Gearing

Notices
Touring Have a dream to ride a bike across your state, across the country, or around the world? Self-contained or fully supported? Trade ideas, adventures, and more in our bicycle touring forum.

Gearing

Old 03-21-20, 04:03 AM
  #1
Adrian99
Junior Member
Thread Starter

Join Date: Aug 2012
Posts: 5
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Gearing

Hi, I have an old adventure/gravel touring bike where the mechanicals are well past their use-by-date and I'm thinking of replacing them and correcting a couple of issues at the same time. I am looking for as wide a range of gearing as I can get - so looking at my needs I considered
  1. what top speed do I need - using my road, MTB and gravel bikes as examples I plonked for a minimum of 110 gear inches
  2. what bottom speed - after experiencing many hills with loaded panniers I decided a maximum of 20 gear inches
How can I do this with commonly available components and my 700x38 wheels? Trying to use 2x11 gearset to give as many intermediate gears as possible. Well the smallest sprocket is 11T then my large chainwheel would need to be 46T giving a top speed gear of 114.2 gear inches. That is available in the GRX component range with a 46/30 chainset. I would need a GRX front derailleur and 105 hydraulic STI shifters would allow me to upgrade to hydraulic disk brakes. One of the issues (extra stopping power) solved.

Now with a 30T small front chainwheel I need a 42T rear cog to get the 20 gear inches lowest speed. In fact it would be 19.5 gear inches. A 11/42 cassette is readily available. Is there a rear derailleur that will handle this? A search gives me the Shimano XT RD-M8000 Shadow+ 11Sp long cage rear derailleur. According to the specs this has a low sprocket_Max.42T(2x11-speed)[TICK], max. front difference 18T[TICK], Total capacity 47T[TICK]. So this looks like a goer.

So to summarise:-
  • GRX FD-RX810 11 Speed Front Derailleur
  • GRX FC-RX600-11 46-30T 2x11 Speed CrankSet
  • XT RD-M8000 11Sp Long Cage Rear Derailleur
  • SLX CS-M7000 11-Speed 11-42 MTB Cassette
  • Jtek Shiftmate to adapt MTB derailleur to Road shifters
  • 105 RS-505/BR-RS785 Road 2x11 Lever/Caliper Set
Comments welcome - I hope it all works.

Last edited by Adrian99; 03-21-20 at 04:08 AM.
Adrian99 is offline
Old 03-21-20, 06:37 AM
  #2
Tourist in MSN
Senior Member

Join Date: Aug 2010
Location: Madison, WI
Posts: 6,564

Bikes: 1961 Ideor, 1994 Bridgestone MB-6, 2006 Airnimal Joey, 2009 Thorn Sherpa, 2013 Thorn Nomad, 2015 VO Pass Hunter, 2017 Lynskey Backroad, 2017 Raleigh Gran Prix, Perfekt 3 Speed -age unknown, 1980s Bianchi Mixte on a trainer. Others are now gone.

Mentioned: 33 Post(s)
Tagged: 0 Thread(s)
Quoted: 1585 Post(s)
Likes: 0
Liked 137 Times in 110 Posts
I have a 700c touring bike with a road triple crankset where I swapped out the 30T granny gear for a 24t. 11/32 cassette. My lowest gear (24/32) is 20.7 gear inches. I also swapped out the 52T big chainring for a 46T, that has a highest gear (46/11) of 115.5 gear inches.

A lot of people use triples that have stock gearing that is lower than what I used that might meet your criteria even better.

Any reason you are not considering a triple? They are getting a bit harder to find but they are still readily available if you look for them.

Tourist in MSN is offline
Old 03-21-20, 11:04 AM
  #3
djb
Senior Member

Join Date: Jul 2010
Location: Montreal Canada
Posts: 9,827
Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 1454 Post(s)
Liked 154 Times in 137 Posts
check out pathlesspedaled for the fellows vids on mixing and matching stuff that goes to 42t that works but officially shouldnt.

a 20-100+ gear inch range is smart, although I wouldnt go past 110. One of my bikes has a 104 top gear and while I spin out at about 50-55kph, I prefer to have the lower low gear for the weight I carry on that bike, and its very rare that I need to pedal past that 50k 30mph speed , but am fine going along at 40-45kph the few times I have long downhills.
djb is offline
Old 03-21-20, 11:43 AM
  #4
robow
Senior Member

robow's Avatar

Join Date: Aug 2005
Posts: 3,280
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 298 Post(s)
Liked 21 Times in 19 Posts
I run a couple of 46x30 cranks with 11-34 cassettes but I personally don't care for those large last few steps at the low end of that 11-42. An 11-40 gets you down to 20" with smaller steps. Let us know how it works out as I would be very interested.

Last edited by robow; 03-21-20 at 11:51 AM.
robow is offline
Old 03-22-20, 03:16 PM
  #5
acantor
Macro Geek

Join Date: Nov 2003
Location: Toronto, Ontario
Posts: 1,356

Bikes: True North tourer (www.truenorthcycles.com), 2004; Miyata 1000, 1985

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 38 Post(s)
Liked 7 Times in 5 Posts
For my first 10 or 15 years of touring, my bikes always had doubles, and although I didn't realize it at the time, the gearing was never low enough for significant hills.

