Possible to cram mudguards with this setup?

Notices
Touring Have a dream to ride a bike across your state, across the country, or around the world? Self-contained or fully supported? Trade ideas, adventures, and more in our bicycle touring forum.

Possible to cram mudguards with this setup?

Old 03-16-19, 04:05 PM
  #1
Rhyso
Junior Member
Thread Starter

Join Date: Nov 2012
Posts: 6
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Possible to cram mudguards with this setup?

Hi!

So I recently switched from 2.00 Marathon Plus Tours to some 2.35 Schwalbe Big Apples for my 26" Surly LHT.

Loving the Big Apples so far, just have one problem; I can't fit my old mudguards on anymore. Do mudguards even come in sizes that accomodate 2.35 tyres? Anyone with a similar setup have any recommendations? My old mudguards are 26" SKS Chromoplastic.

Thanks!
Rhyso is offline
Old 03-16-19, 08:50 PM
  #2
djb
Senior Member

Join Date: Jul 2010
Location: Montreal Canada
Posts: 11,456
Mentioned: 31 Post(s)
Tagged: 0 Thread(s)
Quoted: 2049 Post(s)
Liked 474 Times in 403 Posts
SKS in 26in come in different widths, I have the 55mm ones I think, I believe the next size is 65mm, but the issue here is the frame.
do some searches for max fender size the lht can take, I don't own one, but I suspect you are at the limit.
I have a friend who has the wider fenders on his bike, planned for 2.1in tires, and has fit in 2.5 in tires with those fenders, but again, it's not a LHT.
djb is online now
Old 03-16-19, 08:54 PM
  #3
djb
Senior Member

Join Date: Jul 2010
Location: Montreal Canada
Posts: 11,456
Mentioned: 31 Post(s)
Tagged: 0 Thread(s)
Quoted: 2049 Post(s)
Liked 474 Times in 403 Posts
The other thing with sks fenders is that the stays are cut to size, because of the enclosed attachment system, so even if you could raise your existing fenders, you may run out of stay length.

did you personally install them?
djb is online now
Old 03-16-19, 09:11 PM
  #4
chrisx
Senior Member

chrisx's Avatar

Join Date: Sep 2007
Posts: 924
Mentioned: 9 Post(s)
Tagged: 1 Thread(s)
Quoted: 406 Post(s)
Liked 8 Times in 8 Posts
Have you tried anything like this
https://www.sks-germany.com/en/produ...-26-27-5-zoll/


https://www.universalcycles.com/shop...58&category=79
https://www.universalcycles.com/shop...61&category=79

Clip on fenders could be your new friends.
https://www.universalcycles.com/shop...hp?category=79

I know this makes no since, at the moment. I use 29er clip on fenders on my 26er, and 26er clip on fenders on my 29er.

The 29er sees much rougher roads and bumps, so needs more clearance. The 26er sees some rainy roads in Washington, so I need more coverage.

I am good a breaking full coverage fenders, and, or I like the biggest tires I can fit on my bikes.




Originally Posted by Rhyso View Post
Hi!

So I recently switched from 2.00 Marathon Plus Tours to some 2.35 Schwalbe Big Apples for my 26" Surly LHT.

Loving the Big Apples so far, just have one problem; I can't fit my old mudguards on anymore. Do mudguards even come in sizes that accomodate 2.35 tyres? Anyone with a similar setup have any recommendations? My old mudguards are 26" SKS Chromoplastic.

Thanks!

Last edited by chrisx; 03-16-19 at 09:41 PM.
chrisx is offline
Old 03-17-19, 05:30 AM
  #5
Tourist in MSN
Senior Member

Join Date: Aug 2010
Location: Madison, WI
Posts: 8,074

Bikes: 1961 Ideor, 1994 Bridgestone MB-6, 2006 Airnimal Joey, 2009 Thorn Sherpa, 2013 Thorn Nomad MkII, 2015 VO Pass Hunter, 2017 Lynskey Backroad, 2017 Raleigh Gran Prix, Perfekt 3 Speed -age unknown, 1980s Bianchi Mixte on a trainer. Others are now gone.

Mentioned: 36 Post(s)
Tagged: 0 Thread(s)
Quoted: 2206 Post(s)
Likes: 0
Liked 478 Times in 391 Posts
Not a LHT, but I have 65mm fenders on one of my bikes with 57mm tires. Bought the fenders almost a decade ago on a clearance sale, Bontrager 26 inch.

I suspect your 2.35 tires would be too wide for the fenders that I use.

If you are running V brakes and if you put really big fenders over the 2.35 tires, you might have trouble fitting V brakes. I am using Tektro 857AL V brakes with 110 arm length to get the clearance I need.
Tourist in MSN is offline
Old 03-17-19, 07:51 AM
  #6
Leebo
Senior Member

Join Date: Aug 2009
Location: North of Boston
Posts: 5,721

Bikes: Kona Dawg, Surly 1x1, Karate Monkey, Rockhopper, Crosscheck , Burley Runabout,

Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 854 Post(s)
Liked 109 Times in 64 Posts
Try some plastic zip tied to the downtube and underneath the rear rack( if you have one) I like coroplast or vinyl siding.
Leebo is offline
Old 03-17-19, 10:36 AM
  #7
djb
Senior Member

Join Date: Jul 2010
Location: Montreal Canada
Posts: 11,456
Mentioned: 31 Post(s)
Tagged: 0 Thread(s)
Quoted: 2049 Post(s)
Liked 474 Times in 403 Posts

Originally Posted by Leebo View Post
Try some plastic zip tied to the downtube and underneath the rear rack( if you have one) I like coroplast or vinyl siding.
I have had two of these ziptied to under the rear rack, and then down the seattube for probably 15 years now, they do a fine job, stop crud from going too much over my fd, and work fine for stopping getting a dirty back.

being flexible, they are super tough, can be bent here and there, and it just comes back, and very light also.

on the front, I use one of those removable short mtb fenders, made for front suspension.

anyway, good point lee, there are other options out there, not as good as a real fender, but not bad.
djb is online now
Old 03-17-19, 07:33 PM
  #8
fietsbob
Banned

Join Date: Jun 2010
Location: NW,Oregon Coast
Posts: 43,599

Bikes: 8

Mentioned: 197 Post(s)
Tagged: 0 Thread(s)
Quoted: 7607 Post(s)
Liked 1,311 Times in 823 Posts
cut it to be on either side of the lowest point .. on my bike, it was the fork crown,

so a through bolt holds the 2 separate parts...




..
fietsbob is offline
Old 03-19-19, 12:11 AM
  #9
Trevtassie
Senior Member

Join Date: Jun 2015
Location: Down Under
Posts: 1,891

Bikes: A steel framed 26" off road tourer from a manufacturer who thinks they are cool. Giant Anthem. Trek 720 Multiroad pub bike. 10 kids bikes all under 20". Assorted waifs and unfinished projects.

Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 749 Post(s)
Liked 606 Times in 326 Posts
The widest SKS fenders cover my 2.5 Extraterrestrials so yeah they are wide, But that is on a Troll, so there's heaps of room between the stays.
