NR RD setup woes :(
08-15-11 | 02:57 PM
#26
Fat Guy on a Little Bike
Joined: Jun 2008
Posts: 15,946
Likes: 371
From: Philadelphia, PA
Bikes: Two wheeled ones
Inside every Fuji fan is a Miyata enthusiast waiting for his chance!
08-15-11 | 03:07 PM
#28
The RD spring is whipped.
Keith, with NO chain installed does the cage 'snap back' when its rotated? It should take a fair amount of effort to rotate the cage by hand and it should easily, if not somewhat forcefully, spring back so that the cage stop is firmly against the derailleur body.
Keith, with NO chain installed does the cage 'snap back' when its rotated? It should take a fair amount of effort to rotate the cage by hand and it should easily, if not somewhat forcefully, spring back so that the cage stop is firmly against the derailleur body.
08-15-11 | 03:11 PM
#29
Old fart
Joined: Nov 2004
Posts: 26,404
Likes: 5,339
From: Appleton WI
Bikes: Several, mostly not name brands.
Here's a closeup of the RD/crank cropped out of the full-size pic above. Does this help any? Honestly, I forget what length of chain I have in here in this pics...links were a'flying last night.
And yes, that is a makeshift RD housing until I get a real one...I just wanted to try to get chain length set
And yes, that is a makeshift RD housing until I get a real one...I just wanted to try to get chain length set
Last edited by JohnDThompson; 08-15-11 at 03:21 PM.
08-15-11 | 04:30 PM
#32
Senior Member
Joined: Jul 2009
Posts: 11,128
Likes: 39
Bikes: 1986 Alan Record Carbonio, 1985 Vitus Plus Carbone 7, 1984 Peugeot PSV, 1972 Line Seeker, 1986(est.) Medici Aerodynamic (Project), 1985(est.) Peugeot PY10FC
If it's a pulley cage tension problem, it should be an easy fix. Just remove the stopper bar (I think theres a slot on the tip to use a screw driver on) on the knurled barrel next to the pulley cage that keeps the cage from spinning back and wind in some tension by spinning the pulley cage assembly counter clockwise. reinstall the stop when there is enough tension again. Unless the lower pivot tension spring is broken, this should fix your tension problems.
Chombi
Chombi
They work great
08-15-11 | 05:05 PM
#34
Senior Member
Joined: Apr 2005
Posts: 17,196
Likes: 761
From: Ann Arbor, MI
Bikes: 1980 Masi, 1984 Mondonico, 1984 Trek 610, 1980 Woodrup Giro, 2005 Mondonico Futura Leggera ELOS, 1967 PX10E, 1971 Peugeot UO-8
Do you have room to move the wheel back in the dropout? That has the effect of taking up chain slack, about a half a link total. I'd also suggest showing a picture in the big-big position, I'd like to see if the cage rotation looks right. Finally, it's possible the cage pivot was disassembled and reassembled in the wrong position, or the rotation stop is wrong somehow (a long shot).
I think your idler and jockey wheels look great.
Edit, I think it should have been small-small, like in post 8.
I think your idler and jockey wheels look great.
Edit, I think it should have been small-small, like in post 8.
Last edited by Road Fan; 08-15-11 at 05:23 PM.
08-15-11 | 05:13 PM
#36
Senior Member
Joined: Apr 2005
Posts: 17,196
Likes: 761
From: Ann Arbor, MI
Bikes: 1980 Masi, 1984 Mondonico, 1984 Trek 610, 1980 Woodrup Giro, 2005 Mondonico Futura Leggera ELOS, 1967 PX10E, 1971 Peugeot UO-8
I wish I had more experience with older Campy stuff. I have found that on some frames the Campy RD will affix to the drop out solid & not movable. Other frames the Campy RD will hang loose or movable.
Am I assuming that a correctly mounted RD should hang free to move for & aft. The cage spring pulls the chain & RD to the correct position. This requires a pretty strong spring.
Someone correct me if that is incorrect.
Am I assuming that a correctly mounted RD should hang free to move for & aft. The cage spring pulls the chain & RD to the correct position. This requires a pretty strong spring.
Someone correct me if that is incorrect.
08-15-11 | 05:33 PM
#39
Thread Starter
FBoD Member at Large
Joined: Aug 2008
Posts: 6,094
Likes: 8
From: Woodbury, MN
Well, I didn't have the heart to hang Shimano or Suntour on the Italvega...and before I really bash Campy for real I suppose I'd better ride it some
If I don't like it there may be a VERY nice Italvega Super Speciale in the for sale forum!