When I finally upgraded to a triple, I couldn't believe the difference those extra low-end gears made. During the following twenty years, I have replaced drive trains three or four times as they wore out, and I each time, I reduced the low gears a bit more, even when it meant sacrificing the top-end gears.

I would rather spin-out at the high-end once in a while rather than struggle while climbing for even a minute. I figure I spend much more time climbing hills than bombing down them, so I choose my gearing with that in mind.

Last edited by acantor; 03-24-20 at 09:43 AM.
acantor is offline
Likes For acantor:
Old 03-22-20, 03:47 PM
  #6
danders
Junior Member

Join Date: Nov 2018
Location: Portland Oregon
Posts: 14

Bikes: Fuji World

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Liked 4 Times in 2 Posts
Low Gear Range: Road Shifters & Gears For Easier Hill Climbing - CyclingAbout.com

Thought this was interesting take on multiple options. Might be something there you have not thought of.
Seems like your on the right track.

I'm going from 11-32 to 12-36 on my old 9 speed triple, 48-36-26 because it's easy and cheap.
danders is offline
Old 03-22-20, 04:34 PM
  #7
DeadGrandpa
Senior Member

DeadGrandpa's Avatar

Join Date: Sep 2014
Location: Carolina
Posts: 778

Bikes: Trek 1120, Santa Cruz Tallboy 3CC, Fandango DC-9 MTB tandem, Jamis Renegade Expert, Bike Friday Pocket Llama, Santana Arriva tandem, Bridgestone RB-1

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 246 Post(s)
Likes: 0
Liked 32 Times in 24 Posts
I have recently renewed the drive train on my gravel/touring bike. I use a Sora triple in front, but only use the small and middle chain ring. Previous to the recent change, I had a 26/38 tooth combo in front, and a SRAM 10-42 cassette. I only used the 26 tooth in Alaska on some very steep climbs, with luggage. Skip ahead a few years, I have worn out the 38T chainring, using it like it was a 1x11 drive. I really enjoyed the 38T, it was everything I needed, anywhere, on training rides. But it wore down to shark's teeth. Having recently discovered the Path Less Pedaled channel and researched gravel bike gearing, I went with a 30/46 front and kept (replaced with identical) the 10-42. Practically speaking, it's all I should need, if I pack light enough. Oh yeah, I run 700x40c tires. I can always put a bigger chain ring on the outside spot of the crank, but I have never felt the need, even when I ran the 38. With the 46, I'm sure that I have plenty of top end.
DeadGrandpa is offline
Likes For DeadGrandpa:
Old 03-22-20, 05:54 PM
  #8
timdow
Pie Smuggler

timdow's Avatar

Join Date: Oct 2011
Location: San Diego
Posts: 346

Bikes: 2010 LHT (Blue), 2000 Jamis Aurora, 2005 Giant Ranier, 1998 Schwinn Moab (converted for commuting), 1994 Trek 1220

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 27 Post(s)
Likes: 0
Liked 4 Times in 4 Posts
Originally Posted by robow View Post
I run a couple of 46x30 cranks with 11-34 cassettes but I personally don't care for those large last few steps at the low end of that 11-42. An 11-40 gets you down to 20" with smaller steps. Let us know how it works out as I would be very interested.
I agree with Robow's statement... I would rather give up some top speed for better stepped gearing.
timdow is offline
Likes For timdow:
Old 03-24-20, 08:27 AM
  #9
hilltowner
Senior Member

hilltowner's Avatar

Join Date: Sep 2008
Location: Ashfield, Mass.
Posts: 488
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 81 Post(s)
Liked 10 Times in 8 Posts
Originally Posted by acantor View Post
...I would rather spin-out at the high-end once in a while rather than struggle while climbing for even a minute...
+1 on that. I've never once minded coasting down a hill. When compared to pushing a bike up one, there's no question which I prefer.
hilltowner is offline
Likes For hilltowner:
Old 03-25-20, 07:44 PM
  #10
UKFan4Sure
Useless Member

Join Date: Jun 2015
Location: Louisville, KY
Posts: 704
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 332 Post(s)
Liked 140 Times in 92 Posts
Originally Posted by Tourist in MSN View Post
I have a 700c touring bike with a road triple crankset where I swapped out the 30T granny gear for a 24t. 11/32 cassette. My lowest gear (24/32) is 20.7 gear inches. I also swapped out the 52T big chainring for a 46T, that has a highest gear (46/11) of 115.5 gear inches.

A lot of people use triples that have stock gearing that is lower than what I used that might meet your criteria even better.

Any reason you are not considering a triple? They are getting a bit harder to find but they are still readily available if you look for them.

