Your method of setting correct tyre pressures
#1
Senior Member
Thread Starter
Your method of setting correct tyre pressures
What method do you use to set the ‘correct’ tyre pressures on your bike(s)? And how do you know you’ve finally hit the right pressures?
The method I’ve been using so far is to check the max PSI on the tyre wall and inflate to a value close to, but slightly below, the max pressure. However, I think that this is probably not giving me the best ride quality given that there is a variation in fore and aft load on the bike wheels. Am I right I thinking that the rear tyre should probably have a slightly higher tyre pressure than the front, and bike weight plus body weight also play a role?
The method I’ve been using so far is to check the max PSI on the tyre wall and inflate to a value close to, but slightly below, the max pressure. However, I think that this is probably not giving me the best ride quality given that there is a variation in fore and aft load on the bike wheels. Am I right I thinking that the rear tyre should probably have a slightly higher tyre pressure than the front, and bike weight plus body weight also play a role?
#4
Senior Member
Join Date: Apr 2009
Location: New Rochelle, NY
Posts: 38,706
Bikes: too many bikes from 1967 10s (5x2)Frejus to a Sumitomo Ti/Chorus aluminum 10s (10x2), plus one non-susp mtn bike I use as my commuter
Mentioned: 140 Post(s)
Tagged: 1 Thread(s)
Quoted: 5779 Post(s)
Liked 2,576 Times
in
1,427 Posts
There's no such thing as correct tire pressure. Optimal pressure depends on the specific conditions, including the tire itself, the rider's weight, road surface, weather, and rider's personal preference about ride quality.
So instead of thinking about numbers, think about how pressure affects the ride.
Lowering the pressure will make for a softer ride, which is nice, especially on bumpier roads. But it increases friction and slows you. It can also allow you to bottom on bumps, causing pinch flats and denting rims.
Higher pressure lowers friction which is nice, plus makes for very crisp handling. But less friction, also can mean less traction, especially on wet roads or when cornering. It also makes for a harsher ride, especially if the road isn't glass smooth.
So start at some arbitrary pressure, say 90% of the tire's max. Ride that a while and think about the ride. Then add 10psi and ride that a while making not of what's better or worse. If it felt better overall, try 10psi more, and do this until the good isn't getting better, but the bad is getting worse. You now have an upper limit.
Repeat the process going down from where you started until you find your lower limit. IME the lower limit tends to be more obvious.
So you now have a band, probably 20-30 psi wide, and have a good sense of where within it you're happiest. As you gain a sense of how pressure effects ride, you'll make small adjustments based on specific conditions.
So instead of thinking about numbers, think about how pressure affects the ride.
Lowering the pressure will make for a softer ride, which is nice, especially on bumpier roads. But it increases friction and slows you. It can also allow you to bottom on bumps, causing pinch flats and denting rims.
Higher pressure lowers friction which is nice, plus makes for very crisp handling. But less friction, also can mean less traction, especially on wet roads or when cornering. It also makes for a harsher ride, especially if the road isn't glass smooth.
So start at some arbitrary pressure, say 90% of the tire's max. Ride that a while and think about the ride. Then add 10psi and ride that a while making not of what's better or worse. If it felt better overall, try 10psi more, and do this until the good isn't getting better, but the bad is getting worse. You now have an upper limit.
Repeat the process going down from where you started until you find your lower limit. IME the lower limit tends to be more obvious.
So you now have a band, probably 20-30 psi wide, and have a good sense of where within it you're happiest. As you gain a sense of how pressure effects ride, you'll make small adjustments based on specific conditions.
__________________
FB
Chain-L site
An ounce of diagnosis is worth a pound of cure.
Just because I'm tired of arguing, doesn't mean you're right.
“One accurate measurement is worth a thousand expert opinions” - Adm Grace Murray Hopper - USN
WARNING, I'm from New York. Thin skinned people should maintain safe distance.
FB
Chain-L site
An ounce of diagnosis is worth a pound of cure.
Just because I'm tired of arguing, doesn't mean you're right.
“One accurate measurement is worth a thousand expert opinions” - Adm Grace Murray Hopper - USN
WARNING, I'm from New York. Thin skinned people should maintain safe distance.
#5
Senior Member
Thread Starter
With more weight on the rear axle, particularly with my cruiser bike for example, should the rear tyre pressure should be higher than the front?
I have started experimenting a bit now, whereas previously I would just inflate both tyres close to the max value stated on the tyre wall. I notice that on my Fat Frank tyres theres a minimum and a maximum range of 20-55 PSI.
I have started experimenting a bit now, whereas previously I would just inflate both tyres close to the max value stated on the tyre wall. I notice that on my Fat Frank tyres theres a minimum and a maximum range of 20-55 PSI.
