183rd Street Frameset (completed build; lots of big pictures)

Singlespeed & Fixed Gear "I still feel that variable gears are only for people over forty-five. Isn't it better to triumph by the strength of your muscles than by the artifice of a derailer? We are getting soft...As for me, give me a fixed gear!"-- Henri Desgrange (31 January 1865 - 16 August 1940)

183rd Street Frameset (completed build; lots of big pictures)

Reply

Old 07-22-09, 04:31 PM
  #1
00o00
ex DH/FR rider
Thread Starter

Join Date: May 2009
Posts: 20
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
183rd Street Frameset (completed build; lots of big pictures)

So I know some of you guys think its “hipster” to take pictures of your bike and post it, but I wanted to show off this particular frameset because it’s fairly new, and I love it!! It’s called 183rd street frame and fork. When I originally set out picking a frame there wasn’t very much information about this frameset; i.e. specs, pictures, etc. None the less here I am with the frameset, and I hope I can make it easier for the next person looking for a great frameset buy. It’s a full Chromoly welded track frameset, drilled for brakes and the frame has seat tube water bottle braze-ons. The frame price is in $300s, depending on where you get one. As I just finished the build I haven’t put very many miles on it (I have about 7 right now hahaha), but I can say that it rides great so far! The quality is perfect, I tried to nit-pick, but have yet to find anything wrong, its flawless.

Bike Build Components:
Velocity Deep V Rims
Formula Hubs
Surgio XD Cranks
Surgio Chain Ring (46t)
Surgio 103 bb
Brewtal cog (16t)
Shram PC-1 chain
MKS Sylvan pedals
Race Face Cadence Handlebars
Easton EA30 Stem
Cane Creek S-3 Headset

Frame Geo:
Size*|Top Tube C-C**|Head Angle|Seat Tube Angle|Chainstay Length|Standover|Headtube Length|BB Drop|Wheelbase
49cm| 515/515mm| 73.5°| 75.5°| 388mm|29.4"| 70mm| 58mm| 936mm
51cm| 525/525mm| 73.5°| 75.5°| 388mm|30.4"| 90mm| 58mm| 948mm
53cm| 536/535mm| 74° | 75.3°| 388mm|31.0"| 110mm| 58mm| 953mm
55cm| 551/550mm| 74.3°| 75.3°| 388mm|31.8"| 130mm| 58mm| 966mm
57cm| 561/560mm| 74.3°| 75.3°| 388mm|32.5"| 150mm| 58mm| 976mm
59cm| 578/575mm| 75° | 75°| 388mm|33.3"| 170mm| 58mm| 982mm
61cm| 585/585mm| 75° | 75°| 388mm|33.9"| 190mm| 58mm| 993mm
*Size is measured by seat tube length (center of the BB to the top of the seat tube).
**(Effective/Actual)

(mine is a 55cm.)



Any now for what you clicked on the link for:



















Let me know what you think!

Thanks for looking,
Colin
00o00 is offline
Reply With Quote
Old 07-22-09, 04:34 PM
  #2
time bandit
ˇSenor Member!

time bandit's Avatar

Join Date: Jul 2007
Location: South Philly
Posts: 1,710
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
looks pretty bad ass. thanks for the dropout close up. i was figuring these were maxway frames when i saw them in the action Catalog.


In b4 "fix ur saddle"
time bandit is offline
Reply With Quote
Old 07-22-09, 04:35 PM
  #3
deathhare
:jarckass:

deathhare's Avatar

Join Date: Aug 2006
Location: Nashville
Posts: 6,562
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Try to fix that saddle soon.


Let me guess..you wear black on the outside because black is how you feel on the inside?


Last edited by deathhare; 07-22-09 at 04:48 PM.
deathhare is offline
Reply With Quote
Old 07-22-09, 04:43 PM
  #4
johnnytheboy
Senior Member

johnnytheboy's Avatar

Join Date: Feb 2008
Location: BANNED.
Posts: 3,897
Mentioned: 37 Post(s)
Tagged: 0 Thread(s)
Quoted: 443 Post(s)
if your saddle is pointed down, it means its too high.
lower the post and level that sh it.
johnnytheboy is offline
Reply With Quote
Old 07-22-09, 04:45 PM
  #5
Retem
Paste Taster

Retem's Avatar

Join Date: May 2006
Location: Sacramento, CA
Posts: 4,392

Bikes: , Jury Bike, Moto Outcast 29, Spicer standard track frame and spicer custom steel sprint frame.

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
you know there is a sticky for this sort of thing right at the top of the page
Retem is offline
Reply With Quote
Old 07-22-09, 04:53 PM
  #6
Cy Trivialities
shtface

Cy Trivialities's Avatar

Join Date: Oct 2008
Location: Queens NYC
Posts: 535
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
looks like u wrapped ur handlebars with a trashbag.
Cy Trivialities is offline
Reply With Quote
Old 07-22-09, 07:32 PM
  #7
paulismydog
oops

paulismydog's Avatar

Join Date: May 2009
Location: nantucket
Posts: 74

Bikes: peter mooney, spot, yeti

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
looks to me like you got a pretty cushy livin' situation.....
paulismydog is offline
Reply With Quote
Old 07-22-09, 07:39 PM
  #8
00o00
ex DH/FR rider
Thread Starter

Join Date: May 2009
Posts: 20
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
haha thanks guys, this is my first time with this type of bike... so I'm still learning, i.e. the handlebar situation... I have been working on the seating position; I'll try lowering it and flattening it next.

