Big Dummy rim question
#1
Thread Starter
Share the road.

Joined: Jul 2008
Posts: 1,256
Likes: 45
From: Marysville, CA
Bikes: 1992 Rocky Mountain Fusion, Yuba Mundo, Specialized Venge
Big Dummy rim question
I just bought some Black Alex DX-32 Rim: 26", 32H for my Big Dummy and I was wondering if they were going to fit my Fat Franks. Or did I just make a dumb purchase?
#3
Gear Hub fan
Joined: Nov 2008
Posts: 2,829
Likes: 2
From: Reno, NV
Bikes: Civia Hyland Rohloff, Swobo Dixon, Colnago, Univega
Unless the Alex listed dimension is outside width. The Schwalbe recommendations are for rim width between the beads inside the rim which many rim makers do not list. Normally it is about 5 to 6mm less than the outside rim width.
__________________
Gear Hubs Owned: Rohloff disc brake, SRAM iM9 disc brake, SRAM P5 freewheel, Sachs Torpedo 3 speed freewheel, NuVinci CVT, Shimano Alfine SG S-501, Sturmey Archer S5-2 Alloy. Other: 83 Colnago Super Record, Univega Via De Oro
Visit and join the Yahoo Geared Hub Bikes group for support and links.
https://groups.yahoo.com/group/Geared_hub_bikes/
Gear Hubs Owned: Rohloff disc brake, SRAM iM9 disc brake, SRAM P5 freewheel, Sachs Torpedo 3 speed freewheel, NuVinci CVT, Shimano Alfine SG S-501, Sturmey Archer S5-2 Alloy. Other: 83 Colnago Super Record, Univega Via De Oro
Visit and join the Yahoo Geared Hub Bikes group for support and links.
https://groups.yahoo.com/group/Geared_hub_bikes/
#5
Gear Hub fan
Joined: Nov 2008
Posts: 2,829
Likes: 2
From: Reno, NV
Bikes: Civia Hyland Rohloff, Swobo Dixon, Colnago, Univega
Measure the inside width of the rim. Theoretically the tire width should be within 1.4 and 2.0 times the rim inside width per ISO standards. This is frequently exceeded even by bike manufacturers who fit wider tires than ISO recommends for a particular rim width. For some of the really wide tires it is hard to find rims as wide as ISO recommends.
I would not expect a problem.
I would not expect a problem.
__________________
Gear Hubs Owned: Rohloff disc brake, SRAM iM9 disc brake, SRAM P5 freewheel, Sachs Torpedo 3 speed freewheel, NuVinci CVT, Shimano Alfine SG S-501, Sturmey Archer S5-2 Alloy. Other: 83 Colnago Super Record, Univega Via De Oro
Visit and join the Yahoo Geared Hub Bikes group for support and links.
https://groups.yahoo.com/group/Geared_hub_bikes/
Gear Hubs Owned: Rohloff disc brake, SRAM iM9 disc brake, SRAM P5 freewheel, Sachs Torpedo 3 speed freewheel, NuVinci CVT, Shimano Alfine SG S-501, Sturmey Archer S5-2 Alloy. Other: 83 Colnago Super Record, Univega Via De Oro
Visit and join the Yahoo Geared Hub Bikes group for support and links.
https://groups.yahoo.com/group/Geared_hub_bikes/
#7
cyclopath
Joined: Apr 2006
Posts: 5,264
Likes: 6
From: Victoria, BC
Bikes: Surly Krampus, Surly Straggler, Pivot Mach 6, Bike Friday Tikit, Bike Friday Tandem, Santa Cruz Nomad
I've mounted fatter than recommended tires on rims and had no problems...the issue is really that really wide tires on a narrow rim can exert a lot of force if inflated to high pressure which can damage the rim or blow the tire out. Of course you don't need much pressure in a high volume tire so unless you make a mistake filling the tire with air this isn't much of a concern. You can also have issues if you corner hard with very low pressure, but again that's not going to happen unless you really under inflate your tires.
#8
Thread Starter
Share the road.

Joined: Jul 2008
Posts: 1,256
Likes: 45
From: Marysville, CA
Bikes: 1992 Rocky Mountain Fusion, Yuba Mundo, Specialized Venge
I bought the above mentioned rims because I didn't like the way my fat frank's looked or performed on my Mavic 717's. I thought with a wider rim it would be better.
#9
Senior Member

Joined: Mar 2004
Posts: 184
Likes: 0
Those rims are plenty wide, They'll be fine. I run big apple 60mm(2.3") tires ghetto tubeless on a mavic ex325 with no problems. 32mm outside width. I find 1.1 to 2.2x the rim's outer width is a good rule of thumb for tires.
