1973 Azuki! yeah, yeah...
#1
Member
Thread Starter
Join Date: Jan 2014
Posts: 34
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
1973 Azuki! yeah, yeah...
So I saw this bike on CL and she looked great all yellow and stuff. Thanks to this forum and other references, I have determined her to have matching Shimano components from 1972/73. These being Eagle front and Thunder Bird rear derailleurs, 333 W round stem shifters, and period UKAIRIM rims. Dia-Compe brakes levers and not sure of brand cantilever brakes (looks like SJ or SIJ).
Couple questions I haven't nailed down yet are what type of metal would the frame be made of, anyone seen one of these type of spoke protectors, aluminum rims, and what would you pay for her in this condition?
Seatpost has B187 stamped into it.
Thanks!
Couple questions I haven't nailed down yet are what type of metal would the frame be made of, anyone seen one of these type of spoke protectors, aluminum rims, and what would you pay for her in this condition?
Seatpost has B187 stamped into it.
Thanks!
Last edited by joe bag o donut; 02-01-14 at 04:29 PM.
#2
Senior Member
Looks pretty low end. Rims are steel. Frame is probably hi-ten. Crankset is either installed wrong or the cotters are completely shot (or likely both). Looks like it was probably re-done by someone who didn't know what they were doing.
#3
Vello Kombi, baby
Join Date: Dec 2002
Location: Je suis ici
Posts: 5,188
Bikes: 1973 Eisentraut; 1970s Richard Sachs; 1978 Alfio Bonnano; 1967 Peugeot PX10
Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 80 Post(s)
Likes: 0
Liked 14 Times
in
13 Posts
It's likely some form of hi-ten (high tensile) steel, pretty basic stuff.
Worth? To me, somewhere around 50$. On Craigslist, in ready to ride condition, 125/150$ when the students here come back in session, about 100$ otherwise.
+1 on the shot/poorly installed cotter.
Worth? To me, somewhere around 50$. On Craigslist, in ready to ride condition, 125/150$ when the students here come back in session, about 100$ otherwise.
+1 on the shot/poorly installed cotter.
__________________
"It's always darkest right before it goes completely black"
Waste your money! Buy my comic book!
"It's always darkest right before it goes completely black"
Waste your money! Buy my comic book!
#5
Vello Kombi, baby
Join Date: Dec 2002
Location: Je suis ici
Posts: 5,188
Bikes: 1973 Eisentraut; 1970s Richard Sachs; 1978 Alfio Bonnano; 1967 Peugeot PX10
Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 80 Post(s)
Likes: 0
Liked 14 Times
in
13 Posts
Note how the crank arms don't line up with one another. This is a dead hint the cotter is either loose, shot, or poorly installed. Can't tell which without taking it apart, really.
The cranks should be much more in line:
The cranks should be much more in line:
__________________
"It's always darkest right before it goes completely black"
Waste your money! Buy my comic book!
"It's always darkest right before it goes completely black"
Waste your money! Buy my comic book!
#6
Member
Thread Starter
Join Date: Jan 2014
Posts: 34
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
That explains the loose crank arm!
Google brought me the forum's advice from 2004. Tried it and the cranks line up with no looseness!
"After adjusting the bottom bracket, if you think you need to tighten the cotter pins, try this method which requires no special tools. Take a hammer and an open-end wrench that will fit the nut on the cotter pin. Firmly tap the non-nutted side of the cotter pin and at the same time tighten the nut when you feel that the nut can turn. Repeat firm tapping until it appears that you are no longer able to tighten the nut any further. A word of caution: do not "reef" on the nut since it will strip out easily. In other words, do not apply excessive force as you tighten the nut." -Tom Pedale
Google brought me the forum's advice from 2004. Tried it and the cranks line up with no looseness!
