Is this frame toast?
01-02-10 | 11:28 AM
#5
Bicyclerider4life
Joined: Aug 2006
Posts: 1,076
Likes: 12
From: Florida and Idaho
Bikes: Huffy Beach Cruisers, Miami Sun Trike, Vertical PK7, KHS Montana Summit, Giant Cypress DX, Schwinn OCC Stingray
ouch. You might be able to put a sleeve or something over it to reinforce it and save the frame. I don't know if it would be practical to replace that stay.
__________________
"Whenever I see an adult riding a bicycle, I know there is hope for mankind." (H. G. Wells)
"Whenever I see an adult riding a bicycle, I know there is hope for mankind." (H. G. Wells)
01-02-10 | 11:30 AM
#6
juneeaa memba!
Joined: Oct 2003
Posts: 5,631
Likes: 5
From: boogled up in...Idaho!
Bikes: Crap. The box is not big enough...
I think you'll find that the entire inside of the bike frame looks like that. Take your trusty awl, and poke at the thinnest spot. If you can drive the awl through (or it feels like you could) then Zorro's right, sorry. If you can't, then you'll have to look inside of the frame at the seat tube, bottom bracket, head tube to see if there is extensive rust (especially at the bottom bracket...). If you see thin spots, then, sorry, Zorro's right. Run a steel coat hanger or spoke up into the main tubes and see if rust cascades out...if you get a lot, then...yeah. Finally, if you shake the bike and it sounds like a maraca, then...
Zorro's usually right about these things, btw.
Zorro's usually right about these things, btw.
01-02-10 | 11:43 AM
#8
Bianchi Goddess
Joined: Apr 2009
Posts: 28,890
Likes: 4,133
From: Shady Pines Retirement Fort Wayne, In
Bikes: Too many to list here check my signature.
that is too bad. what kind of frame is it? is that right seatstay the only bad spot or just the worse one?
__________________
“One morning you wake up, the girl is gone, the bikes are gone, all that's left behind is a pair of old tires and a tube of tubular glue, all squeezed out"
Sugar "Kane" Kowalczyk
“One morning you wake up, the girl is gone, the bikes are gone, all that's left behind is a pair of old tires and a tube of tubular glue, all squeezed out"
Sugar "Kane" Kowalczyk
01-02-10 | 12:14 PM
#10
Thread Starter
Senior Member
Joined: Dec 2008
Posts: 659
Likes: 1
It's an early Nuovo Racing 12. That's the only real pit - there are other spots but none that make me wonder about the structural integrity of the frame. This spot seems to be where the old chain was resting against the frame. Of course the seatpost is frozen and I'm going to need heroic measures to remove one of the crank arms, thanks to a rounded-out dust cap hole.
01-02-10 | 12:58 PM
#13
feros ferio
Joined: Jul 2000
Posts: 22,398
Likes: 1,865
From: www.ci.encinitas.ca.us
Bikes: 1959 Capo Modell Campagnolo; 1960 Capo Sieger (2); 1962 Carlton Franco Suisse; 1970 Peugeot UO-8; 1982 Bianchi Campione d'Italia; 1988 Schwinn Project KOM-10;
I am not sure about this, but I believe the Nuovo Racing is a tre tubi frame, with a double-butted Columbus main triangle and seamed CrMo forks and stays. To me the real question is whether we are seeing rust seeping out from the inner surface of the tube, or whether this is just a localized corrosion problem. I think you can ride it safely enough, but pay close attention to any emerging squeaks or play in the rear triangle.
__________________
"Far and away the best prize that life offers is the chance to work hard at work worth doing." --Theodore Roosevelt
Capo: 1959 Modell Campagnolo, S/N 40324; 1960 Sieger (2), S/N 42624, 42597
Carlton: 1962 Franco Suisse, S/N K7911
Peugeot: 1970 UO-8, S/N 0010468
Bianchi: 1982 Campione d'Italia, S/N 1.M9914
Schwinn: 1988 Project KOM-10, S/N F804069
"Far and away the best prize that life offers is the chance to work hard at work worth doing." --Theodore Roosevelt
Capo: 1959 Modell Campagnolo, S/N 40324; 1960 Sieger (2), S/N 42624, 42597
Carlton: 1962 Franco Suisse, S/N K7911
Peugeot: 1970 UO-8, S/N 0010468
Bianchi: 1982 Campione d'Italia, S/N 1.M9914
Schwinn: 1988 Project KOM-10, S/N F804069
01-02-10 | 01:19 PM
#14
Bianchi Goddess
Joined: Apr 2009
Posts: 28,890
Likes: 4,133
From: Shady Pines Retirement Fort Wayne, In
Bikes: Too many to list here check my signature.
what kid of dust cap on the crank? OH just where do you live the beach somewhere? I would use alot of that PB blaster stuff and then drill two small holes in it like for a shimano crankset, assuming you or your shop has the shimano tool. I thought that hole was either a vent hole (most likely) or maybe a chainholder but it seemed low for that.
__________________
“One morning you wake up, the girl is gone, the bikes are gone, all that's left behind is a pair of old tires and a tube of tubular glue, all squeezed out"
Sugar "Kane" Kowalczyk
“One morning you wake up, the girl is gone, the bikes are gone, all that's left behind is a pair of old tires and a tube of tubular glue, all squeezed out"
Sugar "Kane" Kowalczyk
01-02-10 | 01:36 PM
#15
Randomhead
Joined: Aug 2008
Posts: 25,930
Likes: 4,825
From: Happy Valley, Pennsylvania
just like to call attention to my post above where I point out that the hole in the center is a vent hole. It's really common to see the paint fail around vent holes. It makes it look a lot worse than it is. I really doubt a seat stay would fail due to this rust.
