Rear Wheel mounting problem

Old 01-10-21, 02:53 PM
  #1
roadsnakes
Senior Member
Thread Starter

Join Date: Nov 2018
Posts: 159
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 61 Post(s)
Liked 80 Times in 35 Posts
Rear Wheel mounting problem

I`m not sure if I should try this folder, or the Mechanics folder?
I have a 86' Schwinn Passage.
Whenever I have to take the front tire off, it just pops on and off, no problems.

But when I have to remove the rear tire, I have to give it a good pull to get it off.
And putting it back on is almost impossible! It`s like the opening on the tire is bigger than the opening on the bikes frame!
I almost have try to pull and the frame and try to get the wheel in the slot at the same time. Which you can`t do unless you have four hands.
It`s like the seat stays and chain stays need to be pulled apart?
roadsnakes is offline
Old 01-10-21, 03:01 PM
  #2
Moisture
Drip, Drip.

Moisture's Avatar

Join Date: Oct 2020
Posts: 780
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 528 Post(s)
Liked 87 Times in 71 Posts
First check to ensure dropouts are aligned
. Lzy the bike on its side with the bars facing up and gently spread apart each side
Moisture is offline
Old 01-10-21, 04:51 PM
  #3
oneclick
Senior Member

Join Date: Feb 2020
Posts: 872
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 297 Post(s)
Likes: 0
Liked 295 Times in 186 Posts
Originally Posted by Moisture View Post
First check to ensure dropouts are aligned
. Lzy the bike on its side with the bars facing up and gently spread apart each side
No.

NO.

There is a proper way to spread steel stays, and that isn't it.

You have no way of knowing if the stays were aligned before or after if you don't measure, and if you attempt to spread the stays as described above you are unlikely to finish with them aligned even if they were to begin with.
oneclick is offline
Likes For oneclick:
Old 01-10-21, 05:09 PM
  #4
nlerner
Senior Member

Join Date: Dec 2005
Posts: 13,964
Mentioned: 323 Post(s)
Tagged: 0 Thread(s)
Quoted: 2057 Post(s)
Liked 1,412 Times in 769 Posts
Originally Posted by roadsnakes View Post
I`m not sure if I should try this folder, or the Mechanics folder?
I have a 86' Schwinn Passage.
Whenever I have to take the front tire off, it just pops on and off, no problems.

But when I have to remove the rear tire, I have to give it a good pull to get it off.
And putting it back on is almost impossible! It`s like the opening on the tire is bigger than the opening on the bikes frame!
I almost have try to pull and the frame and try to get the wheel in the slot at the same time. Which you can`t do unless you have four hands.
It`s like the seat stays and chain stays need to be pulled apart?
Has the original rear wheel been replaced at some point? Sounds like it. Back in the time of 5-speed rear clusters, spacing between the dropouts was 120mm. When 6- and 7-speed became common, dropouts spacing increased to 126mm. Then 8-speed on up call for 130mm spacing. Mtn bike rear wheels (and some touring bikes) have 135mm spacing. Measure your dropouts, and measure your rear hub from locknut to locknut. See how they compare.
nlerner is offline
Likes For nlerner:
Old 01-10-21, 05:49 PM
  #5
roadsnakes
Senior Member
Thread Starter

Join Date: Nov 2018
Posts: 159
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 61 Post(s)
Liked 80 Times in 35 Posts
Originally Posted by nlerner View Post
Has the original rear wheel been replaced at some point? Sounds like it. Back in the time of 5-speed rear clusters, spacing between the dropouts was 120mm. When 6- and 7-speed became common, dropouts spacing increased to 126mm. Then 8-speed on up call for 130mm spacing. Mtn bike rear wheels (and some touring bikes) have 135mm spacing. Measure your dropouts, and measure your rear hub from locknut to locknut. See how they compare.
WOW!
Looking back , the rear wheel Was replaced over 30 some years ago.
I now remember getting it caught between the grass and sidewalk. When I tried to ride out of it, back onto the sidewalk, the rim got bent Very badly.
The LBS shop said they had a wheel from a tandem bike they could put on, and it would cost less then getting a new rim, and rebuild.
Since both the original wheel and tandem wheel both were 40 spoke.