#6
Senior Member
Join Date: Feb 2014
Location: Pasadena, CA
Posts: 4,848
Bikes: Schwinn Varsity
Mentioned: 22 Post(s)
Tagged: 0 Thread(s)
Quoted: 1931 Post(s)
Liked 742 Times
in
422 Posts
""What method do you use to set the ‘correct’ tyre pressures on your bike(s)? And how do you know you’ve finally hit the right pressures?""
I use the gauge on the pump to set the correct pressure. When the gauge says 90 psi, I know it is the correct pressure.
I use the gauge on the pump to set the correct pressure. When the gauge says 90 psi, I know it is the correct pressure.
#7
Senior Member
Join Date: Jul 2006
Posts: 3,063
Mentioned: 63 Post(s)
Tagged: 0 Thread(s)
Quoted: 1216 Post(s)
Liked 185 Times
in
116 Posts
- Inflate tire until bead snaps into place
- Measure tire height
- Multiply tire height by 15%
- Adjust my sag gauge to (tire height x 15%)
- Orient valve stem so I can reach while sitting on saddle
- Place sag gauge on rim
- Reach down and let air out until sag gauge shows level
- Get off bike and take pressure reading to note for future
Alternatively one could use the Frank Berto chart and fudge the different tire pressure required for tires of different casing stiffness.
#8
Mechanic/Tourist
1. Inflate tires to what I think is about right, with the front a bit lower.
2. If I don't like the ride adjust as appropriate
3. Ride more, worry less.
2. If I don't like the ride adjust as appropriate
3. Ride more, worry less.
#9
working on my sandal tan
Join Date: Aug 2011
Location: CID
Posts: 22,629
Bikes: 1991 Bianchi Eros, 1964 Armstrong, 1988 Diamondback Ascent, 1988 Bianchi Premio, 1987 Bianchi Sport SX, 1980s Raleigh mixte (hers), All-City Space Horse (hers)
Mentioned: 98 Post(s)
Tagged: 0 Thread(s)
Quoted: 3871 Post(s)
Liked 2,568 Times
in
1,579 Posts
This calculator makes it easy: Bicycle tire pressure calculator (I use the "Weight of (Fully-dressed) Rider & Bike" option and select the 45%/55% weight distribution for any road-style bike.)
__________________
RUSA #7498
Originally Posted by noglider
People in this forum are not typical.
Last edited by ThermionicScott; 09-21-17 at 09:58 PM.
#10
Senior Member
Join Date: Jul 2008
Location: 25 miles northwest of Boston
Posts: 29,549
Bikes: Bottecchia Sprint, GT Timberline 29r, Marin Muirwoods 29er, Trek FX Alpha 7.0
Mentioned: 112 Post(s)
Tagged: 0 Thread(s)
Quoted: 5224 Post(s)
Liked 3,581 Times
in
2,342 Posts
trial & error
#11
Sr Member on Sr bikes
Step 1. Pump up tire
Step 2. Ignore gauge on pump
Step 3. Check pressure (i.e. tire 'hardness') with gauge of the thumb of my right hand
Step 4. Repeat steps 1-3 as necessary
Step 5. Ride
Dan
Step 2. Ignore gauge on pump
Step 3. Check pressure (i.e. tire 'hardness') with gauge of the thumb of my right hand
Step 4. Repeat steps 1-3 as necessary
Step 5. Ride
Dan
#12
I'm good to go!
Join Date: Jul 2017
Location: Mississippi
Posts: 14,985
Bikes: Tarmac Disc Comp Di2 - 2020
Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 6193 Post(s)
Liked 4,808 Times
in
3,316 Posts
Don't worry about whether you gauge is accurate. Just make sure it is consistent. No matter how you go about calculating what it "should" be, you will still have to adjust up or down depending on you and your ride conditions. So with any gauge that gives consistent readings you'll know how to inflate your tires for the ride you want irregardless of whether the gauge is telling you the truth about the pressure.
#13
- Soli Deo Gloria -
Join Date: Aug 2015
Location: Northwest Georgia
Posts: 14,779
Bikes: 2018 Rodriguez Custom Fixed Gear, 2017 Niner RLT 9 RDO, 2015 Bianchi Pista, 2002 Fuji Robaix
Mentioned: 235 Post(s)
Tagged: 0 Thread(s)
Quoted: 6844 Post(s)
Liked 736 Times
in
469 Posts
- Inflate tire until bead snaps into place
- Measure tire height
- Multiply tire height by 15%
- Adjust my sag gauge to (tire height x 15%)
- Orient valve stem so I can reach while sitting on saddle
- Place sag gauge on rim
- Reach down and let air out until sag gauge shows level
- Get off bike and take pressure reading to note for future
Alternatively one could use the Frank Berto chart and fudge the different tire pressure required for tires of different casing stiffness.
