Le Tour Brake Help

I have a 1982 Le Tour Iam upgrading. I wont to replace the center pull brakes to side pull. Ive already up graded the wheels to 700c. What side pull brakes can I use with out a lot of trouble (re-engineering)?
scotsman is offline
Reply
Old 07-28-06 | 09:43 AM
  #2
barba's Avatar
Senior Member

Joined: Nov 2005
Posts: 4,083
Likes: 0
The problem you are likely to face is in the reach of the brake calipers. When you go from 27s to 700c you add a little more distance between the brake mount and the rim. The plus side is you get great clearance for fenders! The down side is regular short reach brakes might not make it to the rim (pads rubbing tires is very bad).

Look for long reach calipers. Harris Cyclery has some decent Tektros for $50.
https://sheldonbrown.com/harris/brakes.html#brakesets
barba is offline
Reply
Old 07-28-06 | 09:57 AM
  #3
Stacey's Avatar
Non Tribuo Anus Rodentum and off to the next adventure (RIP)
Sheldon Brown Memorial - Donating
20 Anniversary

Joined: Dec 2002
Posts: 9,161
Likes: 4
Originally Posted by scotsman
I have a 1982 Le Tour Iam upgrading. I wont to replace the center pull brakes to side pull. Ive already up graded the wheels to 700c. What side pull brakes can I use with out a lot of trouble (re-engineering)?

Wot!?!?! Why? How is this an 'upgrade? Oh, the sacrelige!
__________________
Stacey is offline
Reply
Old 07-28-06 | 10:10 AM
  #4
well biked's Avatar
Senior Member
Titanium Club Membership
20 Anniversary

Joined: Jul 2005
Posts: 7,575
Likes: 229
I've changed a le tour from 27's to 700c before, and I ran into problems with brake reach when I tried putting sidepulls on. What you'll find is that the new "long reach" road brakes that are available are more like the old standard reach brakes in terms of their reach. At the time I changed my wheels, I didn't have a working set of centerpulls, which would have provided plenty of reach, so I tried some funky solutions, which included an old Dia-Compe sidepull brake on the front (barely reached the rim) and a new BMX caliper brake on the rear. I never liked that setup, and when I found just what I needed on ebay to put my old centerpulls back together, I did and have been very happy with them ever since. I use kool stop pads on my centerpulls, and aero style brake levers, and the brakes are very strong. Kind of a PIA to set up, but once done, if done correctly, they stay centered. They also provide plenty of room for fenders, which I run front and rear on my bike..............Exactly how much reach you'll need will depend on your bike (there's variation even from one le tour to another depending on frame size), so in your case you might find some type of sidepull that will work. But as much as you probably hate to hear this, in going from 27's to 700c, your centerpulls are probably the best solution you're going to find. Typically, it's the rear brake that needs the most reach, btw, so you might find a brake that will reach the front (like I did with the old Dia-Compe front brake), and have to find a different solution for the rear.

One other thing you might consider is a drop bolt, which will lower the brake down from the bolt mount on the frame/fork. Harris Cyclery used to carry some, may still, but they're very expensive. You might make a homeade one (that's another thing I tried), but personally, I didn't trust it and never used it. Good luck-
well biked is offline
Reply
Old 07-28-06 | 10:24 AM
  #5
superdex's Avatar
staring at the mountains
20 Anniversary

Joined: Mar 2005
Posts: 4,576
Likes: 218
From: Castle Pines, CO

Bikes: Obed GVR, Fairdale Goodship, Salsa Timberjack 29

I kept the top pull brake and just moved the shoes enough to still hit the 700c rim....
superdex is offline
Reply
Old 07-28-06 | 10:52 AM
  #6
Yet another vegan biker

Joined: Dec 2005
Posts: 965
Likes: 6
From: Trapped behind the corn curtain

Bikes: Sakae Prism, Vintage Fuji bike(S), too many bikes, one from scratch bike.

I've got a pair of Weinmann 605 sidepulls on my 1982 Le Tour. They had plenty of reach for the 700c wheelset I recently added.

I've found Wellbiked's point about the rear needing the most reach is true. Maybe I've just been lucky with the couple of 700c conversions I've made.



I've got much nicer bikes but I really love this old Le Tour.
silversmith is offline
Reply
