Is this a defect in the frame?
08-10-16 | 11:05 AM
#1
Thread Starter
Senior Member
Joined: Aug 2012
Posts: 809
Likes: 132
Is this a defect in the frame?
As I was giving the frame a nice wipe-down I realized a few weird dots behind the seatstay part of the frame. Is this considered a defect? Or nothing I should worry about?
Am I being OCD?
Am I being OCD?
08-10-16 | 11:13 AM
#3
Banned.
Joined: Jul 2016
Posts: 2,717
Likes: 10
From: downtown Bulverde, Texas
Bikes: '74 Raleigh International utility; '98 Moser Forma road; '92 Viner Pro CX upright
porosity in the TiG weld
if you see something that looks like a crack in the paint, I would worry - if not, it's probably fine and limited to the
"reinforcement" (weld build-up)
I'm a metallurgist and licensed PE
if you see something that looks like a crack in the paint, I would worry - if not, it's probably fine and limited to the
"reinforcement" (weld build-up)
I'm a metallurgist and licensed PE
08-10-16 | 11:27 AM
#4
Senior Member
Joined: Oct 2015
Posts: 235
Likes: 0
From: Silicon Valley
Bikes: 1978 Motobecane Grand Jubile | 1983 Univega Gran Turismo | 1973 Raleigh Competition
The paint on my raleigh looked like that at the same joints until I striped it and smoothed out the brazing with a file. Nothing to worry about, seems to just be cosmetics.
08-10-16 | 01:22 PM
#6
Senior Member
Joined: Dec 2014
Posts: 3,598
Likes: 329
From: Fernandina Beach FL
Bikes: Vintage Japanese Bicycles, Tange, Ishiwata, Kuwahara
That looks like fish eyes to me. When you spray paint something and a stubborn little spot appears that won't go away. Maybe the scientist types in here can explain it.
08-10-16 | 01:29 PM
#7
Senior Member
Joined: Oct 2011
Posts: 10,043
Likes: 2,505
From: Fairplay Co
Bikes: Current 79 Nishiki Custum Sport, Jeunet 620, notable previous bikes P.K. Ripper loop tail, Kawahara Laser Lite, Paramount Track full chrome, Raliegh Internatioanl, Motobecan Super Mirage. 59 Crown royak 3 speed
I would agree doesn't look like something to worry about. More a combinatation of less than ideal finish on the weld and paint I have seen a lot of high end aluminium frames from the late 80's early 90's that look worse.
