Cinelli Super Corsa
Hi to everyone!
I would like to know your opinion about this Cinelli Super Corsa, re-painted without chrome parts, and with a mix of components: Akron stem, universal brakes , campagnolo shifters,campagnolo sr? headset, campagnolo gran sport rear derrailleur and crankset,campagnolo high-flange hubs,and 3ttt saddle,that is all i know.
Thank you very much in advance!
Regards from Spain.
First photos are older, the last one are recent.







I would like to know your opinion about this Cinelli Super Corsa, re-painted without chrome parts, and with a mix of components: Akron stem, universal brakes , campagnolo shifters,campagnolo sr? headset, campagnolo gran sport rear derrailleur and crankset,campagnolo high-flange hubs,and 3ttt saddle,that is all i know.
Thank you very much in advance!
Regards from Spain.
First photos are older, the last one are recent.







#2
Senior Member




Joined: Oct 2015
Posts: 16,174
Likes: 9,549
From: PDX
Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2
Same thing we think about all SC's, awesome, cool as heck, love em. Nice specimen you have there.
#4
Senior Member


Joined: Jun 2006
Posts: 21,861
Likes: 3,748
Plenty there to like.
Plenty to hold back the value, that cuts both ways.
I would strip the paint right off, I just don't like brown metallic and I even own one brown bike but it was such a good deal I could not pass.
Plenty to hold back the value, that cuts both ways.
I would strip the paint right off, I just don't like brown metallic and I even own one brown bike but it was such a good deal I could not pass.
#5
I would strip it too. But don't powder coat it. Get it the paint job it deserves in a Factory colour for the year of the bike.
#7
Senior Member




Joined: Oct 2015
Posts: 16,174
Likes: 9,549
From: PDX
Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2
Looks like the right fork crown and I think I see the right seat cluster.
#8
Phyllo-buster


Joined: Jan 2010
Posts: 9,276
Likes: 2,698
From: Nova Scotia
Bikes: roadsters, club bikes, fixed and classic
Maybe it has the wider 73mm BB? It may be older than you think. I know the serial number database is a mess but maybe [MENTION=333224]juvela[/MENTION] can shine some light? The headbadge appears to be brass so at least early 70's?
#9
Senior Member


Joined: Aug 2009
Posts: 7,723
Likes: 4,174
From: Berkeley, CA
Bikes: 72 Cilo Pacer, 72 Gitane GT, 72 Peugeot PX10, 73 Speedwell Ti,l, 75 Peugeot PR-10L, 80 Colnago Super, 81 Zinn, 85 ALAN Cross, 85 De Rosa Pro, 86 Look 753, 86 Look KG86, 89 Parkpre Team, 90 Parkpre Team MTB, 90 Merlin
Why is the Cinelli-badged stem stamped made in Spain? Cinelli didnt make any stems in Spain, did they?
#10
Senior Member




Joined: Oct 2015
Posts: 16,174
Likes: 9,549
From: PDX
Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2
#11
Senior Member

Joined: Aug 2011
Posts: 22,676
Likes: 2,643
From: CID
Bikes: 1991 Bianchi Eros, 1964 Armstrong, 1988 Diamondback Ascent, 1988 Bianchi Premio, 1987 Bianchi Sport SX, 1980s Raleigh mixte (hers), All-City Space Horse (hers)
Velobase says that an "Akront" made stems and other parts in Spain: VeloBase.com - View Brand
#12
Senior Member




Joined: Oct 2015
Posts: 16,174
Likes: 9,549
From: PDX
Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2
That's just a sticker, right?
Velobase says that an "Akront" made stems and other parts in Spain: VeloBase.com - View Brand
Velobase says that an "Akront" made stems and other parts in Spain: VeloBase.com - View Brand
#13
Crawlin' up, flyin' down