If I don't like it there may be a VERY nice Italvega Super Speciale in the for sale forum!
08-15-11 | 05:34 PM
#40
Death fork? Naaaah!!
Joined: Nov 2005
Posts: 5,535
Likes: 961
From: The other Maine, north of RT 2
Bikes: Seriously downsizing.
Top
__________________
You know it's going to be a good day when the stem and seatpost come right out.
(looking for a picture and not seeing it? Thank the Photobucket fiasco.PM me and I'll link it up.)
You know it's going to be a good day when the stem and seatpost come right out.
(looking for a picture and not seeing it? Thank the Photobucket fiasco.PM me and I'll link it up.)
08-15-11 | 05:52 PM
#42
Senior Member
Joined: Apr 2005
Posts: 17,196
Likes: 761
From: Ann Arbor, MI
Bikes: 1980 Masi, 1984 Mondonico, 1984 Trek 610, 1980 Woodrup Giro, 2005 Mondonico Futura Leggera ELOS, 1967 PX10E, 1971 Peugeot UO-8
Sheesh. You should just go to the I-Hate-Campy subforum.
08-15-11 | 06:09 PM
#43
Thread Starter
FBoD Member at Large
Joined: Aug 2008
Posts: 6,094
Likes: 8
From: Woodbury, MN
BTW, I couldn't find that subforum, have a link?
08-15-11 | 07:43 PM
#44
Thread Starter
FBoD Member at Large
Joined: Aug 2008
Posts: 6,094
Likes: 8
From: Woodbury, MN
Well, it wasn't the spring. Here's a video of the RD to demonstrate the spring tension:
I replaced the chain with an SRAM PC830 just for grins after working on the length a little more...much better now, both in terms of length and shifting.
I really wanted to use that KMC chain...the RD just must not have liked it...no wear at all according to the gauge.
I replaced the chain with an SRAM PC830 just for grins after working on the length a little more...much better now, both in terms of length and shifting.
I really wanted to use that KMC chain...the RD just must not have liked it...no wear at all according to the gauge.
08-16-11 | 12:23 AM
#45
Senior Member
Joined: Oct 2009
Posts: 2,470
Likes: 5
From: Minneapolis
Bikes: -1973 Motobecane Mirage -197? Velosolex L'Etoile -'71 Raleigh Super Course
Just looking things over through your photos it seems you needed still a couple more links taken out of the chain. I've found older derailleurs seem to want to run with quite a bit more tension in the system than the modern units do. I certainly get crisper shifting when I have more tension in the system, anyway; and if you're getting good results with SRAM chains, that's nothing but good news for the rest of us.
08-16-11 | 12:35 AM
#46
Tyrannosaurus Rexitis
Joined: Mar 2011
Posts: 934
Likes: 0
From: Cape Cod, MA
Bikes: Scott Addict 6870
I use the least amount of chain I can get away with in small/small to have the RD cage not drag on the chain. That always works (disclaimer: I don't own any wide range freewheels, or triples. Just narrow range doubles like the OP's.)
Not sure why it wouldn't like the chain. My patent '74 NR RD shifts anything, even a 10s Shimano 6701 chain.
Not sure why it wouldn't like the chain. My patent '74 NR RD shifts anything, even a 10s Shimano 6701 chain.
08-16-11 | 05:08 AM
#48
Senior Member
Joined: Apr 2005
Posts: 17,196
Likes: 761
From: Ann Arbor, MI
Bikes: 1980 Masi, 1984 Mondonico, 1984 Trek 610, 1980 Woodrup Giro, 2005 Mondonico Futura Leggera ELOS, 1967 PX10E, 1971 Peugeot UO-8
Well, it wasn't the spring. Here's a video of the RD to demonstrate the spring tension:
I replaced the chain with an SRAM PC830 just for grins after working on the length a little more...much better now, both in terms of length and shifting.
I really wanted to use that KMC chain...the RD just must not have liked it...no wear at all according to the gauge.
I replaced the chain with an SRAM PC830 just for grins after working on the length a little more...much better now, both in terms of length and shifting.
I really wanted to use that KMC chain...the RD just must not have liked it...no wear at all according to the gauge.
08-16-11 | 07:11 AM
#49
Senior Member
Joined: Dec 2009
Posts: 8,343
Likes: 16
From: Louisville
Those derailleurs were made to work with a wide, stiff, chain, the old Reginas. They will shift better with a freewheel with a modern tooth, like a Sachs or Shimano, but that 6-speed chain should be what it was made for. Length is the issue, not chain type. A narrower chain should require more overshift, anyway.
