Corn Cob Freewheels

Thread Tools

Search this Thread

Old 01-04-08 | 04:33 PM
  #26
Senior Member
20 Anniversary

Joined: Dec 2005
Posts: 2,245
Likes: 3
From: Auld Blighty

Bikes: Early Cannondale tandem, '99 S&S Frezoni Audax, '65 Moulton Stowaway, '52 Claud Butler, TSR30, Brompton

The only freewheel with an 11t cog was a very rare Suntour that screwed into a 13t AFAIR, so an 11-up straight block freewheel couldn't happen anyway. 13t straight blocks are fairly easy, 12t not impossible. These things haven't been made for a while though...
LWaB is offline
Reply
Old 01-04-08 | 05:15 PM
  #27
TMB's Avatar
TMB
Permanent Refugee .......

Joined: Dec 2005
Posts: 1,256
Likes: 0
From: Okanagan Valley, BC.

Bikes: Steel

Originally Posted by LWaB
The only freewheel with an 11t cog was a very rare Suntour that screwed into a 13t AFAIR, so an 11-up straight block freewheel couldn't happen anyway. 13t straight blocks are fairly easy, 12t not impossible. These things haven't been made for a while though...

I am not at home and so can't check, but I am fairly sure that I can Make a 12 t block using the Regina CX6 kit.

I have 3 of those kits in the garage. I seem to remember that I can do an 11 with it though.
TMB is offline
Reply
Old 01-04-08 | 07:02 PM
  #28
stronglight's Avatar
Old Skeptic

Joined: Jan 2006
Posts: 1,044
Likes: 9
From: New Mexico, USA

Bikes: 19 road bikes & 1 Track bike

Regarding actual FREEWHEELS (not cassettes)... were there any 6-speeds with 12 tooth cogs?

I believe even the early Shimano 7400 series (Dura-Ace MF-7400) 6-speed freewheel was only available down to 13 teeth (and that was around 1986)... and the 7-speed MF-7400 could add a 12 tooth cog.

Were there other 6-speeds freewheels which ever used 12t cogs? ... Regina? ... Maillard?


By the way, here is a gold 5-speed corn cob freewheel dated August 1980 with 13-17 cogs

stronglight is offline
Reply
Old 01-04-08 | 07:38 PM
  #29
Senior Member
20 Anniversary

Joined: Dec 2005
Posts: 2,245
Likes: 3
From: Auld Blighty

Bikes: Early Cannondale tandem, '99 S&S Frezoni Audax, '65 Moulton Stowaway, '52 Claud Butler, TSR30, Brompton

Originally Posted by waytoomanybikes
I am not at home and so can't check, but I am fairly sure that I can Make a 12 t block using the Regina CX6 kit.

I have 3 of those kits in the garage. I seem to remember that I can do an 11 with it though.
12t yes, 11t no. Regina stopped making freewheels ages ago (a decade or so?), so the most used cogs are getting rarer anyway.

The only other 11t freewheels are from Shimano and are the opposite of straight blocks.
LWaB is offline
Reply
Old 01-04-08 | 08:45 PM
  #30
Senior Member

Joined: Nov 2006
Posts: 813
Likes: 0
From: TORONTO , ONT , CA

Bikes: '86 AMBROSI / C RECORD. PINARELLO MONTELLO / FRAME, FORK.

Campy aluminium freewheel:

12-13-14-15-16-17

In my hand.


Regards,
J T
J T CUNNINGHAM is offline
Reply
Old 01-04-08 | 09:33 PM
  #31
oldbobcat's Avatar
Senior Member
20 Anniversary

Joined: Jul 2005
Posts: 4,990
Likes: 709
From: Boulder County, CO

Bikes: '80 Masi Gran Criterium, '12 Trek Madone, early '60s Frejus track

Nashbar has 13-24 7-cog blocks. I think that's as close as you're going to get, unless you happen across something on ebay.
oldbobcat is offline
Reply
Old 01-05-08 | 03:45 AM
  #32
stronglight's Avatar
Old Skeptic

Joined: Jan 2006
Posts: 1,044
Likes: 9
From: New Mexico, USA

Bikes: 19 road bikes & 1 Track bike

Originally Posted by LWaB
"... The only other 11t freewheels are from Shimano and are the opposite of straight blocks."
Do you know what model freewheels those would be?
I've only seen Shimano freehub Cassettes with 11t cogs - but that could be very handy with some compact road cranksets.
stronglight is offline
Reply
Old 01-05-08 | 04:56 AM
  #33
Senior Member
Titanium Club Membership
15 Anniversary

Joined: Feb 2007
Posts: 15,410
Likes: 188
From: Tariffville, CT

Bikes: Tsunami road bikes, Dolan DF4 track

Originally Posted by LWaB
The only freewheel with an 11t cog was a very rare Suntour that screwed into a 13t AFAIR, so an 11-up straight block freewheel couldn't happen anyway.
+1 I was looking for someone to post this.

The kicker with the 11T (I think used by Steve Bauer) was that you couldn't use a 12T. Seemed illogical but a 12T simply wouldn't thread onto existing freewheel bodies. All of us racer types either chose to stick with the 12 (most of us did) and a couple used the 11-13 but to no great effect. I guess Suntour thought that maybe a tourist would use it (or a tandem or some other bike that descends really fast but climbs really slow and therefore would need a wide range of gears). I know for a long time I saved an 11-13 unit in my tool box "just in case". This 11-13 unit threaded onto a standard freewheel body, at least at that time it was standard.

Reginas, Sachs, etc were all limited to a 12T minimum. I know because I had the various cog boards and extra cogs and all that. I still have about 15 pounds of freewheel stuff sitting in the basement. I suppose I should sort through and list/sell it.

cdr
carpediemracing is offline
Reply
Old 01-05-08 | 09:41 AM
  #34
TMB's Avatar
TMB
Permanent Refugee .......

Joined: Dec 2005
Posts: 1,256
Likes: 0
From: Okanagan Valley, BC.

Bikes: Steel

Originally Posted by LWaB
12t yes, 11t no. Regina stopped making freewheels ages ago (a decade or so?), so the most used cogs are getting rarer anyway.

The only other 11t freewheels are from Shimano and are the opposite of straight blocks.
Yep, sorry the 11T ref was a typo.

Well aware that Regina no longer makes freewheels, the CX6 kits I have are new and unused. I also have a lifelong supply of CX freewheel bodies.

I think I am good with freewheels for the rest of my lifetime.
TMB is offline
Reply
Old 01-05-08 | 03:38 PM
  #35
Senior Member
20 Anniversary

Joined: Dec 2005
Posts: 2,245
Likes: 3
From: Auld Blighty

Bikes: Early Cannondale tandem, '99 S&S Frezoni Audax, '65 Moulton Stowaway, '52 Claud Butler, TSR30, Brompton

Originally Posted by stronglight
Do you know what model freewheels those would be?
I've only seen Shimano freehub Cassettes with 11t cogs - but that could be very handy with some compact road cranksets.
7sp 11-28 (rare) and 7sp 11-34 (common). I don't know the model numbers off the top of my head but it should be fairly easy for you to find them.
LWaB is offline
Reply
Old 01-06-08 | 12:17 AM
  #36
Senior Member

Joined: Dec 2006
Posts: 99
Likes: 0
like this?

Last edited by woodenwheels; 01-06-08 at 12:40 AM.
woodenwheels is offline
