Adjustable stem?

Notices
Fitting Your Bike Are you confused about how you should fit a bike to your particular body dimensions? Have you been reading, found the terms Merxx or French Fit, and donít know what you need? Every style of riding is different- in how you fit the bike to you, and the sizing of the bike itself. Itís more than just measuring your height, reach and inseam. With the help of Bike Fitting, youíll be able to find the right fit for your frame size, style of riding, and your particular dimensions. Here yaí goÖ..the location for everything fit related.

Adjustable stem?

Old 10-30-20, 12:35 PM
  #1
SkipII
Member
Thread Starter

Join Date: Sep 2020
Posts: 27
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked 2 Times in 2 Posts
Adjustable stem?

I recall seeing somewhere on this forum a picture of a stem that was adjustable. It basically allowed you to move the stem up or down from a pivot point and lock it in.

I'm not sure how stable it might be but I'm interested to see if it might help me dial in what I need instead fo committing to a particular fixed stem.

Thanks.
SkipII is offline
Old 10-30-20, 02:23 PM
  #2
dabac
Senior Member

Join Date: Mar 2008
Posts: 8,314
Mentioned: 44 Post(s)
Tagged: 0 Thread(s)
Quoted: 958 Post(s)
Liked 128 Times in 99 Posts
And your question is?
Yes, there are adjustable stems. Both for quill stems and aheadset stems.
Most are angle-only. A select few are angle-and-reach.
They are generally seen as OK for fit testing purposes, but to be replaced ASAP with a fixed stem offering the desired rise and reach.
Me, Iím not so categorical.
Sure, I realize theyíre heavier than a fixed stem.
And Iíve seen a couple that have developed an annoying play during use.
But IME, the weight penalty overall isnít much to moan about.
And - If tightened correctly after adjustment - you need to put out some serious watts before the flex coming from being adjustable becomes a valid issue.
dabac is offline
Old 10-30-20, 03:57 PM
  #3
CargoDane
Banned.

Join Date: Oct 2020
Posts: 839

Bikes: Bullitt Milk Plus, Dahon Smooth Hound, Ti Omnium Cargo w/Rohloff

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 325 Post(s)
Liked 292 Times in 181 Posts
When I bought my last bike, I purchased some cheap stems and tried a few, along with different stem spacers to get it right. Then when I had it right, I bought a proper stem (one I'd be happy with) and then cut down the extra tubing afterwards. I kind of knew in which direction I'd go.
CargoDane is offline
Old 11-02-20, 03:23 PM
  #4
freeranger
Senior Member

freeranger's Avatar

Join Date: Jun 2005
Location: Kentucky
Posts: 1,775

Bikes: 06 Lemond Reno, 98 GT Timberline mtn.bike

Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 174 Post(s)
Liked 231 Times in 158 Posts
If I was wanting to see what angle was best for me, but knew what reach, I'd buy the cheapest adjustable and figure what angle I wanted, then buy a regular stem. I want something solid when it comes to steering. IF I was to use an adjustable (but don't think I would), from what I've read, the only one I might consider would be one from Ritchey: https://www.jensonusa.com/Ritchey-4-...20Group%20%231 The two bolt design for adjustment would seem to be much better than a single bolt.
freeranger is offline
Old 11-02-20, 03:42 PM
  #5
Clyde1820
Senior Member

Join Date: May 2014
Location: USA
Posts: 1,290
Mentioned: 7 Post(s)
Tagged: 0 Thread(s)
Quoted: 347 Post(s)
Liked 207 Times in 157 Posts
I've used an adjustable stem, previously. A Ritchey 4-axis adjustable (click @ Ritcheylogic.com); this one's an example of a stem for the AheadSet standard. Works fine. Take it apart, lock it down, and it's set. It's got big splines inside the unit that aren't going anywhere once you tighten the adjustment screw. Very solid. Indistinguishable from a typical non-adjustable stem, function-wise, other than it adjusts in angle. There are less-expensive adjustable stems made, but the Ritchey is a well-designed one.

As others have said, similar units are available out there for quill-type stems.

I've used it and kept it, in some cases. And I've used it to dial-in the fit, then swapped it for the correct stem (angle and length). Works fine, either way.

Am currently building-up a bike that has an uncut steerer on the fork, which extends a good foot above the head tube. Using numerous spacers, I'm able to raise the height of the existing stem to the height where the bars will result in "perfect" hand position. Once I've determined the right spot (for the hands), I'll get a stem with the appropriate angle and length (likely, shorter and much steeper), then cut off the "excess" from the steerer tube. (Right now, the length of the steerer tube is ludicrously tall, but that's only for testing/fitting purposes and temporary.)


Clyde1820 is offline
Likes For Clyde1820:
Old 11-02-20, 03:56 PM
  #6
SkipII
Member
Thread Starter

Join Date: Sep 2020
Posts: 27
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked 2 Times in 2 Posts
Originally Posted by freeranger View Post
If I was wanting to see what angle was best for me, but knew what reach, I'd buy the cheapest adjustable and figure what angle I wanted, then buy a regular stem. I want something solid when it comes to steering. IF I was to use an adjustable (but don't think I would), from what I've read, the only one I might consider would be one from Ritchey: https://www.jensonusa.com/Ritchey-4-...20Group%20%231 The two bolt design for adjustment would seem to be much better than a single bolt.
This is perfect. I swapped out the seat that works better. The current stem is only about 5 degrees so the Richey allows more than that -- and enough to likely get the fit I need. Thank you!
SkipII is offline
Old 11-03-20, 09:06 AM
  #7
Clyde1820
Senior Member

Join Date: May 2014
Location: USA
Posts: 1,290
Mentioned: 7 Post(s)
Tagged: 0 Thread(s)
Quoted: 347 Post(s)
Liked 207 Times in 157 Posts
Originally Posted by SkipII View Post
This is perfect. I swapped out the seat that works better. The current stem is only about 5 degrees so the Richey allows more than that -- and enough to likely get the fit I need. Thank you!
IIRC, the Ritchey can adjust to about a 55 degree angle. You just take off stem's "neck" from the stem's base, then reinstall so the splines lock up at a different angle, then tighten the bolt. Easily done, assuming the length of your cables allow that range of motion. Works well. Isn't going anywhere, once you reassemble and tighten down.
Clyde1820 is offline
