feasibility of hub-gears
Hey there. I have a couple old schwinns that I ride, but I want to put together a more "modern" lighter road bike for longer trips around town, including some pretty good hills. I think I want to put a hub gear system on it in lieu of a derailler, etc. I kind of like the hub gear (3-spd) on my traveler, and I've heard of newer ones that have 7 or 12 speeds or something like that. I was just wondering if anyone has used these much... just trying to get feedback on your experiences with these
thanks
thanks
#2
Not a problem, they work well. Since you are in Cincy, I do recommend getting a hub with more than 3 gears. Do a search for Nexus and you will find lots of examples.
https://www.bikeforums.net/classic-vintage/295583-anyone-run-classic-road-bikes-internally-geared-hub.html
https://www.bikeforums.net/classic-vintage/295583-anyone-run-classic-road-bikes-internally-geared-hub.html
#3
Senior Member
Joined: Sep 2007
Posts: 680
Likes: 4
my wifes been using a bianchi milano with 8-speed shimano nexus hub since late last summer and we've nothing but good things to say of it so far.It still won't cover as broad a gearing range as is possible with conventional derailleurs but for commuting & general schlepping around on the flats and up moderately steep hills, it seems ideal. I esp like that you can change gears at a stop. The twist grip shifter is also about as intuitive as you could ask for and its drum brake has good stopping power for the application it's given. All-in-all it's an amazing mechanism and hopefully will turn out to be as trouble-free as all the reports seem to indicate.
best,
k

best,
k

Last edited by caterham; 03-17-08 at 08:12 PM.
#4
Senior Member



Joined: Dec 2005
Posts: 18,841
Likes: 11,745
I recently outfitted a Raleigh International with a Shimano Nexus 8 hub built into a 700c wheel (which I won on eBay). Overall, I'm liking the hub a lot though I haven't quite adjusted it right and have a problem with it slipping in low gears. It's really quiet and offers a good range of gears. I don't have experience with other modern IG hubs, but I've read good things about the SRAM S7 hub.
Neal
Neal
#6
Senior Member
Joined: Jul 2006
Posts: 584
Likes: 1
From: Tucson AZ
#7
Membership Not Required
Joined: Jan 2005
Posts: 16,853
Likes: 18
From: On the road-USA
Bikes: Giant Excursion, Raleigh Sports, Raleigh R.S.W. Compact, Motobecane? and about 20 more! OMG
I don't "like" IGH...I LOVE THEM

I currently own and ride 4 on a regular basis and 2-3 of my project bikes are planned as IGH. FWIW all I have are the old Sturmey Archer and one old Shimano 3 speed hub. The project bikes include a Sturmey Archer 4 speed from the 50's and a most likely a brand new Sturmey Archer 5 speed with drum brake.
Aaron


