What am I looking for?

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

What am I looking for?

Old 04-06-19, 09:56 AM
  #1
Shinkers
Senior Member
Thread Starter

Join Date: Jan 2014
Location: Utah
Posts: 754

Bikes: '88 Trek 1200, '91 Trek 1400

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 119 Post(s)
Liked 7 Times in 5 Posts
What am I looking for?

Hello,

My 1988 Trek 1200 has been perfect for what I use it for, and fits me very well. The only down side is tire clearance, and I'm now looking to change that. I'm hoping to find a frame that I can transfer my existing build onto.

I'm looking for something with a 27.2 seat post, 130mm spacing (126 would work though), down tube shifter bosses, preferably with a threadless fork (either size), drilled for caliper brakes, and then some tire clearance. I'd love to use 32's and have the room to not worry about clearance.

I'm happy to do some digging myself, but the old catalogs don't really tell you things like tire clearance and hub spacing. I know that older 27" frames will generally fit bigger tires with some long reach calipers, but I'm also really hoping to go the threadless route although I'm aware that I may just need to pick up a fork separately.

Thanks.
Shinkers is offline
Old 04-06-19, 11:33 AM
  #2
madpogue
Senior Member

Join Date: Jan 2004
Location: Madison, WI USA
Posts: 6,258
Mentioned: 43 Post(s)
Tagged: 0 Thread(s)
Quoted: 2120 Post(s)
Liked 1,266 Times in 911 Posts
Why threadless? If you're looking for C&V, you're much more likely to find quill.
madpogue is offline
Old 04-06-19, 12:21 PM
  #3
Shinkers
Senior Member
Thread Starter

Join Date: Jan 2014
Location: Utah
Posts: 754

Bikes: '88 Trek 1200, '91 Trek 1400

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 119 Post(s)
Liked 7 Times in 5 Posts
I can never seem to get quills to stay quiet. I put a threadless fork on my trek and really like it a lot better.
Shinkers is offline
Old 04-07-19, 07:39 AM
  #4
jamesdak
Senior Member

Join Date: Aug 2010
Location: Utah
Posts: 7,995

Bikes: Paletti,Pinarello Monviso,Duell Vienna,Giordana XL Super(2)Lemond Maillot Juane (2) & custom,PDG Paramount,Serotta CSI,Fuji Opus III,Davidson Impulse,Pashley Guv'nor,Evans,Fishlips,Prologue TT,Y-Foil,Softride, Tetra Pro, CAAD8 Optimo,Klein Quantum II

Mentioned: 142 Post(s)
Tagged: 0 Thread(s)
Quoted: 2051 Post(s)
Liked 3,019 Times in 1,214 Posts
Did you see this? I don't know about tire clearance on these but it's local so should be easy to take a quick peak at. The threadless is going to be the hard the part of the equation to meet.

https://www.facebook.com/marketplace...6116058593168/

If you look at the one picture of the front end you can see what looks to be a lot of tire clearance from what's on there.
__________________
Steel is real...and comfy.
jamesdak is offline
Old 04-07-19, 07:51 AM
  #5
Barrettscv
Have bike, will travel

Barrettscv's Avatar

Join Date: Feb 2006
Location: Lake Geneva, WI
Posts: 12,382

Bikes: Ridley Helium SLX, Canyon Endurance SL, De Rosa Professional, Eddy Merckx Corsa Extra, Schwinn Paramount (1 painted, 1 chrome), Peugeot PX10, Serotta Nova X, Simoncini Cyclocross Special, Raleigh Roker, Pedal Force CG2 and CX2

Mentioned: 46 Post(s)
Tagged: 0 Thread(s)
Quoted: 905 Post(s)
Liked 276 Times in 152 Posts
The Soma Pescadero and Black Mountain Road framesets would be ideal. Both use long reach caliper brakes and fit larger tires. The Black Mountain will fit 33mm tires, the Soma will fit 40mm tires.

https://blackmtncycles.com/shop/frames/road-v3/

https://www.somafab.com/archives/product/pescadero-frame-set

You you intend to stay C&V, you choices are impossibly limited. The Trek touring bikes with caliper brakes might fit your needs. However, the forks are threaded.

Last edited by Barrettscv; 04-07-19 at 08:03 AM.
Barrettscv is offline
Old 04-07-19, 08:12 AM
  #6
jlaw
Senior Member

Join Date: Mar 2018
Posts: 934

Bikes: 2015 Spec. AWOL Elite, 2007 Spec. Roubaix Elite, 2003 Spec. Big Hit 2, 1998 VooDoo Zobop, 1985 Trek 410, 1984 Trek 620 1985 Trek 620, 1979 Trek 710

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 371 Post(s)
Liked 142 Times in 87 Posts
Originally Posted by Shinkers View Post
Hello,

My 1988 Trek 1200 has been perfect for what I use it for, and fits me very well. The only down side is tire clearance, and I'm now looking to change that. I'm hoping to find a frame that I can transfer my existing build onto.

I'm looking for something with a 27.2 seat post, 130mm spacing (126 would work though), down tube shifter bosses, preferably with a threadless fork (either size), drilled for caliper brakes, and then some tire clearance. I'd love to use 32's and have the room to not worry about clearance.

I'm happy to do some digging myself, but the old catalogs don't really tell you things like tire clearance and hub spacing. I know that older 27" frames will generally fit bigger tires with some long reach calipers, but I'm also really hoping to go the threadless route although I'm aware that I may just need to pick up a fork separately.

