Headset dilemma

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Headset dilemma

Old 09-25-09, 06:27 PM
  #1
miamijim
Senior Member
Thread Starter

miamijim's Avatar

Join Date: Aug 2003
Location: Tampa, Florida
Posts: 14,017
Mentioned: 39 Post(s)
Tagged: 0 Thread(s)
Quoted: 373 Post(s)
Likes: 0
Liked 33 Times in 29 Posts
Headset dilemma

The Merckx headset is dead so I need a replacement for the original 600 Ultegra tri-color. My dilemma is what to replace it with. Needing to balance component consistency with price I've come up with 3 or 4 options. There aren't alot of 1" threaded headsets availble in the mid-range. Its either $25 or $75+. If the bikes only worth $800 it doesnt make sense to drop $100 on a headset. 9I have checked ebay and I am keeping my eye on a few)

So, without further rambling.....the bike and the posssible headsets. I'm thinking all silver. Whats C&V's opinion? BTW....$50 cap with shipping.

1. Shimano 105 with black top cap $38. I'm not thrilled about 'downgrading' to 105 but its Shimano.
2. Ritchey Logic with black top cap $21. Ritchey makes a fine headset. I consider these to be at least 105 quality but certainly not an Ultegra downgrade. Not Shimano so it doesnt give the appearance to being a downgrade.
3. All black Ritchey Logic. $18.









miamijim is offline
Old 09-25-09, 06:37 PM
  #2
cudak888
www.theheadbadge.com

cudak888's Avatar

Join Date: Sep 2005
Location: Southern Florida
Posts: 26,105

Bikes: https://www.theheadbadge.com

Mentioned: 65 Post(s)
Tagged: 0 Thread(s)
Quoted: 1351 Post(s)
Liked 1,436 Times in 856 Posts
Tange Levin:



They're usually $35-40 or so. Trick is to find the NR knockoff model, though I'd be concerned about stack height. What size crown race?

-Kurt
__________________







cudak888 is offline
Old 09-25-09, 06:49 PM
  #3
miamijim
Senior Member
Thread Starter

miamijim's Avatar

Join Date: Aug 2003
Location: Tampa, Florida
Posts: 14,017
Mentioned: 39 Post(s)
Tagged: 0 Thread(s)
Quoted: 373 Post(s)
Likes: 0
Liked 33 Times in 29 Posts
Originally Posted by cudak888 View Post
Tange Levin:

They're usually $35-40 or so. Trick is to find the NR knockoff model, though I'd be concerned about stack height. What size crown race?

-Kurt
Thats a possibility, stack heights listed at ~38mm so it should be OK. Crown races have different sizes?
miamijim is offline
Old 09-25-09, 06:59 PM
  #4
Ex Pres
Cat 6

Ex Pres's Avatar

Join Date: Dec 2007
Location: Mountain Brook, AL
Posts: 7,359
Mentioned: 24 Post(s)
Tagged: 0 Thread(s)
Quoted: 445 Post(s)
Liked 92 Times in 64 Posts
I just picked the first YST I found, click the pick for ebay $17 shipped. I bought one without the clone 600 top nuts, very plain, no markings, alloy+steel for $13 shipped. It's at least the equal of the Ritchey Logic I installed on another frame.

__________________
72 Frejus, Holdsworth Record & special CNC / 74 Italvega NR / c80 ?French? / 82 Raleigh Intl MkII / 83 Trek 620 / 87 Centurion IM MV / 03 Casati Dardo / 08 BF IRO / 09 Dogma FPX / 10 Vassago Fisticuff


Last edited by Ex Pres; 09-25-09 at 07:03 PM.
Ex Pres is offline
Old 09-25-09, 07:03 PM
  #5
miamijim
Senior Member
Thread Starter

miamijim's Avatar

Join Date: Aug 2003
Location: Tampa, Florida
Posts: 14,017
Mentioned: 39 Post(s)
Tagged: 0 Thread(s)
Quoted: 373 Post(s)
Likes: 0
Liked 33 Times in 29 Posts
Originally Posted by Bob Barker View Post
Too old looking and out of place. The previously mentioned Tange may look out of place as well due to its bulky looking nature.
miamijim is offline
Old 09-25-09, 07:03 PM
  #6
cudak888
www.theheadbadge.com

cudak888's Avatar

Join Date: Sep 2005
Location: Southern Florida
Posts: 26,105

Bikes: https://www.theheadbadge.com

Mentioned: 65 Post(s)
Tagged: 0 Thread(s)
Quoted: 1351 Post(s)
Liked 1,436 Times in 856 Posts
Originally Posted by miamijim View Post
Crown races have different sizes?
Well, it depends how big a hammer you have.