I currently own and ride 4 on a regular basis and 2-3 of my project bikes are planned as IGH. FWIW all I have are the old Sturmey Archer and one old Shimano 3 speed hub. The project bikes include a Sturmey Archer 4 speed from the 50's and a most likely a brand new Sturmey Archer 5 speed with drum brake.
Aaron
__________________
Webshots is bailing out, if you find any of my posts with corrupt picture files and want to see them corrected please let me know. :(
ISO: A late 1980's Giant Iguana MTB frameset (or complete bike) 23" Red with yellow graphics.
"Cycling should be a way of life, not a hobby.
RIDE, YOU FOOL, RIDE!"_Nicodemus
"Steel: nearly a thousand years of metallurgical development
Aluminum: barely a hundred
Which one would you rather have under your butt at 30mph?"_krazygluon
Webshots is bailing out, if you find any of my posts with corrupt picture files and want to see them corrected please let me know. :(
ISO: A late 1980's Giant Iguana MTB frameset (or complete bike) 23" Red with yellow graphics.
"Cycling should be a way of life, not a hobby.
RIDE, YOU FOOL, RIDE!"_Nicodemus
"Steel: nearly a thousand years of metallurgical development
Aluminum: barely a hundred
Which one would you rather have under your butt at 30mph?"_krazygluon
#8
Sister Annie
Joined: Jul 2007
Posts: 1,519
Likes: 2
From: Hauraki Plains District, New Zealand
Bikes: Retro Hercules adult tricycle, 1953 Hercules ladies roadster, 1950s Wearwell fixed gear 'Club' pathracer, 1980s Malvern Star 'Super Star', 1980s Healing GTX-105 Arabesque, 1980's Morrison Concorde & etc & etc.......
Whenever I take out my old Ladies Hercules roadster for a ride it's a real joy. Why? - because it's got the sweetest SA 3 speed hub and it never gives me a troublesome moment. The now out of production Sachs 2 speed kickback hub is another hub I'm very fond of too. Being only two speed it is a wee bit limited, but it's largely flat around town and my bikes with a Sachs hub are used for 'go-and-fetch-it' type shopping runs and the like so two speeds aren't a problem.
I do own a 1980s 10 speed bicycle with derailleur gears which is very nicely setup with Vx SunTour components and while it's a good and trouble free ride I never feel quite so confident about shifting gears as when I'm riding a hub geared bike.
I do own a 1980s 10 speed bicycle with derailleur gears which is very nicely setup with Vx SunTour components and while it's a good and trouble free ride I never feel quite so confident about shifting gears as when I'm riding a hub geared bike.
__________________
OMNIPOTENS aeterne Deus, qui nos secundum imaginem Tuam plasmasti, et omnia bona, vera, pulchra, praesertim in divina persona Unigeniti Filii Tui Domini nostri Iesu Christi, quaerere iussisti, praesta quaesumus ut, per intercessionem Sancti Isidori, Episcopi et Doctoris, in peregrinationibus per interrete factis et manus oculosque ad quae Tibi sunt placita intendamus et omnes quos convenimus cum caritate ac patientia accipiamus. Per Christum Dominum nostrum. Amen.
OMNIPOTENS aeterne Deus, qui nos secundum imaginem Tuam plasmasti, et omnia bona, vera, pulchra, praesertim in divina persona Unigeniti Filii Tui Domini nostri Iesu Christi, quaerere iussisti, praesta quaesumus ut, per intercessionem Sancti Isidori, Episcopi et Doctoris, in peregrinationibus per interrete factis et manus oculosque ad quae Tibi sunt placita intendamus et omnes quos convenimus cum caritate ac patientia accipiamus. Per Christum Dominum nostrum. Amen.
#9
I don't "like" IGH...I LOVE THEM

I currently own and ride 4 on a regular basis and 2-3 of my project bikes are planned as IGH. FWIW all I have are the old Sturmey Archer and one old Shimano 3 speed hub. The project bikes include a Sturmey Archer 4 speed from the 50's and a most likely a brand new Sturmey Archer 5 speed with drum brake.
Aaron


I currently own and ride 4 on a regular basis and 2-3 of my project bikes are planned as IGH. FWIW all I have are the old Sturmey Archer and one old Shimano 3 speed hub. The project bikes include a Sturmey Archer 4 speed from the 50's and a most likely a brand new Sturmey Archer 5 speed with drum brake.
Aaron

#10
Senior Member
Joined: Feb 2005
Posts: 1,213
Likes: 1
From: Pleasanton Tx
Bikes: old,older.and very old
All kinds of hub gears on the market at present--some costing $1000s ---German made 21 gear hub and also a 2 speed BB internal gear so you can match just about anything done by derailers.At a cost!Harris cycle has hub gears.
#11
Try www.biketoolsetc.com
I've no idea if they actually have any or not, but permaco may still have some of the UK made hubs left.
I've no idea if they actually have any or not, but permaco may still have some of the UK made hubs left.
#12
Thread Starter
Full Member


