Heels strike panniers?

Reply Subscribe

Thread Tools

Search this Thread

11-02-10 | 04:55 PM

Capecodder

Thread Starter

Senior Member

Joined: Jul 2010

Posts: 1,995

Likes: 5

From: Somewhere Between The Beginning And The End

Heels strike panniers?

Well I was very excited when I picked up a pair of panniers today during my lunch hour till I got home. I installed them on the rear rack and thought, "that looks pretty good"..... Then I took it for a ride and that all changed. My heels hit the corners of the panniers and it drives me nuts. Is this how most of them are or is it just that these don't fit correctly? I might just return them and get a rack trunk.

11-02-10 | 05:05 PM

clasher

Senior Member

Joined: May 2009

Posts: 2,741

Likes: 151

From: Kitchener, ON

You need to get the rack farther back, or get a rack that goes farther back. I've been eyeing tubus logo for a hybrid -> touring conversion I'm doing.

11-02-10 | 05:05 PM

RavingManiac

Senior Member

Joined: Jun 2010

Posts: 530

Likes: 3

From: Maine

Bikes: 90 Raleigh Chill MTB, 92 Trek 1200, 2004 Trek 2300, 67 Sports, 70 Sports, 71 Philips, Lotus Challenger, 74 Super Course, Univega Gran Tourismo, Nishiki Seral

Me + Miyata 001..jpgCan they be repositioned a little further back on the rack? I moved mine, REI bags on a Blackburn rack, back as far as possible. Don't know but it could be my Miyata 210 has a little longer stays than your Shogun.

11-02-10 | 05:09 PM

illwafer

)) <> ((

Joined: Mar 2008

Posts: 2,409

Likes: 4

From: San Diego, CA

i cant say enough good things about the axiom streamliner rack. it basically works perfectly on every bike, even those without rack mounts.

11-02-10 | 05:18 PM

big chainring

Senior Member

Joined: Sep 2007

Posts: 6,944

Likes: 853

From: Wilmette, IL

WOW, I gotta get one of those.^

11-02-10 | 05:26 PM

BentLink

Senior Member

Joined: Jan 2010

Posts: 684

Likes: 2

From: Pennsyl-tuckey

Bikes: '86 Cannondale SR400, '86 Pugeot PX10, '92 Bianchi Axis, '95 Bianchi Campione d'Italia, '00 Fondriest X-Status, '08 Specialized Roubaix, '13 Cannondale CAADX

Yup, my big feet and long crank arms combined to give me some contact. I was able to move my panniers back behind a weld on my Cannondale rack. It's still mighty close, but no more interference.

11-02-10 | 06:26 PM

old's'cool

curmudgineer

Joined: Dec 2009

Posts: 4,417

Likes: 113

From: Chicago SW burbs

Bikes: 2 many 2 fit here

I have borderline heel strike issues with my bikes & panniers. I've been able to finesse them adequately by:

placing the panniers further back on the rack
positioning the rack higher up and/or further back, within its mounting constraints

The ultimate solution is a touring frame, with longer chainstays. That way the weight is better distributed, instead of overhanging the rear axle so much. The mounting lugs are nice to have also.

Last edited by old's'cool; 11-02-10 at 06:27 PM. Reason: punctuation

11-02-10 | 09:04 PM

JohnDThompson

Old fart

Joined: Nov 2004

Posts: 26,401

Likes: 5,333

From: Appleton WI

Bikes: Several, mostly not name brands.

Quote:

Originally Posted by Capecodder

Your frame looks to have fairly short chainstays. Most frames designed for panniers have chainstays of at least 43cm. Can you move the panniers further back on the rack?

You may also want to investigate other panniers with truncated corners to increase heel clearance.

11-03-10 | 12:45 AM

snarkypup

Senior Member

Joined: Aug 2010

Posts: 1,207

Likes: 0

From: Around Seattle

Bikes: 1969 Raleigh Sports: The Root Beer Bomber

Quote:

Originally Posted by illwafer

i cant say enough good things about the axiom streamliner rack. it basically works perfectly on every bike, even those without rack mounts.

Interesting. Does it feel sturdy? Folks on Amazon (the source for genius commentary, of course) have complained of it collapsing on their rear wheels.