Thanks for the comments and tips!
00o00 is offline
Reply With Quote
Old 07-22-09, 07:40 PM
  #9
killerfixie
On a mission

killerfixie's Avatar

Join Date: Jul 2009
Location: Boston, MA
Posts: 16
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
diggin the all black. Agreed though about the saddle. Personal preference: get better straps for your clips. Fabric ones suck, especially with single gate clips.
Cushy living situation or not, if youve got the money to spend, might as well get a nice bike.
killerfixie is offline
Reply With Quote
Old 07-22-09, 07:50 PM
  #10
sweatpants
Senior Member

sweatpants's Avatar

Join Date: May 2008
Posts: 170
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I like those dropouts with the integrated tensioner. nice.
sweatpants is offline
Reply With Quote
Old 07-22-09, 07:55 PM
  #11
johnnytheboy
Senior Member

johnnytheboy's Avatar

Join Date: Feb 2008
Location: BANNED.
Posts: 3,897
Mentioned: 37 Post(s)
Tagged: 0 Thread(s)
Quoted: 443 Post(s)
line your tire labels up with your valve stem.
rookie.
johnnytheboy is offline
Reply With Quote
Old 07-23-09, 08:21 AM
  #12
j3ffr3y
chickenosaurus

j3ffr3y's Avatar

Join Date: Sep 2008
Location: Boston, MA
Posts: 1,189

Bikes: 2010 Motobecane Team Track, 1997 GT Edge, 2012 Kilo TT Stripper

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
all I could think while looking at that bike was that the saddle must be bad to sit on with an angle like that. Other than that looks fine. but get a black chain and chainring and pedals.
j3ffr3y is offline
Reply With Quote
Old 07-23-09, 08:38 AM
  #13
bratton
Senior Member

Join Date: Jul 2008
Location: ridley, pa
Posts: 291

Bikes: felt f85

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
saddle fix pls
bratton is offline
Reply With Quote
Old 07-23-09, 02:03 PM
  #14
00o00
ex DH/FR rider
Thread Starter

Join Date: May 2009
Posts: 20
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Originally Posted by sweatpants View Post
I like those dropouts with the integrated tensioner. nice.
ya they're great; easy to use and strong!

Originally Posted by thehappyrobot View Post
line your tire labels up with your valve stem.
rookie.
hahah I'll make a note for next time

Originally Posted by bratton View Post
saddle fix pls
Fixed!! Feels much much better... I'm still playing with the height though
00o00 is offline
Reply With Quote
Old 07-23-09, 05:12 PM
  #15
beer slayer
Member

Join Date: Mar 2009
Posts: 49
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
THE BEER SLAYER APPROVES!
beer slayer is offline
Reply With Quote
Old 07-23-09, 06:31 PM
  #16
November
Senior Member

November's Avatar

Join Date: Oct 2007
Posts: 196
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
yeah, yeah, bike's great. That brick & stonework is NOYCE! Gravel driveway FTW. Excellent choice of pachysandra for groundcover. Liquid backyard and a chill gazebo. I can see right into yout house in that one shot. You have matching warrior statues?!?! I nominate your house for the next BBQ.
November is offline
Reply With Quote
Old 08-02-09, 09:37 AM
  #17
00o00
ex DH/FR rider
Thread Starter

Join Date: May 2009
Posts: 20
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks Beer Slayer and November!
00o00 is offline
Reply With Quote
Old 08-03-09, 01:09 AM
  #18
beer slayer
Member

Join Date: Mar 2009
Posts: 49
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
how does it ride?
beer slayer is offline
Reply With Quote
Old 08-03-09, 01:18 AM
  #19
cc700
Ths Hipstr Kills Masheenz

cc700's Avatar

Join Date: Oct 2006
Location: seattle
Posts: 8,543

Bikes: tirove

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Originally Posted by November View Post
yeah, yeah, bike's great. That brick & stonework is NOYCE! Gravel driveway FTW. Excellent choice of pachysandra for groundcover. Liquid backyard and a chill gazebo. I can see right into yout house in that one shot. You have matching warrior statues?!?! I nominate your house for the next BBQ.
someone's worked in landscaping...


as for the bike... well... it looks very nice but how much does it weigh?
cc700 is offline
Reply With Quote
Old 08-03-09, 02:16 AM
  #20
happytruck
hey

happytruck's Avatar

Join Date: Nov 2007
Posts: 193
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
nice bars
happytruck is offline
Reply With Quote
Old 08-03-09, 05:19 AM
  #21
simplestyle
Junior Member

simplestyle's Avatar

Join Date: Dec 2008
Location: Macau SAR
Posts: 9

Bikes: IRO Angus

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
NANA NaNa nana NaNa BAT MAN!
simplestyle is offline
Reply With Quote
