Bolt removal
11-17-16 | 04:50 PM
#2
Senior Member
Joined: Nov 2011
Posts: 7,951
Likes: 688
From: Port Angeles, WA
Bikes: A green one, "Ragleigh," or something.
Looks like you need a special tool that holds those two slots on the backing nut, to unscrew the mounting bolt from it. I've got the same derailleur with the same problem; just haven't got around to trying to fix it.
__________________
● 1971 Grandis SL ● 1972 Lambert Grand Prix frankenbike ● 1972 Raleigh Super Course fixie ● 1973 Nishiki Semi-Pro ● 1979 Motobecane Grand Jubile ●1980 Apollo "Legnano" ● 1984 Peugeot Vagabond ● 1985 Shogun Prairie Breaker ● 1986 Merckx Super Corsa ● 1987 Schwinn Tempo ● 1988 Schwinn Voyageur ● 1989 Bottechia Team ADR replica ● 1990 Cannondale ST600 ● 1993 Technium RT600 ● 1996 Kona Lava Dome ●
● 1971 Grandis SL ● 1972 Lambert Grand Prix frankenbike ● 1972 Raleigh Super Course fixie ● 1973 Nishiki Semi-Pro ● 1979 Motobecane Grand Jubile ●1980 Apollo "Legnano" ● 1984 Peugeot Vagabond ● 1985 Shogun Prairie Breaker ● 1986 Merckx Super Corsa ● 1987 Schwinn Tempo ● 1988 Schwinn Voyageur ● 1989 Bottechia Team ADR replica ● 1990 Cannondale ST600 ● 1993 Technium RT600 ● 1996 Kona Lava Dome ●
11-17-16 | 04:58 PM
#4
Senior Member
Joined: Apr 2009
Posts: 154
Likes: 61
Bikes: '84 specialized expedition, '87 specialized sirrus, '84 specialized stumpjumper sport
A Park Tool pin spanner will suffice unless the nut is really stuck on there, I've used one successfully for this exact job:
Pin Spanner | Park Tool
Pin Spanner | Park Tool
11-17-16 | 04:58 PM
#5
Senior Member
Joined: Nov 2013
Posts: 1,536
Likes: 675
From: Big Apple
Bikes: yes
Just use a pin spanner, or the opened end of a needle nose pliers, to hold the bushing nut slots and turn the bolt on the front with a 6mm allen key.
Last edited by Vintage_Cyclist; 11-17-16 at 05:20 PM.
11-17-16 | 06:15 PM
#6
Senior Member
Joined: Oct 2015
Posts: 16,150
Likes: 9,531
From: PDX
Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2
11-17-16 | 07:02 PM
#7
Senior Member
Joined: Nov 2011
Posts: 7,951
Likes: 688
From: Port Angeles, WA
Bikes: A green one, "Ragleigh," or something.
Or, mount the 6mm hex in the vise, and work from the other end.
That's what I did when I made this tool from some scrap, about 15 minutes ago. (Love my Dremel!)
We'll call this Suntour Special Backing Nut Remover #cvman-RD-001
[MENTION=433911]primo123[/MENTION], let me know if you'd like to borrow it, I can mail it to you. But you (and I, too) should just get a pin spanner like everyone else says to.
_____________
NOW that I've got my mounting bolt removed, de-gunked, re-lubed and back to gather, can someone tell me how you're supposed to mount this thing tight enough to stay on a dropout RD hanger and still have it pivot around the mounting bolt? The only way I can see it working is with a backing nut on the other side of a thin claw hanger (which it came with). Is this one not designed to work on an integrated hanger?
That's what I did when I made this tool from some scrap, about 15 minutes ago. (Love my Dremel!)
We'll call this Suntour Special Backing Nut Remover #cvman-RD-001
[MENTION=433911]primo123[/MENTION], let me know if you'd like to borrow it, I can mail it to you. But you (and I, too) should just get a pin spanner like everyone else says to.
_____________
NOW that I've got my mounting bolt removed, de-gunked, re-lubed and back to gather, can someone tell me how you're supposed to mount this thing tight enough to stay on a dropout RD hanger and still have it pivot around the mounting bolt? The only way I can see it working is with a backing nut on the other side of a thin claw hanger (which it came with). Is this one not designed to work on an integrated hanger?
__________________
● 1971 Grandis SL ● 1972 Lambert Grand Prix frankenbike ● 1972 Raleigh Super Course fixie ● 1973 Nishiki Semi-Pro ● 1979 Motobecane Grand Jubile ●1980 Apollo "Legnano" ● 1984 Peugeot Vagabond ● 1985 Shogun Prairie Breaker ● 1986 Merckx Super Corsa ● 1987 Schwinn Tempo ● 1988 Schwinn Voyageur ● 1989 Bottechia Team ADR replica ● 1990 Cannondale ST600 ● 1993 Technium RT600 ● 1996 Kona Lava Dome ●
● 1971 Grandis SL ● 1972 Lambert Grand Prix frankenbike ● 1972 Raleigh Super Course fixie ● 1973 Nishiki Semi-Pro ● 1979 Motobecane Grand Jubile ●1980 Apollo "Legnano" ● 1984 Peugeot Vagabond ● 1985 Shogun Prairie Breaker ● 1986 Merckx Super Corsa ● 1987 Schwinn Tempo ● 1988 Schwinn Voyageur ● 1989 Bottechia Team ADR replica ● 1990 Cannondale ST600 ● 1993 Technium RT600 ● 1996 Kona Lava Dome ●
Last edited by Lascauxcaveman; 11-17-16 at 07:10 PM.
11-18-16 | 07:20 AM
#8
Senior Member
Joined: Jan 2013
Posts: 3,149
Likes: 883
Bikes: too many sparkly Italians, some sweet Americans and a couple interesting Japanese
Or, mount the 6mm hex in the vise, and work from the other end.
That's what I did when I made this tool from some scrap, about 15 minutes ago. (Love my Dremel!)
We'll call this Suntour Special Backing Nut Remover #cvman-RD-001
[MENTION=433911]primo123[/MENTION], let me know if you'd like to borrow it, I can mail it to you. But you (and I, too) should just get a pin spanner like everyone else says to.
_____________
NOW that I've got my mounting bolt removed, de-gunked, re-lubed and back to gather, can someone tell me how you're supposed to mount this thing tight enough to stay on a dropout RD hanger and still have it pivot around the mounting bolt? The only way I can see it working is with a backing nut on the other side of a thin claw hanger (which it came with). Is this one not designed to work on an integrated hanger?
That's what I did when I made this tool from some scrap, about 15 minutes ago. (Love my Dremel!)
We'll call this Suntour Special Backing Nut Remover #cvman-RD-001
[MENTION=433911]primo123[/MENTION], let me know if you'd like to borrow it, I can mail it to you. But you (and I, too) should just get a pin spanner like everyone else says to.
_____________
NOW that I've got my mounting bolt removed, de-gunked, re-lubed and back to gather, can someone tell me how you're supposed to mount this thing tight enough to stay on a dropout RD hanger and still have it pivot around the mounting bolt? The only way I can see it working is with a backing nut on the other side of a thin claw hanger (which it came with). Is this one not designed to work on an integrated hanger?