11-03-10 | 03:06 PM

#10

illwafer

)) <> ((

Joined: Mar 2008

Posts: 2,409

Likes: 4

From: San Diego, CA

Quote:

Originally Posted by snarkypup

Interesting. Does it feel sturdy? Folks on Amazon (the source for genius commentary, of course) have complained of it collapsing on their rear wheels.

as sturdy as any other sub-$100 rack. i've used it for years commuting every day and it's still like new.

11-03-10 | 03:24 PM

#11

auchencrow

Senior Member

Joined: Apr 2009

Posts: 10,303

Likes: 60

From: Detroit

Quote:

Originally Posted by Capecodder

Hi CC !
I have a simple solution: Stop wearing heels.

__________________
- Auchen

11-03-10 | 03:34 PM

#12

dashuaigeh

grad stud.

Joined: Apr 2010

Posts: 674

Likes: 1

From: Houston, TX

Bikes: 1987 Schwinn Voyageur

another +1 on the axiom rack. used it for light loaded touring and its awesome. looks great too.

11-03-10 | 03:53 PM

#13

aixaix

car guy, recovering

Joined: Nov 2008

Posts: 1,255

Likes: 9

From: Mount Vernon, NY

Bikes: Olympia Competizione & Special Piuma, Frejus track circa 1958, Dahon Helios, many others

You might try moving the rack down the seat stays a bit. This will tilt the bags back as well as move rearward.

11-03-10 | 05:02 PM

#14

kknh3

Senior Member

Joined: Aug 2005

Posts: 211

Likes: 0

From: St. Charles, MO

Bikes: Schwinn High Plains, Trek 750 Multi-Track, Schwinn Passage, Schwinn High Sierra

I used a Jandd Expedition rack on my Trek 750 Multitrack to accommodate my size 12/13 feet. I works good with my panniers, although this pic shows it with my trunk rack.

11-03-10 | 05:25 PM

#15

gaucho777

Senior Member

Joined: Aug 2009

Posts: 7,723

Likes: 4,174

From: Berkeley, CA

Bikes: 72 Cilo Pacer, 72 Gitane GT, 72 Peugeot PX10, 73 Speedwell Ti,l, 75 Peugeot PR-10L, 80 Colnago Super, 81 Zinn, 85 ALAN Cross, 85 De Rosa Pro, 86 Look 753, 86 Look KG86, 89 Parkpre Team, 90 Parkpre Team MTB, 90 Merlin

If moving the rack back does not work, you might also consider the Tubus quick release adapter (a little pricey, but prob cheaper than a new rack):

https://www.thetouringstore.com/TUBUS...ONS%20PAGE.htm

Quick Release Rack Mounting Kit

The photos above are of a quick release mounting system that works with most of the Tubus racks. This adapter allows you to mount a rack on a bike without lower rack mounting eyelets, such as a race bike. In addition, it moves the rack toward the rear of the bike, greatly increasing heel clearance for panniers -- great for bikes with short chainstay lengths. The adapter consists of a longer quick release mechanism, and the curved stainless steel brackets that slip over the quick release skewer and attach to rack. $33.00 Set

__________________
-Randy

'72 Cilo Pacer (x2) • '72 Peugeot PX10 • ‘72 Gitane Gran Tourisme • '73 Speedwell Ti • '74 Motobecane Grand Jubile • '74 Peugeot UE-8 • ‘80 Colnago Super • ‘81 Univega Super Special • ‘82 Zinn • ‘84ish Mystery Custom • '85 A.L.A.N Cyclocross • '85 De Rosa Pro • '86 Look Equipe 753 • '86 Look KG86 • '89 Parkpre Team Road • '90 Parkpre Team MTB • '90 Merlin Ti

Avatar photo courtesy of jeffveloart.com, contact: contact: jeffnil8 (at) gmail.com.

11-03-10 | 06:16 PM

#16

old's'cool

curmudgineer

Joined: Dec 2009

Posts: 4,417

Likes: 113

From: Chicago SW burbs

Bikes: 2 many 2 fit here

Quote:

Originally Posted by illwafer

Quote:

Originally Posted by snarkypup
Interesting. Does it feel sturdy? Folks on Amazon (the source for genius commentary, of course) have complained of it collapsing on their rear wheels.

as sturdy as any other sub-$100 rack. i've used it for years commuting every day and it's still like new.

I see vertical stiffness and strength issues with that design that are not present with conventional designs that tie all the vertical struts directly to the dropout. YMMV

Last edited by old's'cool; 11-03-10 at 07:43 PM. Reason: fixed