I'm reading this post and it is almost precisely what I did. But my tourer is a bit older and has a 6 speed freewheel. 13,15,17,20,26,30. I swapped to a 46/36/24 and pushed my derailleur's chain wrap to it's limit.
__________________
2013 Schwinn Paramount Series 8, 2015 Specialized Roubaix Competition, 2008 Trek Portland, 1986 Schwinn LeTour, 1985 Peugeot PGN-10, 1986 Schwinn Voyageur
UKFan4Sure is offline
Old 03-25-20, 07:46 PM
  #11
UKFan4Sure
Useless Member

Join Date: Jun 2015
Location: Louisville, KY
Posts: 704
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 332 Post(s)
Liked 140 Times in 92 Posts
Originally Posted by timdow View Post
I agree with Robow's statement... I would rather give up some top speed for better stepped gearing.
Totally agree. Speed isn't the game, it's the ride....
__________________
2013 Schwinn Paramount Series 8, 2015 Specialized Roubaix Competition, 2008 Trek Portland, 1986 Schwinn LeTour, 1985 Peugeot PGN-10, 1986 Schwinn Voyageur
UKFan4Sure is offline
Old 03-30-20, 04:31 AM
  #12
rifraf
Senior Member

Join Date: Apr 2011
Location: Perth Australia
Posts: 895

Bikes: Surly Ogre, Carry Freedom Y-frame, Extrawheel Trailer

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 80 Post(s)
Liked 3 Times in 3 Posts
20 gear inches?

The hell with that.

Quite happy with my 15.3 GI for my aged worn knees and Ogres 700x 2.3' tires.

YMMV
rifraf is offline
Old 03-30-20, 06:59 AM
  #13
djb
Senior Member

Join Date: Jul 2010
Location: Montreal Canada
Posts: 9,827
Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 1454 Post(s)
Liked 154 Times in 137 Posts
The other day with my bike that has a 16.7 gear inch low, I rode it up a short steep section unloaded beside my wife pushing her bike up the hill, so that we could talk and I hate pushing bikes.

3.5kph and easy to ride, this was the slowest I've ridden this bike, but waa able to hold this speed because it was so light. I've been riding all winter on snow so my balance is pretty good, so I'm sure this helped.

but all that to say that lower than 20 g.i. is always a plus on a touring bike.
djb is offline
Old 03-30-20, 08:28 AM
  #14
Tourist in MSN
Senior Member

Join Date: Aug 2010
Location: Madison, WI
Posts: 6,564

Bikes: 1961 Ideor, 1994 Bridgestone MB-6, 2006 Airnimal Joey, 2009 Thorn Sherpa, 2013 Thorn Nomad, 2015 VO Pass Hunter, 2017 Lynskey Backroad, 2017 Raleigh Gran Prix, Perfekt 3 Speed -age unknown, 1980s Bianchi Mixte on a trainer. Others are now gone.

Mentioned: 33 Post(s)
Tagged: 0 Thread(s)
Quoted: 1585 Post(s)
Likes: 0
Liked 137 Times in 110 Posts
Originally Posted by djb View Post
The other day with my bike that has a 16.7 gear inch low, I rode it up a short steep section unloaded beside my wife pushing her bike up the hill, so that we could talk and I hate pushing bikes.

3.5kph and easy to ride, this was the slowest I've ridden this bike, but waa able to hold this speed because it was so light. I've been riding all winter on snow so my balance is pretty good, so I'm sure this helped.

but all that to say that lower than 20 g.i. is always a plus on a touring bike.
I find that 3.5 mph (5.6 km/hr) is my minimum speed to maintain vertical and directional stability. If you can balance at 3.5 km/hr, I am impressed.

I sized the chainring that I use for touring on my Rohloff bike to give me 3.5 mph at a cadence of 72. That is a low gear of 16.2 gear inches. Sometimes if the wind is not blowing and the conditions are good, I might find myself pedaling up a hill in a cadence in the 60s, but I am not much below that 3.5 mph that I consider a minimuim.

That said, my derailleur touring bikes have a lowest gear of 19.3 or 20.7 gear inches and I manage to live with those bikes too.
Tourist in MSN is offline
Old 03-30-20, 08:43 AM
  #15
djb
Senior Member

Join Date: Jul 2010
Location: Montreal Canada
Posts: 9,827
Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 1454 Post(s)
Liked 154 Times in 137 Posts
Thanks, it was actually fun, we were chatting and I looked down at computer and saw the 3.4,5,6 just as muy wife said, yup we're going 3.5....
I had hundreds of snowy slippy front wheel understeer moments this winter, and like I wrote in my thread about winter riding, it became a game for me to not put a foot down, so keeping the power on and using body language to push through the understeer, so going up this hill with one light pannier on pavement was easy more or less.

but as for the lowest gear inch, like you say, the old adage of 20 to 100 is still pretty valid, although for unloaded riding I do prefer a taller high gear. I like the 112 g.i. on my lighter bike to be able to spin up to close to 70kph.45mph, so if this fellow rides a lot unloaded and is comfortable going fast, he very well may like a taller top gear.
I have a friend who never goes past 40kph and she really doesn't need a 50t , especially given that her knees and low gearing that isn't low enough kill her on climbs.... but she has been ignoring my loud comments for years and won't change her bike....
djb is offline
