Drop bar bottle cage mounting
11-07-08 | 11:51 AM
#1
Thread Starter
Full Member
Joined: Aug 2005
Posts: 361
Likes: 63
Drop bar bottle cage mounting
I've seen the Velo Orange bracket/ clamp that attaches to drop bars in order to mount a bottle cage. I've seen a few where there are 2 mounted on either side of the stem/ handlebar clamp.
Is there anything similar that mounts in the center or around the stem rather than offset like above that may interfere with bar tape or a light? I was trying to avoid mounting anything to the frame.
Thanks!
Is there anything similar that mounts in the center or around the stem rather than offset like above that may interfere with bar tape or a light? I was trying to avoid mounting anything to the frame.
Thanks!
11-07-08 | 12:25 PM
#2
Senior Member
Joined: Nov 2005
Posts: 5,768
Likes: 10
Bikes: Cinelli, Paramount, Raleigh, Carlton, Zeus, Gemniani, Frejus, Legnano, Pinarello, Falcon
TA, REG and others made cages that mounted to the bars with a wide piece to fit around the end of the stem and clamped to the bars either side of the stem. But they're obsolete; turn up pn ebay now and then for good prices.
I mounted 2 bottles using the Velo-Orange setup; two was pretty common in the olden days...
Here's a TA one on my Frejus. Blackburn made an adapter years ago, don't know if those are still available.
I mounted 2 bottles using the Velo-Orange setup; two was pretty common in the olden days...
Here's a TA one on my Frejus. Blackburn made an adapter years ago, don't know if those are still available.
Last edited by dbakl; 11-07-08 at 12:37 PM.
11-07-08 | 03:52 PM
#3
Junior Member
Joined: Oct 2008
Posts: 23
Likes: 0
11-07-08 | 04:00 PM
#4
Senior Member
Joined: Nov 2005
Posts: 5,768
Likes: 10
Bikes: Cinelli, Paramount, Raleigh, Carlton, Zeus, Gemniani, Frejus, Legnano, Pinarello, Falcon
11-07-08 | 04:18 PM
#6
Senior Member
Joined: Nov 2005
Posts: 5,768
Likes: 10
Bikes: Cinelli, Paramount, Raleigh, Carlton, Zeus, Gemniani, Frejus, Legnano, Pinarello, Falcon
11-08-08 | 12:13 AM
#8
Senior Member
Joined: Nov 2007
Posts: 1,218
Likes: 0
Well, it's hard to see in this tiny little pic, but my 51 Clubman has one that mounts in the middle. It is made from thin aluminum strips bent adn riveted into a holder, and held on with two straps on either side of the stem. It's way less bulky and less in-the-way than the new ones that mount off to the side. It's lower, too, so that's nice. I picked it up 'cheap' on eBay. Not sure how old it is, but it has to be from the 60s or before. I had one of hte newer kind as above, but I ended up taking it off because it looked too klutzy and stuck up too high.
You can see hte rest of the bike here:
https://www.sciencemonster.net/machin...n/clubman.html
You can see hte rest of the bike here:
https://www.sciencemonster.net/machin...n/clubman.html
11-08-08 | 01:40 AM
#9
Senior Member
Joined: Oct 2008
Posts: 2,929
Likes: 2
I have one made by Minoura. It clamps to the horizontal section of the bars using one rubber sleeved U-bolt on either side of the stem. It has provisions for mounting two conventional water bottle cages to it via the normal two screws. You could use any water bottle cages you choose.
I went to the Minoura web site. They do not show a dual bottle unit but have several different styles of single bottle holders. Buy two!
My recollection is that when the two bottles are full (heavy), the entire affair tends to bounce around (bobble) a lot.
I also found this from Nashbar being sold on Amazon:
https://www.amazon.com/Nashbar-Handle...ef=pd_sim_sg_2
I went to the Minoura web site. They do not show a dual bottle unit but have several different styles of single bottle holders. Buy two!
My recollection is that when the two bottles are full (heavy), the entire affair tends to bounce around (bobble) a lot.
I also found this from Nashbar being sold on Amazon:
https://www.amazon.com/Nashbar-Handle...ef=pd_sim_sg_2
Last edited by Mike Mills; 11-08-08 at 01:46 AM.
11-08-08 | 07:46 AM
#10
Senior Member
Joined: Nov 2007
Posts: 1,218
Likes: 0
11-08-08 | 10:42 AM
#11
This is what the Minoura double mount looks like. Like Mr. Mills said above, if not clamped tight it can move around a bit.
11-08-08 | 03:09 PM
#12
K2ProFlex baby!
Joined: Feb 2007
Posts: 6,134
Likes: 59
From: My response would have been something along the lines of: "Does your bike have computer controlled suspension? Then shut your piehole, this baby is from the future!"
Bikes: to many to list
I picked this up at the LBS's Bike Swap, its not a bar mounted cage but I thought it was when I saw it
Pretty cool me thinks
Im going to mount it on my Sport Tourer
Pretty cool me thinks Im going to mount it on my Sport Tourer
__________________
You see, their morals, their code...it's a bad joke, dropped at the first sign of trouble. They're only as good as the world allows them to be. I'll show you. When the chips are down, these...These "civilized" people...they'll eat each other. See, I'm not a monster. I'm just ahead of the curve
You see, their morals, their code...it's a bad joke, dropped at the first sign of trouble. They're only as good as the world allows them to be. I'll show you. When the chips are down, these...These "civilized" people...they'll eat each other. See, I'm not a monster. I'm just ahead of the curve
11-08-08 | 03:55 PM
#13
Senior Member
Joined: Apr 2004
Posts: 539
Likes: 0
From: sf
I just found this one on ebay https://cgi.ebay.com/Schwinn-Sprint-W...1%7C240%3A1318
11-08-08 | 06:36 PM
#14
feros ferio
Joined: Jul 2000
Posts: 22,413
Likes: 1,878
From: www.ci.encinitas.ca.us
Bikes: 1959 Capo Modell Campagnolo; 1960 Capo Sieger (2); 1962 Carlton Franco Suisse; 1970 Peugeot UO-8; 1982 Bianchi Campione d'Italia; 1988 Schwinn Project KOM-10;
The Minoura system works great. I have posted various pictures of the two water bottle cages on Capo #1.