Joined: Jan 2006
Posts: 6,761
Likes: 4,415
From: Democratic Peoples' Republic of Berkeley
Bikes: 1967 Paramount; 1982-ish Ron Cooper; 1978 Eisentraut "A"; two mid-1960s Cinelli Speciale Corsas; and others in various stages of non-rideability.
Leaving aside the somewhat odd melange of component and focusing solely on the frame, I see some tantalizing clues and have some questions.
In enlarging the photos, the head lugs appear to be the "wolf's ear" kind. Those were phased out c.1960. Close-up photos are needed to confirm this, as the absence of chrome on thos lugs makes it harder to see.
In enlarging the left side bottom bracket photo, it does not look like it has an oil port hole. That would be inconsistent with the wolf's ear lugs. Again, close-up photos needed. Also needed are photos of the underside of the bottom bracket to see if the drain port is there.
The fork crown looks about right, albeit without chrome.
The seat cluster looks more or less correct, but again, close-up photos are needed to confirm. And again, the absence of chrome makes it harder to tell from the photos provided.
So, color me somewhat confused
. The head lugs say 1960 or earlier, the bottom bracket says 1965ish or later, the absence of chrome says it was most likely repainted, and the crooked rainbow stripe on the seat tube (good eye, [MENTION=131875]andy k[/MENTION]) says the decals are most likely replacements, too.
I would also like to see a photo of the serial number on the bottom bracket, not because Cinelli serial numbers of that time are any help in dating the frame (they aren't), but because the format and placement of the serial number would help answer the "Cinelli, yes or no?" question. Similarly, I would like to know the seat post diameter - that is about as good a "rule of thumb" clue as there is.
My gut says it is a Cinelli Speciale Corsa that has non-original paint and non-original decals, but with the inconsistencies noted above, I could be convinced otherwise (a 26.8mm seat post would do it, for example).
In enlarging the photos, the head lugs appear to be the "wolf's ear" kind. Those were phased out c.1960. Close-up photos are needed to confirm this, as the absence of chrome on thos lugs makes it harder to see.
In enlarging the left side bottom bracket photo, it does not look like it has an oil port hole. That would be inconsistent with the wolf's ear lugs. Again, close-up photos needed. Also needed are photos of the underside of the bottom bracket to see if the drain port is there.
The fork crown looks about right, albeit without chrome.
The seat cluster looks more or less correct, but again, close-up photos are needed to confirm. And again, the absence of chrome makes it harder to tell from the photos provided.
So, color me somewhat confused
. The head lugs say 1960 or earlier, the bottom bracket says 1965ish or later, the absence of chrome says it was most likely repainted, and the crooked rainbow stripe on the seat tube (good eye, [MENTION=131875]andy k[/MENTION]) says the decals are most likely replacements, too.I would also like to see a photo of the serial number on the bottom bracket, not because Cinelli serial numbers of that time are any help in dating the frame (they aren't), but because the format and placement of the serial number would help answer the "Cinelli, yes or no?" question. Similarly, I would like to know the seat post diameter - that is about as good a "rule of thumb" clue as there is.
My gut says it is a Cinelli Speciale Corsa that has non-original paint and non-original decals, but with the inconsistencies noted above, I could be convinced otherwise (a 26.8mm seat post would do it, for example).
__________________
"I'm in shape -- round is a shape." Andy Rooney
"I'm in shape -- round is a shape." Andy Rooney
#14
Senior Member




Joined: Oct 2015
Posts: 16,174
Likes: 9,549
From: PDX
Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2
Should be 70 or 74mm, mine is 74, oil port, drain, no wolfs ear, no chrome, supposed to be a 1960.
Last edited by merziac; 06-06-18 at 09:07 AM.
#15
Thread Starter
Member
Joined: Jan 2016
Posts: 30
Likes: 0
From: Spain
This was itīs previous condition if it can helps, I donīt have more photos because i havenīt bought it yet, but itīs right, it has been repainted with new stickers. Iīm not a specialist on cinelli, but in my opinion i think itīs a supercorsa.














Last edited by ogx; 06-06-18 at 03:29 AM.
#16
Phyllo-buster


Joined: Jan 2010
Posts: 9,276
Likes: 2,698
From: Nova Scotia
Bikes: roadsters, club bikes, fixed and classic
#20
Senior Member

Joined: Apr 2005
Posts: 17,196
Likes: 761
From: Ann Arbor, MI
Bikes: 1980 Masi, 1984 Mondonico, 1984 Trek 610, 1980 Woodrup Giro, 2005 Mondonico Futura Leggera ELOS, 1967 PX10E, 1971 Peugeot UO-8
I think the original steel crank, bottom bracket parts, and pedals are significant clues. If the seller still has them, perhaps he can throw them in.
Another point: the headset on the rebuild is Record, not Super Record. The Record headset was the absolute best/smoothest one available (IMO) until the Super Record came out. The Super Record was absolutely not contemporary with that frame.
The key outward difference is that the Super Record was alloy, not chromed steel.
If the races of your Record are in good condition, it will last most of your lifetime if you overhaul it once a year or after a major rain ride. Same for all your other high end bearings on that bike. Very good quality materials and design, but usually not much attention was paid to gaskets or seals to keep water out. In some cased they had labyrinth seals to reduce water intrusion, but they don't do the whole job.
Overall, my guess is that it is a Cinelli and more likely to be a SC than a Model B or Riviera. Based on the cotter-pin crank, it might be from the 1950s or up to the mid-1960s. Steel cotter-pin cranks were used in serious professional racing into the '60s, because teams were worried that alloy cranks were too new and unproven. It is NOT a sign of a mid-range or low-range bike.
The stem could have been sourced through any of a number of channels for the rebuild. The original one looks to have an oval logo on the front of the handlebar clamp, which could have been an original Cinelli. If the bike was originally supplied with a Campagnolo rear derailleur, it was most likely a Gran Sport or a Record, not a Nuovo Record.
#23
Thread Starter
Member
Joined: Jan 2016
Posts: 30
Likes: 0
From: Spain
Interesting, those could be early 60's components according to Velobase. So perhaps the frame was ordered and built with all Spanish equipment.
Which groupset is the right one, campagnolo record?
#25
Thread Starter
Member
Joined: Jan 2016
Posts: 30
Likes: 0
From: Spain
Really i like it and the price is good,itīs a supercorsa on my size, and painting with a color that i like. The worst are no chrome lugs and the groupset, although this one can be solved well.