NOW, What are my options. The difference must be not too much more than 1/16 on an inch.
But, my sanity can`t take too many more times trying to pull on the chain stays , And slide the wheel in at the same time.
'

roadsnakes is offline
Old 01-10-21, 07:50 PM
  #6
nlerner
Senior Member

Join Date: Dec 2005
Posts: 13,964
Mentioned: 323 Post(s)
Tagged: 0 Thread(s)
Quoted: 2057 Post(s)
Liked 1,412 Times in 769 Posts
There’s plenty of DIY stuff online to spread your dropouts (such as https://www.sheldonbrown.com/frame-spacing.html) or take it to your LBS to have it done properly and ensure that everything is aligned.
nlerner is offline
Old 01-10-21, 08:19 PM
  #7
seedsbelize
smelling the roses

Join Date: Nov 2010
Location: Tixkokob, Yucatán, México
Posts: 14,617

Bikes: 79 Trek 930, 80 Trek 414, 84 Schwinn Letour Luxe (coupled), 92 Schwinn Paramount PDG 5

Mentioned: 103 Post(s)
Tagged: 1 Thread(s)
Quoted: 6642 Post(s)
Liked 725 Times in 480 Posts
Originally Posted by nlerner View Post
There’s plenty of DIY stuff online to spread your dropouts (such as https://www.sheldonbrown.com/frame-spacing.html) or take it to your LBS to have it done properly and ensure that everything is aligned.
This. It can be difficult getting everything just right, with the Sheldon Brown method. It works, but is fiddly.
__________________
Well look what the cat dragged in. Such a fine addition to the thread





seedsbelize is offline
Old 01-10-21, 10:43 PM
  #8
thook
Senior Member

Join Date: Aug 2009
Location: Winslow, AR
Posts: 1,581

Bikes: '83 univega gran turismo x2, '85 schwinn super le tour,'89 miyata triple cross, '91 GT tequesta, '90 yokota grizzly peak, '94 GT backwoods, '95'ish scott tampico, '98 bonty privateer, '93 mongoose crossway 625, '98 parkpre ariel, 2k'ish giant fcr3

Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 342 Post(s)
Liked 199 Times in 151 Posts
Originally Posted by seedsbelize View Post
This. It can be difficult getting everything just right, with the Sheldon Brown method. It works, but is fiddly.
understatement
thook is offline
Old 01-11-21, 01:38 AM
  #9
KCT1986
Senior Member

Join Date: Jan 2016
Posts: 162
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 60 Post(s)
Liked 22 Times in 18 Posts
Is it possible to reduce the hub width? If there is room between the smallest cog and the dropout, remove and swapping around the spacers or locknuts to equally reduce each side. If you do each side the same amount the dish of the wheel will not be effected.
KCT1986 is online now
Old 01-11-21, 07:00 AM
  #10
nlerner
Senior Member

Join Date: Dec 2005
Posts: 13,964
Mentioned: 323 Post(s)
Tagged: 0 Thread(s)
Quoted: 2057 Post(s)
Liked 1,412 Times in 769 Posts
Originally Posted by KCT1986 View Post
Is it possible to reduce the hub width? If there is room between the smallest cog and the dropout, remove and swapping around the spacers or locknuts to equally reduce each side. If you do each side the same amount the dish of the wheel will not be effected.
Usually not a good idea as you run the risk of have too much axle poking through the dropout, and the quick release won’t bite down as a result.
nlerner is offline
Old 01-11-21, 09:42 AM
  #11
conspiratemus1
Used to be Conspiratemus

Join Date: Jan 2009
Location: Hamilton ON Canada
Posts: 1,490
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 283 Post(s)
Liked 233 Times in 155 Posts
If the wheel came from a tandem 30 years ago, it likely has an OLD of 135 mm. 140 was starting to appear but 140 would not be able to be crammed into a singe-bike frame. There were some tandems still made with 130 and if the OP’s bike is 126, the tandem wheel could have been made to fit poorly, as he describes.

So, before you go bending your frame willy-nilly, the first thing to do is measure the width between the inner faces of the dropouts and the over-locknut dimension of the hub, and you need to tell us what kind of hub you have—cassette or freewheel, and whether the hub can be shortened on one or both axle ends. A cassette hub can’t be shortened on the right side — well, maybe a millimetre— but a freewheel hub can be.

The question is whether the frame should be widened to fit the wheel, or should the hub be shortened to fit the frame, if the latter is even possible given the design of the hub. Photos showing these details will be more useful than one of the bike leaning against a tree and showing only the front end.

Much depends on how handy you are with tools, and how much experience you have with bike repair. You might be better off just buying a cheap rear wheel — it’s a wheel you need, not a “tire” — of the correct size, rather than tackling the job of making two parts fit together when they weren’t meant to.