What sag gauge to you use?
Do you find that you have to adjust for riding style (race vs casual ride) or surface (gravel vs paved)?
-Tim-
#14
Calamari Marionette Ph.D
With more weight on the rear axle, particularly with my cruiser bike for example, should the rear tyre pressure should be higher than the front?
I have started experimenting a bit now, whereas previously I would just inflate both tyres close to the max value stated on the tyre wall. I notice that on my Fat Frank tyres theres a minimum and a maximum range of 20-55 PSI.
I have started experimenting a bit now, whereas previously I would just inflate both tyres close to the max value stated on the tyre wall. I notice that on my Fat Frank tyres theres a minimum and a maximum range of 20-55 PSI.
I ride my tires on the low side. Grip and comfort mean more to me than outright speed.
The "Best" pressure is a compromise.
Experiment a lot. Pay attention (document if needed) to the changes in performance and ride quality.
Too high and you lose grip and the ride is harsh. Too low and it sucks power from you.
Find your happy middle ground.
#15
Calamari Marionette Ph.D
#16
Banned
Join Date: Apr 2010
Location: Lincoln Ne
Posts: 9,924
Bikes: RANS Stratus TerraTrike Tour II
Mentioned: 46 Post(s)
Tagged: 0 Thread(s)
Quoted: 3352 Post(s)
Liked 1,056 Times
in
635 Posts
On a bike, 10% less than the max listed on the side wall. Allows for pressure increase on hot days, and helps prevent snake bite punctures. On Tadpole Trikes some what less on the two front tires. I run 65 on them and 80 in back on 100# tires.
#17
Senior Member
Join Date: Jul 2006
Posts: 3,063
Mentioned: 63 Post(s)
Tagged: 0 Thread(s)
Quoted: 1216 Post(s)
Liked 185 Times
in
116 Posts
Definitely, it's terrain and tire dependent. I try to stay between 10-25% depending on the terrain/weather. For races/events I'll often overthink and add too much pressure on race day - it probably ends up faster but less comfortable. Most of my casual mixed terrain rides are such a smaller percentage of gravel overall that I stopped messing with pressure/sag and just ride it at my road pressure/sag as the segments are rarely longer than 10-15 minutes and mostly flat/smooth.
I've only been really paying attention to this for a few months. I'm still experimenting and figuring out just how much change in sag makes a difference in tire feel/speed/reduction in pinch flats. I think 2-3% is noticeable but I'm still not sure it's worthwhile to be so quantitative.
#18
working on my sandal tan
Join Date: Aug 2011
Location: CID
Posts: 22,629
Bikes: 1991 Bianchi Eros, 1964 Armstrong, 1988 Diamondback Ascent, 1988 Bianchi Premio, 1987 Bianchi Sport SX, 1980s Raleigh mixte (hers), All-City Space Horse (hers)
Mentioned: 98 Post(s)
Tagged: 0 Thread(s)
Quoted: 3871 Post(s)
Liked 2,568 Times
in
1,579 Posts
Riding through dust on an otherwise hard road (or marking the tires with chalk before riding) can give a good visual indication of the contact patch of the tire, too. If it's just a narrow strip down the middle of the tire, you're probably running too much pressure. Ditto if you find that your rear tires wear thin at the centers when there is still thick rubber at the shoulders of the tread.
From https://janheine.wordpress.com/2016/...ompass-tires/:
The rear tire is a bit more worn. The wear is almost entirely in the center of the tread – an indication that Andreas is running slightly higher tire pressures than we’d recommend. He might be more comfortable and even faster if he let out a tiny bit of air.
From https://janheine.wordpress.com/2016/...ompass-tires/:
The rear tire is a bit more worn. The wear is almost entirely in the center of the tread – an indication that Andreas is running slightly higher tire pressures than we’d recommend. He might be more comfortable and even faster if he let out a tiny bit of air.
#19
- Soli Deo Gloria -
Join Date: Aug 2015
Location: Northwest Georgia
Posts: 14,779
Bikes: 2018 Rodriguez Custom Fixed Gear, 2017 Niner RLT 9 RDO, 2015 Bianchi Pista, 2002 Fuji Robaix
Mentioned: 235 Post(s)
Tagged: 0 Thread(s)
Quoted: 6844 Post(s)
Liked 736 Times
in
469 Posts
This was the poor man's tire pressure guage for sports cars back in the day.
One would mark the shoulder of the tire with chalk some distance up the sidewall and into the tread. If the chalk is wearing off the sidewall then pressure was too low. If chalk is left on the outside of the tread area then pressure is too high.
It was surprisingly effective.