Thanks.
Have you considered modifying your existing bike to a 650b wheel size?

It's easy to determine the approx. tire size you could fit if you used 650b rims. These guidelines are a good primer for those thinking about going 650b - and it includes the description of how to determine largest possible tire size.

650B Conversion Guidlines

You would likely need longer-reach brake calipers - unless your existing calipers can accommodate a 19mm move of the pad toward the axle.

Rolling on larger tires is the way to go.
jlaw is offline
Old 04-07-19, 12:03 PM
  #7
randyjawa
Senior Member

randyjawa's Avatar

Join Date: Apr 2007
Location: Thunder Bay, Ontario, Canada - burrrrr!
Posts: 11,376

Bikes: 1958 Rabeneick 120D, 1968 Legnano Gran Premio, 196? Torpado Professional, 2000 Marinoni Piuma

Mentioned: 204 Post(s)
Tagged: 0 Thread(s)
Quoted: 1283 Post(s)
Likes: 0
Liked 1,433 Times in 802 Posts
Get yourself an early eighties Bianchi Touring. It takes 700c x 38 barely, but they do fit and they do feel great, even though they are cheap tires...


__________________
"98% of the bikes I buy are projects".
randyjawa is offline
Old 04-07-19, 12:49 PM
  #8
Shinkers
Senior Member
Thread Starter

Join Date: Jan 2014
Location: Utah
Posts: 754

Bikes: '88 Trek 1200, '91 Trek 1400

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 119 Post(s)
Liked 7 Times in 5 Posts
Thanks for all of the replies.

I know that threadless is a major ball-up. Was there a period when 1" threadless was actually adopted more widely? Or did things just go from 1" threaded to 1 1/8" threadless?

Currently I'm really liking the idea of a 650b conversion. I've done it before on this bike, but the wheels I built were kind of so-so and I wasn't all that impressed. I think maybe if I spring for some nicer rims (I already have a set of 5800 hubs), and keep them tubeless I can make it work and just ride two wheelsets.
Shinkers is offline
Old 04-07-19, 02:58 PM
  #9
merziac
Senior Member

merziac's Avatar

Join Date: Oct 2015
Location: PDX
Posts: 11,766

Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2

Mentioned: 232 Post(s)
Tagged: 0 Thread(s)
Quoted: 3668 Post(s)
Liked 4,212 Times in 2,520 Posts
Originally Posted by Shinkers View Post
I can never seem to get quills to stay quiet. I put a threadless fork on my trek and really like it a lot better.
Not sure where you could be getting chronic creaking. I have probably have at least 2 dozen quill equipped C+V road bikes with many different stem, bar, headset setups. Some old, some new, overhauled and not, a few slightly undersize and everything in between. Not a single creak, anywhere, can't imagine ever converting any of them to threadless.

Are you working on these yourself? We really should be able to help get to the bottom of this I would think.

This really limits your options and eliminates a lot of very cool C+V projects.
merziac is offline
Old 04-07-19, 03:01 PM
  #10
Shinkers
Senior Member
Thread Starter

Join Date: Jan 2014
Location: Utah
Posts: 754

Bikes: '88 Trek 1200, '91 Trek 1400

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 119 Post(s)
Liked 7 Times in 5 Posts
In all fairness, it could have been the fork I had. Who knows what the inside of it looked like. Had I really wanted to keep the quill, I'd have tried a new threaded fork on this bike. However, I opted to go the threadless route.
Shinkers is offline
Old 04-07-19, 05:50 PM
  #11
jlaw
Senior Member

Join Date: Mar 2018
Posts: 934

Bikes: 2015 Spec. AWOL Elite, 2007 Spec. Roubaix Elite, 2003 Spec. Big Hit 2, 1998 VooDoo Zobop, 1985 Trek 410, 1984 Trek 620 1985 Trek 620, 1979 Trek 710

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 371 Post(s)
Liked 142 Times in 87 Posts
Originally Posted by Shinkers View Post
Thanks for all of the replies.

I know that threadless is a major ball-up. Was there a period when 1" threadless was actually adopted more widely? Or did things just go from 1" threaded to 1 1/8" threadless?

Currently I'm really liking the idea of a 650b conversion. I've done it before on this bike, but the wheels I built were kind of so-so and I wasn't all that impressed. I think maybe if I spring for some nicer rims (I already have a set of 5800 hubs), and keep them tubeless I can make it work and just ride two wheelsets.
As a novice wheel-builder I had good luck with the 32h Pacenti Brevet 650b machined rims last year - 1200 miles and still true. Velocity, H Son, and others also have solid offerings

I think 650b is a really versatile set-up for many vintage frames/forks.
jlaw is offline
Old 04-07-19, 05:55 PM
  #12
Kuromori
Senior Member

Join Date: Jan 2019
Posts: 528
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 237 Post(s)
Likes: 0
Liked 83 Times in 64 Posts
Originally Posted by Shinkers View Post
In all fairness, it could have been the fork I had. Who knows what the inside of it looked like. Had I really wanted to keep the quill, I'd have tried a new threaded fork on this bike. However, I opted to go the threadless route.
It's not just your imagination. Under high stress, quill stems can flex and creak. It's why French constructeurs made non-quill stems as a custom option which worked very much like modern threadless stems except that they didn't preload the headset. Whether it's really much of a problem, I'd err to the side of saying it's mostly a non-issue for most kinds of riding.
Kuromori is offline