Edit: As nlerner says, if you make the OLD narrower, you must make sure that the axle ends do not protrude even a hair’s breadth past the outer face of the dropouts (assuming it’s a quick-release hub.). This will require a hacksaw.

Last edited by conspiratemus1; 01-11-21 at 09:53 AM.
conspiratemus1 is offline
Likes For conspiratemus1:
Old 01-11-21, 01:30 PM
  #12
roadsnakes
Senior Member
Thread Starter

Join Date: Nov 2018
Posts: 159
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 61 Post(s)
Liked 80 Times in 35 Posts
I stopped by my LBS with the bike today.

They did some measuring and looked at the wheel.

They said the frame appears to be bent. It was off by 5mm.

They`re going to bend it out 5mm, for 20 bucks.
roadsnakes is offline
Likes For roadsnakes:
Old 01-11-21, 09:27 PM
  #13
Hobbiano
Senior Member

Join Date: Sep 2014
Location: Baton Rouge La
Posts: 758
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 224 Post(s)
Liked 105 Times in 78 Posts
That looks like a 48 spoke rear wheel.
Hobbiano is offline
Old 01-11-21, 11:29 PM
  #14
walterpeter946
Banned.

Join Date: Jan 2021
Posts: 12
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 3 Post(s)
Likes: 0
Liked 1 Time in 1 Post
I Agree witht this!!

Originally Posted by oneclick View Post
No.

NO.

There is a proper way to spread steel stays, and that isn't it.

You have no way of knowing if the stays were aligned before or after if you don't measure, and if you attempt to spread the stays as described above you are unlikely to finish with them aligned even if they were to begin with.
AMa
walterpeter946 is offline
Old 01-12-21, 07:56 AM
  #15
roadsnakes
Senior Member
Thread Starter

Join Date: Nov 2018
Posts: 159
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 61 Post(s)
Liked 80 Times in 35 Posts
Originally Posted by Hobbiano View Post
That looks like a 48 spoke rear wheel.
'

It`s 40 spoke wheel. Originally on a tandem bicycle.


roadsnakes is offline
Old 01-12-21, 08:33 AM
  #16
markk900
Senior Member

markk900's Avatar

Join Date: Jan 2007
Location: Ontario
Posts: 2,028
Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 229 Post(s)
Liked 102 Times in 65 Posts
While the bike is in the shop, have them confirm your stem is installed safely. It is a big frame and that looks like a long stem but seems to me it’s not in the steerer tube very far, and you’d have a lot of leverage on it.

There is usually a mark or line that says “their much must be in the steerer”.

I assume you prefer the stem facing backwards for fit?

Nice looking bike btw.
markk900 is offline
Old 01-12-21, 12:42 PM
  #17
Hobbiano
Senior Member

Join Date: Sep 2014
Location: Baton Rouge La
Posts: 758
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 224 Post(s)
Liked 105 Times in 78 Posts
Originally Posted by roadsnakes View Post
'

It`s 40 spoke wheel. Originally on a tandem bicycle.


Not that it makes any difference, but I count 48. The original wheel may have had 40.
Hobbiano is offline
Old 01-12-21, 02:33 PM
  #18
roadsnakes
Senior Member
Thread Starter

Join Date: Nov 2018
Posts: 159
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 61 Post(s)
Liked 80 Times in 35 Posts
WELL ! Now you have me thinking!

I`ll have to check next time I go out to the garage.

It could very well be 48! I just remember that 30+ years ago the LBS told me they had a used 40 spoke Tandem wheel they could put on, and I never doubted them.

That could explain that I don`t recall having to true the rear wheel in a couple of Decades! LOL

roadsnakes is offline
Old 01-12-21, 02:41 PM
  #19
roadsnakes
Senior Member
Thread Starter

Join Date: Nov 2018
Posts: 159
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 61 Post(s)
Liked 80 Times in 35 Posts
Originally Posted by markk900 View Post
While the bike is in the shop, have them confirm your stem is installed safely. It is a big frame and that looks like a long stem but seems to me it’s not in the steerer tube very far, and you’d have a lot of leverage on it.

There is usually a mark or line that says “their much must be in the steerer”.

I assume you prefer the stem facing backwards for fit?

Nice looking bike btw.
No , I installed the stem, and I know it`s backwards. (for comfort , because of a Very bad back).

