When to replace chain rings?

Notices
Bicycle Mechanics Broken bottom bracket? Tacoed wheel? If you're having problems with your bicycle, or just need help fixing a flat, drop in here for the latest on bicycle mechanics & bicycle maintenance.

When to replace chain rings?

Old 07-25-16, 05:48 PM
  #1
dmanthree
Senior Member
Thread Starter

dmanthree's Avatar

Join Date: Sep 2014
Location: Northeastern MA, USA
Posts: 1,057

Bikes: 2017 Roubaix

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 376 Post(s)
Liked 67 Times in 50 Posts
When to replace chain rings?

I've been trying to find a creaking noise that seems to be coming from the bottom bracket area, and I was wondering if there's some rule of thumb when it comes to replacing chain rings. My front shifts aren't as quick and positive as they used to be, and the large chain ring teeth seems to be slightly resembling hooks. Could this be the cause of the creaking It happens on both chain rings and only when I'm standing on the pedals.

I'll look at the BB, as well. I'm curious; how can I tell if I have a threaded or press-fit BB? It's a 2012 Madone 5.2.
dmanthree is offline
Old 07-25-16, 09:54 PM
  #2
Camilo
Senior Member

Join Date: Apr 2007
Posts: 4,715
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 309 Post(s)
Liked 92 Times in 58 Posts
Threaded BB, on a bike as new as yours will have external cups with indentations like these (the indentations are for the tool you use to install or remove). They'll be very similar in appearance no matter what brand of crank you have:



Older threaded BBs don't look like that but your 2012 Trek will.

Press fit BBs don't have external cups that can take the tool like that.

Hope that makes sense.

As for the chain wheel question, I'll let others answer that.
Camilo is offline
Old 07-25-16, 10:08 PM
  #3
2lo8
Senior Member

Join Date: Jun 2016
Posts: 625
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 252 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
I would have thought Trek was using BB90 by 2012.
2lo8 is offline
Old 07-26-16, 06:00 AM
  #4
sch
Senior Member

Join Date: May 2003
Location: Mountain Brook. AL
Posts: 3,749
Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 231 Post(s)
Likes: 0
Liked 47 Times in 39 Posts
YMMV but my general rule is replace two chains, on 3d chain the cassette will be worn and not mesh, so replace. On 4 th chain a CW
replacement is likely because of CW/chain not meshing. Creaks in the BB can be elusive. The cartridge BB (pictured by Camilo)
are cheap and easy to replace. Pressed in bearings require a little more finesse to R&R. And replacing the BB may not solve the
creak. Also look at pedal to crank and crank to axle threadings. Sometimes an apparent BB creak is actually the seat post/saddle
area.
sch is offline
Old 07-26-16, 06:20 PM
  #5
dmanthree
Senior Member
Thread Starter

dmanthree's Avatar

Join Date: Sep 2014
Location: Northeastern MA, USA
Posts: 1,057

Bikes: 2017 Roubaix

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 376 Post(s)
Liked 67 Times in 50 Posts
Originally Posted by 2lo8 View Post
I would have thought Trek was using BB90 by 2012.
The spec sheet says BB90, so is that pressed fit?
dmanthree is offline
Old 07-26-16, 09:33 PM
  #6
sch
Senior Member

Join Date: May 2003
Location: Mountain Brook. AL
Posts: 3,749
Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 231 Post(s)
Likes: 0
Liked 47 Times in 39 Posts
Park tool on BB90 (press fit BB): Bottom Bracket Service: BB90, BB86, BB92, GXP Press Fit | Park Tool
sch is offline
Old 07-26-16, 09:44 PM
  #7
10 Wheels
Galveston County Texas

10 Wheels's Avatar

Join Date: Nov 2007
Location: In The Wind
Posts: 30,975

Bikes: 2010 Expedition, 03 GTO

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 710 Post(s)
Likes: 0
Liked 5 Times in 4 Posts
This one creaked on my bike.

__________________
Fred "The Real Fred"
10 Wheels is offline
Old 07-28-16, 02:27 PM
  #8
miamijim
Senior Member

miamijim's Avatar

Join Date: Aug 2003
Location: Tampa, Florida
Posts: 13,993
Mentioned: 39 Post(s)
Tagged: 0 Thread(s)
Quoted: 365 Post(s)
Likes: 0
Liked 22 Times in 19 Posts
Originally Posted by dmanthree View Post
I was wondering if there's some rule of thumb when it comes to replacing chain rings.
Chain on big ring...at 3 o'clock pull the chain away from the ring. If you can see daylight between the tip of the tooth and the chain then the chain ring is whipped.
miamijim is offline
Old 07-29-16, 09:30 AM
  #9
P_M
Senior Member

Join Date: Jul 2011
Posts: 180

Bikes: Devinci Tosca S

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 26 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
How often do you replace your chain?

The more the chain is stretched and used in that state, the quicker the teeth will wear. I once bought a used bike that needed a new chain. I replaced the chain and found the cassette was pooched. So then I replaced the cassette and once that was grabbing hold well the chain rings couldn't handle it and I nearly ended up on the top tube the first ride out. In the end I had a new drivetrain.
P_M is offline
Old 07-29-16, 09:58 AM
  #10
bulldog1935
Banned.

Join Date: Jul 2016
Location: downtown Bulverde, Texas
Posts: 2,717

Bikes: '74 Raleigh International utility; '98 Moser Forma road; '92 Viner Pro CX upright

Mentioned: 44 Post(s)
Tagged: 0 Thread(s)
Quoted: 939 Post(s)
Likes: 0
Liked 3 Times in 3 Posts
Chain rings need to be repaced when they become shark-teethed - no longer round along the top.
If you regularly replace your chain, which is usually cheaper, you can get 15 years from your alloy chainrings.
bulldog1935 is offline
Old 07-31-16, 06:37 PM
  #11
dmanthree
Senior Member
Thread Starter

dmanthree's Avatar

Join Date: Sep 2014
Location: Northeastern MA, USA
Posts: 1,057

Bikes: 2017 Roubaix

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 376 Post(s)
Liked 67 Times in 50 Posts
The teeth on the big ring are a little shark-toothed. I replace the chain annually, and I've got about 23,000 miles on the chain rings. I spend about 70% of my time on the big ring. I think I'll replace it. Cheap enough.
dmanthree is offline
Old 08-01-16, 08:07 PM
  #12
ThermionicScott
7-speed cultist

ThermionicScott's Avatar

Join Date: Aug 2011
Location: CID
Posts: 20,010

Bikes: 1991 Bianchi Eros, 1964 Armstrong, 1988 Diamondback Ascent, 1988 Bianchi Premio, 1987 Bianchi Sport SX, 1980s Raleigh mixte (hers)

Mentioned: 87 Post(s)
Tagged: 0 Thread(s)
Quoted: 2769 Post(s)
Liked 680 Times in 474 Posts
Originally Posted by dmanthree View Post
The teeth on the big ring are a little shark-toothed. I replace the chain annually, and I've got about 23,000 miles on the chain rings. I spend about 70% of my time on the big ring. I think I'll replace it. Cheap enough.
Get out your camera and post a pic already.
__________________
Originally Posted by chandltp View Post
There's no such thing as too far.. just lack of time
Originally Posted by noglider
People in this forum are not typical.
RUSA #7498
ThermionicScott is offline