"After adjusting the bottom bracket, if you think you need to tighten the cotter pins, try this method which requires no special tools. Take a hammer and an open-end wrench that will fit the nut on the cotter pin. Firmly tap the non-nutted side of the cotter pin and at the same time tighten the nut when you feel that the nut can turn. Repeat firm tapping until it appears that you are no longer able to tighten the nut any further. A word of caution: do not "reef" on the nut since it will strip out easily. In other words, do not apply excessive force as you tighten the nut." -Tom Pedale
#7
Senior Member
Join Date: Oct 2011
Location: Fairplay Co
Posts: 9,519
Bikes: Current 79 Nishiki Custum Sport, Jeunet 620, notable previous bikes P.K. Ripper loop tail, Kawahara Laser Lite, Paramount Track full chrome, Raliegh Internatioanl, Motobecan Super Mirage. 59 Crown royak 3 speed
Mentioned: 26 Post(s)
Tagged: 1 Thread(s)
Quoted: 790 Post(s)
Liked 1,767 Times
in
635 Posts
Looks to have one of the cotter pins installed backwards upside down causing the crank to be at wrong angle. In Current shape only a $50 sort out he crank issues about $125 if the rest of the bike is good.
#8
Constant tinkerer
Frame is hi-ten at best, might even be gas-pipe though. I seriously doubt I could sell that bike for $100. And if I did I'd feel like I ripped off the person...
My price would be $75 max. Considering the bunged crank, $20 max. I don't see any parts that have value.
Edit: actually, looks like they put new Continental Ultra Sport tires on there. So if you have a 27" wheelset in need of tires you could harvest them. Those are nice tires.
My price would be $75 max. Considering the bunged crank, $20 max. I don't see any parts that have value.
Edit: actually, looks like they put new Continental Ultra Sport tires on there. So if you have a 27" wheelset in need of tires you could harvest them. Those are nice tires.
#9
Senior Member
I don't know why but for whatever reasons I like the shifters - if you decide to part out you may get some coin for them (if I was building something funky with gears I'd totally use them)
#10
Senior Member
Join Date: Mar 2012
Location: Minnesota
Posts: 1,968
Bikes: '09 Trek 2.1 * '75 Sekine * 2010 Raleigh Talus 8.0 * '90 Giant Mtb * Raleigh M20 * Fuji Nevada mtb
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
I'm digging the shifters though....
__________________
FB4K - Every October we wrench on donated bikes. Every December, a few thousand kids get bikes for Christmas. For many, it is their first bike, ever. Every bike, new and used, was donated, built, cleaned and repaired. Check us out on FaceBook: FB4K.
Disclaimer: 99% of what I know about cycling I learned on BF. That would make, ummm, 1% experience. And a lot of posts.
FB4K - Every October we wrench on donated bikes. Every December, a few thousand kids get bikes for Christmas. For many, it is their first bike, ever. Every bike, new and used, was donated, built, cleaned and repaired. Check us out on FaceBook: FB4K.
Disclaimer: 99% of what I know about cycling I learned on BF. That would make, ummm, 1% experience. And a lot of posts.
#11
Senior Member
Join Date: Oct 2011
Location: Fairplay Co
Posts: 9,519
Bikes: Current 79 Nishiki Custum Sport, Jeunet 620, notable previous bikes P.K. Ripper loop tail, Kawahara Laser Lite, Paramount Track full chrome, Raliegh Internatioanl, Motobecan Super Mirage. 59 Crown royak 3 speed
Mentioned: 26 Post(s)
Tagged: 1 Thread(s)
Quoted: 790 Post(s)
Liked 1,767 Times
in
635 Posts
Frame is hi-ten at best, might even be gas-pipe though. I seriously doubt I could sell that bike for $100. And if I did I'd feel like I ripped off the person...
My price would be $75 max. Considering the bunged crank, $20 max. I don't see any parts that have value.
Edit: actually, looks like they put new Continental Ultra Sport tires on there. So if you have a 27" wheelset in need of tires you could harvest them. Those are nice tires.
My price would be $75 max. Considering the bunged crank, $20 max. I don't see any parts that have value.
Edit: actually, looks like they put new Continental Ultra Sport tires on there. So if you have a 27" wheelset in need of tires you could harvest them. Those are nice tires.