It`s right at the line of being the Maximum Height.

roadsnakes is offline
Old 01-13-21, 08:50 AM
  #20
markk900
Senior Member

markk900's Avatar

Join Date: Jan 2007
Location: Ontario
Posts: 2,028
Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 229 Post(s)
Liked 102 Times in 65 Posts
Originally Posted by roadsnakes View Post
No , I installed the stem, and I know it`s backwards. (for comfort , because of a Very bad back).

It`s right at the line of being the Maximum Height.
I fully understand the trials and tribulations of a very bad back! As long as its safe......
markk900 is offline
Old 01-13-21, 06:35 PM
  #21
uncleivan
Senior Member

Join Date: Aug 2008
Posts: 140

Bikes: '92 MX Leader, 84 Colnago Mexico, 85 Recherche, 92 Klein, 86 Panasonic ATB Pro, 88 Roberts, 80 moser, 90 Wojcik, 92 Spectrum... ect

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Liked 32 Times in 22 Posts
The passage was 126mm 6 speed. Your rear wheel is too wide.
uncleivan is online now
Likes For uncleivan:
Old 01-14-21, 01:42 PM
  #22
roadsnakes
Senior Member
Thread Starter

Join Date: Nov 2018
Posts: 159
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 61 Post(s)
Liked 80 Times in 35 Posts
I picked up the bike from the LBS yesterday.

The original mechanic ,(who was not even born when I bought the bike was built , or when I had the rear wheel replaced) who told me my frame was bent , was wrong.

Another mechanic looked at it and determined the cones were out of adjustment.

After he adjusted the cones and spacing, the wheel fit fine.

The bill stayed at 20 bucks.

roadsnakes is offline
Old 01-14-21, 06:19 PM
  #23
Hobbiano
Senior Member

Join Date: Sep 2014
Location: Baton Rouge La
Posts: 758
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 224 Post(s)
Liked 105 Times in 78 Posts
That doesn't sound right. They would have to be so way, way, out of adjustment, to make it appreciably harder to get the wheel in. Have you tried removing the wheel from the dropouts and putting it back in since they worked on it?
Hobbiano is offline
Old 01-15-21, 08:23 AM
  #24
roadsnakes
Senior Member
Thread Starter

Join Date: Nov 2018
Posts: 159
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 61 Post(s)
Liked 80 Times in 35 Posts
Originally Posted by Hobbiano View Post
That doesn't sound right. They would have to be so way, way, out of adjustment, to make it appreciably harder to get the wheel in. Have you tried removing the wheel from the dropouts and putting it back in since they worked on it?
'

No I haven`t.
Lots of ice and some snow. Maybe when the weather breaks I`ll check it out, and get back riding it. Right now I`ve been riding my other bike which is better in winter conditions.

I do trust the LBS and the guy that worked on it. I`ve been going to this LBS for over 5 decades.
roadsnakes is offline
Old 01-15-21, 11:04 AM
  #25
conspiratemus1
Used to be Conspiratemus

Join Date: Jan 2009
Location: Hamilton ON Canada
Posts: 1,490
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 283 Post(s)
Liked 233 Times in 155 Posts
Originally Posted by Hobbiano View Post
That doesn't sound right. They would have to be so way, way, out of adjustment, to make it appreciably harder to get the wheel in. Have you tried removing the wheel from the dropouts and putting it back in since they worked on it?
Maybe something was lost in the broken telephone game. It’s possible that the shop removed some spacers on the left side to reduce the OLD of that old tandem wheel to 126 mm. This would entail a final adjustment of the left cone before securing the locknut to finish the job. Maybe both cones, if the axle had to be “walked” to centre it in the cones. The OP’s last photo, the only one in all his posts that is of any use whatsoever except to confirm the bike is red, does show a left-end configuration consistent with 126 mm. (But wait! Is this the “before” photo, or the “after” photo? Should we guess?). A tandem wheel would have more spacers there in its native state.

The OP was positive he had a 40-spoke wheel and never bothered to count before retorting “it’s 40” when questioned. No doubt he is just as positive the shop fixed his too-wide wheel properly, after initially telling him his frame was bent. So we’ll leave him to it.

Agree with you that the proof doesn’t come till next time he tries to remove the rear wheel. Strange lack of curiosity here. Me, that’s the first thing I’d do, not to distrust the shop, just for the satisfaction of understanding what was wrong exactly.
conspiratemus1 is offline

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off


Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright © 2021 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