Joined: Feb 2008
Posts: 332
Likes: 12
From: Cincinnati
Bikes: Custom 94 Specialized Crossroads
Awesome. thanks for the info. One of the reasons I asked is because on my traveler with the 3sp Sturmey, it seems that i have to stop pedaling for just a second for the gear to change. I don't know if that is common or what. What say you?
#13
Junior Member
Joined: Feb 2008
Posts: 13
Likes: 0
From: The beautiful Southern Highlands of N.S.W. Australia
Bikes: Carbine [5 of them, 1936 to '49] SJH track bikes [2 of them late 50's & early 60's] Morgan Custom tourer [1985] Olympic Road racer [c 1951] Malvern Star 5 Star, [1939 & '51] Unknown [c1910 to c1920] plus about 12 others.
Well you need to step on the clutch to change gears in a car. If you keep pedaling with the Sturmey you have the internal gears all loadad up & unable to move untill you unload them when you stop pedaling.
Nobody would get far trying a clutchless gear change in a car with the pedal still floored, [trans still loaded] you would never get it out of gear [forget the disaster that awaits if the next gear is actually selected]
So yes, you should always change to another Gear in a Sturmey Archer with either the wheel rolling forward, or if stationary, with the pedals rotated backwards during the actual shift.
Nobody would get far trying a clutchless gear change in a car with the pedal still floored, [trans still loaded] you would never get it out of gear [forget the disaster that awaits if the next gear is actually selected]
So yes, you should always change to another Gear in a Sturmey Archer with either the wheel rolling forward, or if stationary, with the pedals rotated backwards during the actual shift.
#14
Thread Starter
Full Member


Joined: Feb 2008
Posts: 332
Likes: 12
From: Cincinnati
Bikes: Custom 94 Specialized Crossroads
Ah. That makes perfect sense. I was comparing that to a derailer system in which you have to keep pedaling to change gears. But alas, there is still that moment of "clutch" action, sort of.
#15
Membership Not Required
Joined: Jan 2005
Posts: 16,853
Likes: 18
From: On the road-USA
Bikes: Giant Excursion, Raleigh Sports, Raleigh R.S.W. Compact, Motobecane? and about 20 more! OMG
Try Old Bike Trader in the UK. I have ordered some bits and pieces from them with good results.
Aaron
Aaron
__________________
Webshots is bailing out, if you find any of my posts with corrupt picture files and want to see them corrected please let me know. :(
ISO: A late 1980's Giant Iguana MTB frameset (or complete bike) 23" Red with yellow graphics.
"Cycling should be a way of life, not a hobby.
RIDE, YOU FOOL, RIDE!"_Nicodemus
"Steel: nearly a thousand years of metallurgical development
Aluminum: barely a hundred
Which one would you rather have under your butt at 30mph?"_krazygluon
Webshots is bailing out, if you find any of my posts with corrupt picture files and want to see them corrected please let me know. :(
ISO: A late 1980's Giant Iguana MTB frameset (or complete bike) 23" Red with yellow graphics.
"Cycling should be a way of life, not a hobby.
RIDE, YOU FOOL, RIDE!"_Nicodemus
"Steel: nearly a thousand years of metallurgical development
Aluminum: barely a hundred
Which one would you rather have under your butt at 30mph?"_krazygluon
#16
The Legitimiser
Joined: Jul 2005
Posts: 4,849
Likes: 6
From: Southampton, UK
Bikes: Gazelle Trim Trophy, EG Bates Track Bike, HR Bates Cantiflex bike, Nigel Dean fixed gear conversion, Raleigh Royal, Falcon Westminster.
5's are available on the link below, both some older steel British built ones (the Sprinter, not the old S5) and the newer alloy ones:
https://www.sjscycles.co.uk/category-...r-Hubs-104.htm
https://www.sjscycles.co.uk/category-...r-Hubs-104.htm
#17
Thanks for the help with the five speeds. I'm only interested in the new and improved ones. I've got one of the new three speeds and I'm sold on the new Taiwan-made stuff. (I never thought I'd say that.)
