Dimpling / Relieving Chainstays to allow for wider tires

Search
Notices
Framebuilders Thinking about a custom frame? Lugged vs Fillet Brazed. Different Frame materials? Newvex or Pacenti Lugs? why get a custom Road, Mountain, or Track Frame? Got a question about framebuilding? Lets discuss framebuilding at it's finest.

Dimpling / Relieving Chainstays to allow for wider tires

Thread Tools

Search this Thread

Old 10-30-12 | 04:10 PM
  #1
4Rings6Stars's Avatar
Thread Starter
Seņor Member

Joined: Jul 2009
Posts: 1,637
Likes: 3
From: Boston Burbs

Bikes: Bedford, IF, Hampsten, DeSalvo, Intense Carbine 27.5, Raleigh Sports, Bianchi C.u.S.S, Soma DC Disc, Bill Boston Tandem

Dimpling / Relieving Chainstays to allow for wider tires

I'm considering buying a steel cross frame, but hesitant because the rear will only accept a true 30mm wide tire. (I won't be racing, not concerned with UCI rules)

The seller tells me that there is ample clearance at the rear of the seat tube and between the seatstays to allow for much wider tires.

Would it be possible (without framebuilding/specialty tools---I just have basic household stuff) to dimple each chainstay about 2-3mm? I'm not too concerned with damaging the paint on the inside of the stays but don't want to do any structural damage or screw up the alignment.

If possible, any suggestions for how I should go about it?

4Rings6Stars is offline
Reply
Old 10-30-12 | 04:52 PM
  #2
Randomhead

Joined: Aug 2008
Posts: 25,930
Likes: 4,825
From: Happy Valley, Pennsylvania
you put a shaped wooden block in a vise with the frame to form the dimple. On the outside, you use a wooden block with a channel cut in it the shape of the chainstay

You can always bet that Alex Wetmore has done whatever you want to do, see this post

Last edited by unterhausen; 10-30-12 at 04:55 PM.
unterhausen is offline
Reply
Old 10-30-12 | 07:45 PM
  #3
Senior Member

Joined: Jul 2011
Posts: 2,441
Likes: 4
Is that the frame? It has carbon stays, you can't dimple them. It does look ample though.
MassiveD is offline
Reply
Old 10-30-12 | 08:00 PM
  #4
4Rings6Stars's Avatar
Thread Starter
Seņor Member

Joined: Jul 2009
Posts: 1,637
Likes: 3
From: Boston Burbs

Bikes: Bedford, IF, Hampsten, DeSalvo, Intense Carbine 27.5, Raleigh Sports, Bianchi C.u.S.S, Soma DC Disc, Bill Boston Tandem

Originally Posted by MassiveD
Is that the frame? It has carbon stays, you can't dimple them. It does look ample though.
Chainstays are steel. I know I can't dimple carbon. Clearance is not ample.
4Rings6Stars is offline
Reply
Old 10-30-12 | 09:59 PM
  #5
Andrew R Stewart's Avatar
Senior Member
Titanium Club Membership
10 Anniversary

Joined: Feb 2012
Posts: 19,379
Likes: 5,524
From: Rochester, NY

Bikes: Stewart S&S coupled sport tourer, Stewart Sunday light, Stewart Commuting, Stewart Touring, Co Motion Tandem, Stewart 3-Spd, Stewart Track, Fuji Finest, Mongoose Tomac ATB, GT Bravado ATB, JCP Folder, Stewart 650B ATB

A wooden pair of crimping forms clamped with cee clamps one stay at a time. Lots of hand forming of the wood blocks to make the results look smooth. Far easier done before the stays are brazed in place... Andy.
Andrew R Stewart is offline
Reply
