tagged: 0 Thread(s)
Quoted: 3588 Post(s)
Liked 154 Times in 115 Posts
That would rely on a perfectly sealed system. The pistons move through seals, which is where contaminants get into the fluid. If the seal was absolutely perfect, the pistons couldn't move.

Imagine a typical internal combustion automobile engine. Properly maintained, sitting inside a car in the driveway, it doesn't leak oil, coolant, or fuel. Now turn it upside down.
__________________
DrIsotope is offline
Old 06-05-19, 09:10 AM
  #25
WhyFi
Senior Member

WhyFi's Avatar

Join Date: Jan 2010
Location: Got a castle in - er, Minneapolis, that's where I dwell!
Posts: 24,842

Bikes: 2016 Diamondback Haanjo, 2018 Trek Domane SL5 Gravel

Mentioned: 298 Post(s)
Tagged: 1 Thread(s)
Quoted: 8884 Post(s)
Liked 135 Times in 81 Posts
Originally Posted by jackb View Post
As for migrating air bubbles as someone suggested, why wouldn't these migrating bubbles migrate back to where they came from when the inverted bike is placed right side up?
I take it you've never bled a system. Brake lines don't always run downhill the entire length between the levers and calipers. Mineral oil is thicker than water. Bubbles stick and often need to be coerced. Until those bubbles are back on the other side of the piston, though, you could have some seriously compromised braking.

It's great that you/your wife haven't experienced any issues, but you're completely mistaken in thinking that it's a non-issue.
WhyFi is offline
