Help with frame ID
04-27-17 | 09:15 PM
#1
Thread Starter
Eccentric Old Man
Joined: Jan 2014
Posts: 727
Likes: 177
From: BelleVegas, IL
Bikes: 1986 Trek 520 Cirrus, 1979 Schwinn Traveler III, Trek T100, 1995 Trek 970, Fuji America
Help with frame ID
Mystery Red Frame, serial # 805400
Bought at swap meet a few years ago as pictured, and put aside until now. Seller claimed it is 531.
56 cm x 56 cm ctc
42 cm chain stay
Weight is 4.12 lbs
No Headbadge holes
Both seat stays have decal that says “Handbuilt in England”
Seat tube is 28.6 od
Top tube is 25.4 od
Down Tube is 28.6 od
BB is English thread, stamped BCM
126 rear spacing with Gipiemme drop outs with adjusters
3 top tube guides, 2 sets bottle bosses, no eyelets, down tube shifter bosses, pump peg
Brake bridge is recessed
27.0 seat post
Thanks for any help
More pictures here.
https://flic.kr/s/aHskYJWeVM
[IMG]
IMG_0638 by lebagman, on Flickr[/IMG]
[IMG]
IMG_0637 by lebagman, on Flickr[/IMG]
Bought at swap meet a few years ago as pictured, and put aside until now. Seller claimed it is 531.
56 cm x 56 cm ctc
42 cm chain stay
Weight is 4.12 lbs
No Headbadge holes
Both seat stays have decal that says “Handbuilt in England”
Seat tube is 28.6 od
Top tube is 25.4 od
Down Tube is 28.6 od
BB is English thread, stamped BCM
126 rear spacing with Gipiemme drop outs with adjusters
3 top tube guides, 2 sets bottle bosses, no eyelets, down tube shifter bosses, pump peg
Brake bridge is recessed
27.0 seat post
Thanks for any help
More pictures here.
https://flic.kr/s/aHskYJWeVM
[IMG]
IMG_0638 by lebagman, on Flickr[/IMG][IMG]
IMG_0637 by lebagman, on Flickr[/IMG]
04-28-17 | 11:16 AM
#2
Bianchi Goddess
Joined: Apr 2009
Posts: 28,874
Likes: 4,118
From: Shady Pines Retirement Fort Wayne, In
Bikes: Too many to list here check my signature.
Falcon? Are they British?
__________________
“One morning you wake up, the girl is gone, the bikes are gone, all that's left behind is a pair of old tires and a tube of tubular glue, all squeezed out"
Sugar "Kane" Kowalczyk
“One morning you wake up, the girl is gone, the bikes are gone, all that's left behind is a pair of old tires and a tube of tubular glue, all squeezed out"
Sugar "Kane" Kowalczyk
04-28-17 | 11:42 AM
#3
Senior Member
Joined: Aug 2014
Posts: 540
Likes: 761
From: Los Angeles, CA
Bikes: None in ridable condition
I think [MENTION=159681]Bianchigirll[/MENTION] is right. This looks like a late 80s Falcon.
https://www.bikeforums.net/classic-vi...on-s-gone.html
Falcon Jaguar
https://www.bikeforums.net/classic-vi...on-s-gone.html
Falcon Jaguar
04-28-17 | 11:46 AM
#4
Senior Member
Joined: May 2013
Posts: 2,643
Likes: 3,330
From: Greenwood SC USA
Bikes: 2002 Mercian Vincitore, 1982 Mercian Colorado, 1976 Puch Royal X, 1973 Raleigh Competition, 1971 Gitane Tour de France and others
Now that Bianchigirll has said it, yeah - 80s Falcon?
I think this one - [IMG]
[/IMG] - is the less expensive, 501 tubed version of the OP's bike.
I think this one - [IMG]
[/IMG] - is the less expensive, 501 tubed version of the OP's bike.
04-28-17 | 11:50 AM
#5
Senior Member
Joined: Aug 2015
Posts: 1,418
Likes: 725
From: Kingdom of Hawai'i
Bikes: Peugeot, Legnano, Fuji, Zunow, De Rosa, Miyata, Bianchi, Pinarello, Specialized, Bridgestone, Cinelli, Merckx
Yep, [MENTION=159681]Bianchigirll[/MENTION] got it.
Here's a red one like the OP's:
Here's a red one like the OP's:
04-28-17 | 11:58 AM
#6
Thread Starter
Eccentric Old Man
Joined: Jan 2014
Posts: 727
Likes: 177
From: BelleVegas, IL
Bikes: 1986 Trek 520 Cirrus, 1979 Schwinn Traveler III, Trek T100, 1995 Trek 970, Fuji America
I'm no good at word games.