-Kurt
__________________







cudak888 is offline
Old 09-25-09, 07:05 PM
  #7
miamijim
Senior Member
Thread Starter

miamijim's Avatar

Join Date: Aug 2003
Location: Tampa, Florida
Posts: 14,017
Mentioned: 39 Post(s)
Tagged: 0 Thread(s)
Quoted: 373 Post(s)
Likes: 0
Liked 33 Times in 29 Posts
Originally Posted by cudak888 View Post
Well, it depends how big a hammer you have.

-Kurt
If its a 27.0 I could file down the race. Right?
miamijim is offline
Old 09-25-09, 07:06 PM
  #8
Bianchigirll
Bianchi Goddess

Bianchigirll's Avatar

Join Date: Apr 2009
Location: Shady Pines Retirement Fort Wayne, In
Posts: 27,328

Bikes: Too many to list here check my signature.

Mentioned: 142 Post(s)
Tagged: 2 Thread(s)
Quoted: 1940 Post(s)
Liked 721 Times in 455 Posts
which one fits the the fork crown and your existing stackheight? the YST looks like an old 600ex
__________________
Bianchis '90 Proto, '90 Campione del Fausto Giamondi Specialisma Italiano Mundo, '91 Boarala 'cross, '93 Project 3, '86 Volpe, '97 Ti Megatube, '93 Reparto Corse SBX

Others but still loved; '80 Batavus Professional, '87 Cornelo, '?? Jane Doe (still on the drawing board), '90ish Haro Escape SLX Bertoni "Speckled Trout"
Bianchigirll is offline
Old 09-25-09, 07:08 PM
  #9
gomango
Senior Member

Join Date: Jul 2006
Location: STP
Posts: 15,160
Mentioned: 70 Post(s)
Tagged: 0 Thread(s)
Quoted: 798 Post(s)
Liked 159 Times in 105 Posts
If you want to go for "good enough" go back to a Shimano 600 from Peter White. $56. The bike though, is worth far more in our market. I had a legit offer last weekend for $1,100 at the Minneapolis Bike Classic. I went for a Campy Record headset for mine, but I have the 600 in two other bikes and it works well. Nice bike by the way, I really like mine.
__________________


Bikes and stuff

https://www.flickr.com/photos/36270004@N06/
gomango is offline
Old 09-25-09, 08:17 PM
  #10
canopus
Senior Member

canopus's Avatar

Join Date: Mar 2009
Location: Kingwood, TX
Posts: 1,352

Bikes: 1985 Cannondale SR300, 1985 Cannondale ST400, 1984 Trek 760, 1984 Trek 610, 1984 Trek 720, 1981 Trek 710, 1979 Trek 710, Gary Littlejohn Cruiser, BMX

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 58 Post(s)
Liked 52 Times in 40 Posts
1" Grand Cru from Velo Orange. Nice sealed unit for $40.

Last edited by canopus; 09-25-09 at 08:19 PM. Reason: added pic
canopus is offline
Old 09-25-09, 10:05 PM
  #11
dannyg1
Senior Member

Join Date: Jan 2005
Posts: 1,225
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Likes: 0
Liked 4 Times in 3 Posts
Another pretty option:

https://cgi.ebay.com/1-inch-threaded-...d=p3286.c0.m14
dannyg1 is offline
Old 09-26-09, 06:42 AM
  #12
Road Fan
Senior Member

Road Fan's Avatar

Join Date: Apr 2005
Location: Ann Arbor, MI
Posts: 15,351

Bikes: 1980 Masi, 1984 Mondonico, 1984 Trek 610, 1980 Woodrup Giro, 2005 Mondonico Futura Leggera ELOS, 1967 PX10E, 1971 Peugeot UO-8

Mentioned: 42 Post(s)
Tagged: 0 Thread(s)
Quoted: 1237 Post(s)
Liked 212 Times in 180 Posts
Good luck, Miamijim! This is what I've referred to in the past as "headset hell." One of the problems is getting definitive readings on the stack height and crown/cup sizings, without buying and measuring.

I would not file down the crown race mount on a Merkcx (or any decent) frame. There's a risk you won't get the new surface round or concentric, or will make it too small. Then you'd have to get it knurled to build out a slight interference fit. The fit it has now is the result of rather precise machining. It has interference, but can be pressed on. You can measure with a mike or caliper to detect out of round, but it's much harder to measure it for true concentricity with the steering axis. Get the right size. This might be harsh, but IMO to bugger up the crown race is tantamount to Drewing.

I'd suggest a modern NOS Campy, a Shimano 600 from Peter White, a roller-bearing Stronglight, or a Tange of some sort. I would definitely prefer silver color for that bike. The Tanges can be confusing since there are so many, and the characteristics of the Levin changed over the years. At one point they really were Campy Record clones, but later they shrank to a much lower stack height. My Trek 610 was designed for a Stronglight delrin, but I found a 2005 or so Campy Chorus was a good fit.

