Which Pug is this?

Search
Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Which Pug is this?

Thread Tools

Search this Thread

Old 04-05-15 | 08:24 PM
  #1
Thread Starter
Senior Member

Joined: Jan 2014
Posts: 272
Likes: 2
Which Pug is this?

I just picked this up for $25. I looked around online and it looks to be a mid to late 70s era. It came with a cottered steel crank, steel seatpost, and Atax stem, the rest had been striped long ago. I'm guessing its a standard U-08 or something mass produced, the serial # is B7 ****. Also I would like to know if I could just swap out the cottered spindle for a square taper with caged bearings while using the existing French cups? Does anyone know I can swap the loose headset bearings for caged bearings as well?

I apologize in advance for my phone focusing on the background instead of the frame. I didn't notice until I linked the pics here.

Thanks





Antieverything is offline
Reply
Old 04-05-15 | 08:27 PM
  #2
greg3rd48's Avatar
Senior Member
Titanium Club Membership
10 Anniversary

Joined: Aug 2014
Posts: 1,898
Likes: 229
From: Bronx, NYC

Bikes: '19 Fuji Gran Fondo 1.5, '72 Peugeot PX10, '71ish Gitane Super Corsa, '78 Fuji Newest, '89 Fuji Ace, '94 Cannondale R600, early '70s LeJeune Pro project

You will definitely need different cups to use the square taper spindle. I did this on my U08 and used a new French thread cup and bearings set. It works great.
greg3rd48 is offline
Reply
Old 04-05-15 | 09:31 PM
  #3
markk900's Avatar
Senior Member
15 Anniversary

Joined: Jan 2007
Posts: 2,831
Likes: 847
From: Ontario
[MENTION=384048]greg3rd48[/MENTION]: I don't think you need new cups - mine is a bit older than the frame shown but I used my original cups with (I think) a 68mm spindle and its been fine.
[MENTION=364362]Antieverything[/MENTION]: not sure exactly what yours is but it doesn't have the Aztec style lugs so its later 70s; but it does have nice lugs so not one of the internally brazed frames...no chrome on the fork so possibly the successor to the AO-8?
markk900 is offline
Reply
Old 04-05-15 | 09:34 PM
  #4
greg3rd48's Avatar
Senior Member
Titanium Club Membership
10 Anniversary

Joined: Aug 2014
Posts: 1,898
Likes: 229
From: Bronx, NYC

Bikes: '19 Fuji Gran Fondo 1.5, '72 Peugeot PX10, '71ish Gitane Super Corsa, '78 Fuji Newest, '89 Fuji Ace, '94 Cannondale R600, early '70s LeJeune Pro project

Originally Posted by markk900
@greg3rd48: I don't think you need new cups - mine is a bit older than the frame shown but I used my original cups with (I think) a 68mm spindle and its been fine.
@Antieverything: not sure exactly what yours is but it doesn't have the Aztec style lugs so its later 70s; but it does have nice lugs so not one of the internally brazed frames...no chrome on the fork so possibly the successor to the AO-8?
Thanks that is a good pieceof information. I was told by quite a few that there would be issues doing that but I guess not in all cases.
greg3rd48 is offline
Reply
Old 04-06-15 | 08:09 AM
  #5
thumpism's Avatar
Bikes are okay, I guess.
Titanium Club Membership
10 Anniversary
Community Builder

Joined: Jan 2015
Posts: 8,006
Likes: 3,771
From: Richmond, Virginia

Bikes: Waterford Paramount Touring, Raleigh Sports 3-speeds in M23 & L23, Schwinn Cimarron oddball build, Marin Palisades Trail dropbar conversion, Nishiki Cresta GT, Jeunet mixte

Might be tough finding the Simplex shifter for that frame. It's an odd one in that it has a band clamp with a left shifter and a hole on the right side that wraps the existing braze-on, and a separate shifter for the right side to fit on that braze-on.
[img]https://encrypted-tbn0.gstatic.com/i...RmlnUdWMzaUyVA[/img]
thumpism is offline
Reply
Old 04-06-15 | 08:23 AM
  #6
Grand Bois's Avatar
Senior Member

Joined: Mar 2005
Posts: 17,392
Likes: 40
From: Pinole, CA, USA
Those shifters are not hard to find. Neither are the superior Criterium shifters with the same band.
Grand Bois is offline
Reply
Old 04-06-15 | 09:10 AM
  #7
bertinjim's Avatar
Senior Member
Titanium Club Membership
10 Anniversary
Active Streak: 30 Days

Joined: Mar 2012
Posts: 1,546
Likes: 434
From: Niagara Region, Canada

Bikes: 1970s Alex Singer, 1960s Peugeot PX 10, 1960s Bertin C37, 1973 Carre Bertin C 37, 1972 Carlton Kermesse, 1981 Peugeot PX 14 Super Competition

Antieverything-

It looks like a P 10 or PA 10. Those had sportier geometry than the UO 8/AO 8 designs and either the stamped rear dropouts like yours or forged Simplexes. Frame is standard plain gauge Peugeot made hi-tensile tubing. It would have been standard with Normandy HF QR hubs with tubular rims and tires. They made a cool entry level club/racing bike.
bertinjim is offline
Reply
Old 04-06-15 | 11:12 AM
  #8
Thread Starter
Senior Member

Joined: Jan 2014
Posts: 272
Likes: 2
Thanks guys! I'm still debating on how to build this frame. I wish I had gotten it a few years ago, before the rust on the chrome ️️crankset and pedals started flaking the chrome off. I might build it as a single speed so I don't have to deal with sourcing period parts or just hang this on the wall next to the PH-6 which is giving me fits locating a decently priced seatpost. It was a little on the big side in terms of sizing but I figured, french bike-french fit right? The price couldn't be turned down though.

Anyone have a opinion on value? Worth restoring or just build it/hang it? Whatever the value it'll just stay in the collection as I am unwilling to build to sell anymore.
Antieverything is offline
Reply
Old 04-06-15 | 11:27 AM
  #9
Senior Member

Joined: Feb 2015
Posts: 762
Likes: 56
I'm not a big fan of the heavier peugeot frames (I imagine many people aren't!). If I just wanted a project I'd probably turn it into like a single speed.
willydstyle is offline
Reply
Old 04-06-15 | 12:22 PM
  #10
Thread Starter
Senior Member

Joined: Jan 2014
Posts: 272
Likes: 2
Originally Posted by willydstyle
I'm not a big fan of the heavier peugeot frames (I imagine many people aren't!). If I just wanted a project I'd probably turn it into like a single speed.
My thoughts exactly! I was tossing the idea to build both Pugs into singles that share the same wheelset. There's a Sun wheelset on the Bay that would look nice! Might even keep the steel cottered crankset on this one. Too bad the Mafac brakes are missing.
Antieverything is offline
Reply
Old 04-06-15 | 12:46 PM
  #11
Thread Starter
Senior Member

Joined: Jan 2014
Posts: 272
Likes: 2
Originally Posted by bertinjim
Antieverything-

It looks like a P 10 or PA 10. Those had sportier geometry than the UO 8/AO 8 designs and either the stamped rear dropouts like yours or forged Simplexes. Frame is standard plain gauge Peugeot made hi-tensile tubing. It would have been standard with Normandy HF QR hubs with tubular rims and tires. They made a cool entry level club/racing bike.
Thanks for the tip, searching for a P10 gave me this site https://www.peugeotshow.com/1976nl/1976nl_15.jpg which shows the closest match yet. 77ish P10, it's good to know the lineage.
Antieverything is offline