BG seems to have nailed it.
Thanks for the help.
BG seems to have nailed it.
Thanks for the help.
04-28-17 | 06:25 PM
#7
Bianchi Goddess
Joined: Apr 2009
Posts: 28,874
Likes: 4,118
From: Shady Pines Retirement Fort Wayne, In
Bikes: Too many to list here check my signature.
What a lucky guess
[MENTION=418278]billytwosheds[/MENTION] you really think he has a 531 frame? Would that be consistent with the 27.0 seatpost?
[MENTION=364834]eom[/MENTION] I got lucky maybe but the remnants of that decal looked vaguely familiar. Do you have the fork? Did you buy it like that? if so just sell it for what you paid for it.
[MENTION=418278]billytwosheds[/MENTION] you really think he has a 531 frame? Would that be consistent with the 27.0 seatpost? [MENTION=364834]eom[/MENTION] I got lucky maybe but the remnants of that decal looked vaguely familiar. Do you have the fork? Did you buy it like that? if so just sell it for what you paid for it.
__________________
“One morning you wake up, the girl is gone, the bikes are gone, all that's left behind is a pair of old tires and a tube of tubular glue, all squeezed out"
Sugar "Kane" Kowalczyk
“One morning you wake up, the girl is gone, the bikes are gone, all that's left behind is a pair of old tires and a tube of tubular glue, all squeezed out"
Sugar "Kane" Kowalczyk
04-29-17 | 02:20 PM
#8
Senior Member
Joined: Aug 2015
Posts: 1,418
Likes: 725
From: Kingdom of Hawai'i
Bikes: Peugeot, Legnano, Fuji, Zunow, De Rosa, Miyata, Bianchi, Pinarello, Specialized, Bridgestone, Cinelli, Merckx
It could be...either slightly off when measuring (and is actually 27.2), or it is actually 27.0 depending on how the frame building reamed the seat tube.
Last edited by billytwosheds; 04-29-17 at 02:20 PM. Reason: Messed up the quote formatting
04-29-17 | 04:14 PM
#9
If I own it, I ride it
Joined: Nov 2005
Posts: 5,685
Likes: 820
From: Cardinal Country
Bikes: Lejeune(14), Raleigh, Raysport, Jan De Reus, Gazelle, Masi, B. Carré(4), Springfield, Greg Lemond, Andre Bertin, Schwinn Paramount
Kudos to the OP for providing adequate photos. How many times have we had to pry photos out of people making ID requests?
Nice job BG.
The seat tube could also be pinched causing a 27.0 measurement.
Nice job BG.
The seat tube could also be pinched causing a 27.0 measurement.
04-29-17 | 04:22 PM
#10
Thread Starter
Eccentric Old Man
Joined: Jan 2014
Posts: 727
Likes: 177
From: BelleVegas, IL
Bikes: 1986 Trek 520 Cirrus, 1979 Schwinn Traveler III, Trek T100, 1995 Trek 970, Fuji America
I did not measure, I inserted a 27.0, 27.2 would not fit.
Thanks again to the collective mind.
Thanks again to the collective mind.
04-29-17 | 04:59 PM
#11
Senior Member
Joined: Apr 2006
Posts: 3,652
Likes: 109
When Paramounts were built out of 531 in the 1970s you could get a Paramount with either a 27.0 ot 27.2 seat post depending on how the 531 tube came to them. Apparently Reynolds had slight variation in the inside diameter of their tubing. Roger
04-29-17 | 08:48 PM
#12
Mr. Anachronism
Joined: Jan 2013
Posts: 2,110
Likes: 291
From: Somewhere west of Tobie's
Bikes: fillet-brazed Chicago Schwinns, and some other stuff
That 4.12 lb weight would certainly point to 531 or some equivalent premium tubing. Reference a 55cm (C2C) '74 Raleigh International frame at 4.66 lbs, a 57cm '79 Raleigh Comp GS frame at 4.59 lbs., a 58cm 70's Viscount frame at 4.37 lbs., and a 56cm 4130 Chrome Moly (Schwinn LeTour Luxe) frame at 5.45 lbs. Weights are as the OP shows, with all bearings and cups removed.
__________________
"My only true wisdom is in knowing I have none" -Socrates
"My only true wisdom is in knowing I have none" -Socrates
Last edited by Hudson308; 04-29-17 at 09:01 PM. Reason: added more specs