Other good ones that might be hard to find in unworn used condition: Campagnolo Nuovo Record, Dura Ace, Suntour Superbe. I'd not hesitate to put a good Campy NR on that bike if I had one. With maintainance it will last decades more. Same for the 600 and I presume the Dura Ace.
Road Fan is offline
Old 09-26-09, 07:15 AM
  #13
Grand Bois
Senior Member

Grand Bois's Avatar

Join Date: Mar 2005
Location: Pinole, CA, USA
Posts: 17,415
Mentioned: 24 Post(s)
Tagged: 0 Thread(s)
Quoted: 436 Post(s)
Likes: 0
Liked 8 Times in 8 Posts
Those Ritchie headsets are serviceable, but they're heavy and very cheap looking with the black plastic cap. They used to be all over eBay for around $6. I'd put one on a cheap flipper mountain bike, but a midrange road bike deserves something better.
Grand Bois is offline
Old 09-26-09, 09:13 AM
  #14
cudak888
www.theheadbadge.com

cudak888's Avatar

Join Date: Sep 2005
Location: Southern Florida
Posts: 26,105

Bikes: https://www.theheadbadge.com

Mentioned: 65 Post(s)
Tagged: 0 Thread(s)
Quoted: 1351 Post(s)
Liked 1,436 Times in 856 Posts
DA AX/Tange Levin Aero headset?



-Kurt
__________________







cudak888 is offline
Old 09-26-09, 10:06 AM
  #15
Road Fan
Senior Member

Road Fan's Avatar

Join Date: Apr 2005
Location: Ann Arbor, MI
Posts: 15,351

Bikes: 1980 Masi, 1984 Mondonico, 1984 Trek 610, 1980 Woodrup Giro, 2005 Mondonico Futura Leggera ELOS, 1967 PX10E, 1971 Peugeot UO-8

Mentioned: 42 Post(s)
Tagged: 0 Thread(s)
Quoted: 1237 Post(s)
Liked 212 Times in 180 Posts
Originally Posted by Dirtdrop View Post
Those Ritchie headsets are serviceable, but they're heavy and very cheap looking with the black plastic cap. They used to be all over eBay for around $6. I'd put one on a cheap flipper mountain bike, but a midrange road bike deserves something better.
how can you say a merkcx is midrange? these are high end, and deserve the best you can find reasonably.
Road Fan is offline
Old 09-26-09, 10:36 AM
  #16
MetinUz
Senior Member

Join Date: Apr 2005
Posts: 953
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 32 Post(s)
Likes: 0
Liked 5 Times in 4 Posts
Is this not the model with sealed bearings ? I had both 600 and 105 headsets at some point, and the bearings looked interchangeable. If so, the easiest option would be to buy a 105 headset and use the bearings.
MetinUz is offline
Old 09-26-09, 10:43 AM
  #17
Zaphod Beeblebrox
PanGalacticGargleBlaster

Zaphod Beeblebrox's Avatar

Join Date: Apr 2009
Location: Smugglers Notch, Vermont
Posts: 7,536

Bikes: Upright and Recumbent....too many to list, mostly Vintage.

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Likes: 0
Liked 3 Times in 2 Posts
There's a 600 Ultegra headeset ending shortly on eBay

https://cgi.ebay.com/Shimano-600-Ulte...d=p3286.c0.m14
Zaphod Beeblebrox is offline
Old 09-26-09, 11:36 AM
  #18
gomango
Senior Member

Join Date: Jul 2006
Location: STP
Posts: 15,160
Mentioned: 70 Post(s)
Tagged: 0 Thread(s)
Quoted: 798 Post(s)
Liked 159 Times in 105 Posts
Agreed on Road Fan's noting the "mid-range" comment. My wife and I just returned from a nice forty miler. I took my Merckx, she chose her Primato. If a Merckx Century is mid-range, is a Primato also so? At any rate, just order up a Record or 600 headset from your favorite vendor/LBS. This will solve the issue promptly. You really can't miss with these choices.

edit: I just noticed your $50 limit, so do what I do. No fancy coffee for a week or two! Voila, cash.
__________________


Bikes and stuff

https://www.flickr.com/photos/36270004@N06/

Last edited by gomango; 09-26-09 at 01:36 PM.
gomango is offline
Old 09-26-09, 11:36 AM
  #19
Road Fan
Senior Member

Road Fan's Avatar

Join Date: Apr 2005
Location: Ann Arbor, MI
Posts: 15,351

Bikes: 1980 Masi, 1984 Mondonico, 1984 Trek 610, 1980 Woodrup Giro, 2005 Mondonico Futura Leggera ELOS, 1967 PX10E, 1971 Peugeot UO-8

