frame identification

Thread Tools

Search this Thread

Old 01-22-10 | 03:30 PM
  #1
Thread Starter
Junior Member

Joined: Jan 2010
Posts: 12
Likes: 0
frame identification

i made the same thread in the inquiries subforum but apparently it is suitable to go here as i am not asking for its value. got some better photos aswell so i hope it helps.















cheers

Last edited by djsearcy; 01-23-10 at 07:03 AM.
djsearcy is offline
Reply
Old 01-22-10 | 03:48 PM
  #2
unworthy1's Avatar
Stop reading my posts!
20 Anniversary
Community Builder

Joined: Sep 2004
Posts: 14,001
Likes: 2,200
I can't give you a positive ID, but I'll tell you this:
It has a variation of the style of fastback seatcluster known as "Brampton-Victor" or just Victor for short, coupled with the full-sloping crown one might jump to assuming a Raleigh Pro, but I'm not certain enough to jump, yet (you'd want 3 holes for the badge, not 2)
There were other British marques that did this style of seatcluster and had some kind of similar forkcrown: Holdsworth was one, Carlton perhaps another.
I'd guess it's certainly British and most likely 531 tubing and a 27.2 post.

Last edited by unworthy1; 01-22-10 at 04:08 PM. Reason: spelling
unworthy1 is offline
Reply
Old 01-22-10 | 04:24 PM
  #3
Thread Starter
Junior Member

Joined: Jan 2010
Posts: 12
Likes: 0
thanks alot! just had a look around... https://www.carltoncycles.me.uk/mybik...ofessional.htm ?
djsearcy is offline
Reply
Old 01-22-10 | 04:34 PM
  #4
Senior Member

Joined: Dec 2008
Posts: 659
Likes: 1
Any chance you're in Atlanta?
stausty is offline
Reply
Old 01-22-10 | 04:37 PM
  #5
Thread Starter
Junior Member

Joined: Jan 2010
Posts: 12
Likes: 0
nope, i'm from nottingham, u.k
djsearcy is offline
Reply
Old 01-22-10 | 04:49 PM
  #6
Senior Member

Joined: Dec 2008
Posts: 659
Likes: 1
Originally Posted by djsearcy
nope, i'm from nottingham, u.k
I swear I saw the same frame chained to a tree at the bar across the street from my apartment last week. It was built up with Dura Ace components, but had the same paint and pair of holes in the head tube. It's a beautiful bike and you are assured of my jealousy.
stausty is offline
Reply
Old 01-22-10 | 04:51 PM
  #7
Thread Starter
Junior Member

Joined: Jan 2010
Posts: 12
Likes: 0
haha fair enough. thankyou!
djsearcy is offline
Reply
Old 01-22-10 | 06:55 PM
  #8
unworthy1's Avatar
Stop reading my posts!
20 Anniversary
Community Builder

Joined: Sep 2004
Posts: 14,001
Likes: 2,200
Carlton Professional seems a very close match, and the serial number might indicate a '71 or '72, but did they come with all those braze-on bits and chrome headlugs in this period? The picture of the '72 (maybe a late '72) shown on that site have neither. The clincher will be to match up the badge holes on a Carlton with a badge.
unworthy1 is offline
Reply
Old 01-22-10 | 09:59 PM
  #9
JohnDThompson's Avatar
Old fart
Titanium Club Membership
20 Anniversary
Community Builder

Joined: Nov 2004
Posts: 26,345
Likes: 5,251
From: Appleton WI

Bikes: Several, mostly not name brands.

Looks like a Raleigh "Professional." Mid 1970s production.
JohnDThompson is offline
Reply
Old 01-23-10 | 07:02 AM
  #10
Thread Starter
Junior Member

Joined: Jan 2010
Posts: 12
Likes: 0
thanks unworthy, it is the closest i have seen yet though. i heard from somewhere else it could be a carlton competition but i cant find any images on the internet. i hear that raleigh pro's have a cut out on the BB? so that is out of the question unless i heard wrong.
djsearcy is offline
Reply
Old 01-23-10 | 07:57 AM
  #11
Senior Member
20 Anniversary

Joined: Nov 2004
Posts: 23,212
Likes: 3,122
I agree with Unworthy1 and suspect this is a Carlton Professional, as opposed to a Raleigh Professional, purely on the basis of the chromed head lugs. I've never seen a Raleigh Professional with chromed head lugs and the Carlton Professional was known to have them in 1970, so it probably also had them in 1971/1972. The few Carlton Competition that I've seen did not use a fastback stay arrangement.
T-Mar is offline
Reply
Old 01-23-10 | 12:05 PM
  #12
Thread Starter
Junior Member

Joined: Jan 2010
Posts: 12
Likes: 0
thankyou for your help guys
djsearcy is offline
Reply
Old 03-24-10 | 07:29 AM
  #13
Senior Member

Joined: Jan 2009
Posts: 104
Likes: 0
From: cambridge, UK

Bikes: Denti Scheggia, 1974 holdsworth super mistral as a single speed

not a holdsworth as the headbadge had the hols vertically and not horizontally like yours. the serial number goes across the BB too.
nuovo_record is offline