-Tim-
One would mark the shoulder of the tire with chalk some distance up the sidewall and into the tread. If the chalk is wearing off the sidewall then pressure was too low. If chalk is left on the outside of the tread area then pressure is too high.
It was surprisingly effective.
-Tim-
#20
rebmeM roineS
Join Date: Jan 2006
Location: Metro Indy, IN
Posts: 16,216
Bikes: Bacchetta Giro A20, RANS V-Rex, RANS Screamer
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 653 Post(s)
Liked 347 Times
in
226 Posts
+1. Since experimenting with the Frank Berto recommendations years ago, I have not been disappointed. No pinch flats, and the ride is much more comfortable than when I simply aired up the tires to the max pressure rating.
This calculator makes it easy: Bicycle tire pressure calculator (I use the "Weight of (Fully-dressed) Rider & Bike" option and select the 45%/55% weight distribution regardless of the style of bike.)
This calculator makes it easy: Bicycle tire pressure calculator (I use the "Weight of (Fully-dressed) Rider & Bike" option and select the 45%/55% weight distribution regardless of the style of bike.)
__________________
Bacchetta Giro A20, RANS V-Rex, RANS Screamer
Bacchetta Giro A20, RANS V-Rex, RANS Screamer
#21
Senior Member
Join Date: Oct 2013
Location: Mich
Posts: 7,386
Bikes: RSO E-tire dropper fixie brifter
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked 2,968 Times
in
1,917 Posts
IDK if it is just coincidence; From my experiences with my bike, with a higher PSI in the tube the more prone a spoke is to break.
__________________
-Oh Hey!
-Oh Hey!
#22
working on my sandal tan
Join Date: Aug 2011
Location: CID
Posts: 22,629
Bikes: 1991 Bianchi Eros, 1964 Armstrong, 1988 Diamondback Ascent, 1988 Bianchi Premio, 1987 Bianchi Sport SX, 1980s Raleigh mixte (hers), All-City Space Horse (hers)
Mentioned: 98 Post(s)
Tagged: 0 Thread(s)
Quoted: 3871 Post(s)
Liked 2,568 Times
in
1,579 Posts
I start with the 15% tire drop pressure from the calculator above and go from there. Works best to first weigh you and your bike front and rear to find out the load on each wheel and the F/R distribution. Two of my bikes are about 30/70 F/R so considerably less pressure for the front tires. (Both long wheelbase recumbent bikes.)
#24
aka Tom Reingold
Join Date: Jan 2009
Location: New York, NY, and High Falls, NY, USA
Posts: 40,502
Bikes: 1962 Rudge Sports, 1971 Raleigh Super Course, 1971 Raleigh Pro Track, 1974 Raleigh International, 1975 Viscount Fixie, 1982 McLean, 1996 Lemond (Ti), 2002 Burley Zydeco tandem
Mentioned: 511 Post(s)
Tagged: 0 Thread(s)
Quoted: 7348 Post(s)
Liked 2,465 Times
in
1,433 Posts
I take a guess at what pressure risks bottoming out on my rims. Let's say that's 30 psi with 32mm tires. 40 psi is the pressure I want to ride at. Then I inflate to 50 psi, because the tires will seep air, and I don't want to reinflate frequently. When it feels like I'm below 40 psi, I reinflate.
__________________
Tom Reingold, tom@noglider.com
New York City and High Falls, NY
Blogs: The Experienced Cyclist; noglider's ride blog
“When man invented the bicycle he reached the peak of his attainments.” — Elizabeth West, US author
Please email me rather than PM'ing me. Thanks.
Tom Reingold, tom@noglider.com
New York City and High Falls, NY
Blogs: The Experienced Cyclist; noglider's ride blog
“When man invented the bicycle he reached the peak of his attainments.” — Elizabeth West, US author
Please email me rather than PM'ing me. Thanks.
#25
- Soli Deo Gloria -
Join Date: Aug 2015
Location: Northwest Georgia
Posts: 14,779
Bikes: 2018 Rodriguez Custom Fixed Gear, 2017 Niner RLT 9 RDO, 2015 Bianchi Pista, 2002 Fuji Robaix
Mentioned: 235 Post(s)
Tagged: 0 Thread(s)
Quoted: 6844 Post(s)
Liked 736 Times
in
469 Posts
I take a guess at what pressure risks bottoming out on my rims. Let's say that's 30 psi with 32mm tires. 40 psi is the pressure I want to ride at. Then I inflate to 50 psi, because the tires will seep air, and I don't want to reinflate frequently. When it feels like I'm below 40 psi, I reinflate.
I like this method.
It completely avoids anything which might require thinking, minimizes the need to do actual work and justifies it all using hypothetical numbers and acronyms.
Only a seasoned IT pro can come up with a system like this.
-Tim-