Mentioned: 42 Post(s)
Tagged: 0 Thread(s)
Quoted: 1237 Post(s)
Liked 212 Times in 180 Posts
Originally Posted by MetinUz View Post
Is this not the model with sealed bearings ? I had both 600 and 105 headsets at some point, and the bearings looked interchangeable. If so, the easiest option would be to buy a 105 headset and use the bearings.
Earlier 600 EX (should be a 6207 marked on it) were loose bearings. Can't say about any of the later ones, but I have the 6207. I know that one for sure.
Road Fan is offline
Old 09-26-09, 04:04 PM
  #20
Grand Bois
Senior Member

Grand Bois's Avatar

Join Date: Mar 2005
Location: Pinole, CA, USA
Posts: 17,415
Mentioned: 24 Post(s)
Tagged: 0 Thread(s)
Quoted: 436 Post(s)
Likes: 0
Liked 8 Times in 8 Posts
Originally Posted by Road Fan View Post
how can you say a merkcx is midrange? these are high end, and deserve the best you can find reasonably.
I probably meant to say "midrange or better" or something to that effect. Note that it was early on Saturday morning. I barely remember posting.
Grand Bois is offline
Old 09-26-09, 04:44 PM
  #21
gomango
Senior Member

Join Date: Jul 2006
Location: STP
Posts: 15,160
Mentioned: 70 Post(s)
Tagged: 0 Thread(s)
Quoted: 798 Post(s)
Liked 159 Times in 105 Posts
Heh Dirtdrop, this is no big deal. Have a good day, and sorry I even bothered with the initial post.

P.S. I think I posted a couple of items on my company blog last night. After your post just now, I might need to review those late night posts.
__________________


Bikes and stuff

https://www.flickr.com/photos/36270004@N06/
gomango is offline
Old 09-26-09, 09:21 PM
  #22
JohnDThompson
Old fart

JohnDThompson's Avatar

Join Date: Nov 2004
Location: Appleton WI
Posts: 22,337

Bikes: Several, mostly not name brands.

Mentioned: 131 Post(s)
Tagged: 0 Thread(s)
Quoted: 2495 Post(s)
Liked 1,029 Times in 667 Posts
Originally Posted by miamijim View Post
If its a 27.0 I could file down the race. Right?
You need some way of ensuring that the race seat is concentric and coaxial with the steering axis; that's why crown race mills were invented.

They're very expensive, though, so don't bother trying to buy one for a one-off project. Take the fork to your LBS and have them mill it to ISO dimensions.
JohnDThompson is offline
Old 09-26-09, 10:34 PM
  #23
Charles Wahl
Disraeli Gears

Charles Wahl's Avatar

Join Date: Jul 2007
Location: NYC
Posts: 3,815
Mentioned: 19 Post(s)
Tagged: 0 Thread(s)
Quoted: 321 Post(s)
Liked 138 Times in 93 Posts
I recently put a Tange Falcon on a frame, and it's very pleasant-looking. Cartridge bearings. Downside is that I suspect they don't make it anymore -- I bought mine from VeloOrange, who no longer lists it; Harris sez "sorry all gone", and the only place I could find one now is Ben's in Milwaukee. $39. Stack about 35 mm. Standard 26.4/30.2 size, if that fits.

Charles Wahl is offline
Old 09-26-09, 10:42 PM
  #24
Panthers007
Great State of Varmint

Panthers007's Avatar

Join Date: Sep 2008
Location: Dante's Third Ring
Posts: 7,476
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Likes: 0
Liked 10 Times in 10 Posts
Originally Posted by cudak888 View Post
Tange Levin:



They're usually $35-40 or so. Trick is to find the NR knockoff model, though I'd be concerned about stack height. What size crown race?

-Kurt
+10

I've had my Tange Levin on my vintage PUCH since 1983. Overhauled yearly - it's still in perfect shape and never has caused me any problems. The worst it ever did was need a spacer. I put a Campy spacer on it. I'm sure this violates some law somewhere. But they coexist peaceably.
Panthers007 is offline
Old 09-27-09, 07:09 AM
  #25
Grand Bois
Senior Member

Grand Bois's Avatar

Join Date: Mar 2005
Location: Pinole, CA, USA
Posts: 17,415
Mentioned: 24 Post(s)
Tagged: 0 Thread(s)
Quoted: 436 Post(s)
Likes: 0
Liked 8 Times in 8 Posts
I think that Velo Orange Grand Cru is a beautiful piece at a bargain price, but maybe it's not suited to your Merckx. I've got one that's waiting for the right bike to come along. I love the split crown race! It snaps on with just finger pressure.
Grand Bois is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright 2021 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
