Can this frame be saved?

I picked up a 1980 Schwinn Voyager 11.8 frame today -- nothing particularly special but it was cheap, it was my size and it had fancy head tube lugs so I decided to get it. I always forget the things I need to look for before buying a frame, and this one should have been pretty obvious. The fork is bent, but worse than that so are the top tube and down tube.

If you have a good eye for these things maybe you can spot it in this pic from the seller's ad:



I missed it and even from this picture I didn't see that the fork was bent:



I noticed it as I was putting the frame in my car but I paid so little for the frame that I didn't bother to go back. Here are a couple of pics that show the damage:







So my questions... Can anything be done to repair this short of replacing these tubes? If not, is it safe to ride this as a beater or would that be broken teeth waiting to happen?
__________________
My Bikes
Andy_K is offline
Old 05-13-16, 08:06 PM
  #2
Senior Member

3speedslow's Avatar

Join Date: Oct 2010
Location: Jacksonville, NC
Posts: 9,334

Bikes: A few

Mentioned: 117 Post(s)
Tagged: 0 Thread(s)
Quoted: 1936 Post(s)
Liked 1,039 Times in 624 Posts
Safe to ride.
3speedslow is offline
Old 05-13-16, 08:18 PM
  #3
Senior Member

juvela's Avatar

Join Date: Feb 2013
Location: Alta California
Posts: 14,188
Mentioned: 409 Post(s)
Tagged: 1 Thread(s)
Quoted: 3735 Post(s)
Liked 3,176 Times in 2,085 Posts
The appearance of the metal can be improved with rolling blocks.

Deformation so slight it looks like it may not require a stretch.

Fork can be put right with the aid of a fork alignment jig such as the Park tool:

Attached Images
File Type: jpg
Park fork alignment jig .jpg (97.5 KB, 22 views)
juvela is offline
Old 05-13-16, 08:31 PM
  #4
working on my sandal tan

ThermionicScott's Avatar

Join Date: Aug 2011
Location: CID
Posts: 22,611

Bikes: 1991 Bianchi Eros, 1964 Armstrong, 1988 Diamondback Ascent, 1988 Bianchi Premio, 1987 Bianchi Sport SX, 1980s Raleigh mixte (hers), All-City Space Horse (hers)

Mentioned: 98 Post(s)
Tagged: 0 Thread(s)
Quoted: 3867 Post(s)
Liked 2,549 Times in 1,570 Posts
I've been riding a frame with worse damage without crashing and dying for a couple of years now. This post probably contributes to confirmation bias, though.
__________________
Originally Posted by chandltp
There's no such thing as too far.. just lack of time
Originally Posted by noglider
People in this forum are not typical.
RUSA #7498
ThermionicScott is offline
Old 05-13-16, 08:36 PM
  #5
Senior Member
Thread Starter

Andy_K's Avatar

Join Date: Jan 2008
Location: Beaverton, OR
Posts: 14,772

Bikes: Yes

Mentioned: 517 Post(s)
Tagged: 0 Thread(s)
Quoted: 3221 Post(s)
Liked 3,815 Times in 1,426 Posts
One of the odd things about this frame is that it is apparently "due tubi" 4130. That is, there's a sticker saying the "top and bottom" tubes are 4130, so I guess not even the seat tube.

I'm just finding myself getting really attached to it because it looks like it was Agent Coulson's bike:



How could you not love that?
__________________
My Bikes
Andy_K is offline
Old 05-13-16, 08:46 PM
  #6
Senior Member

Join Date: Apr 2009
Location: New Rochelle, NY
Posts: 38,384

Bikes: too many bikes from 1967 10s (5x2)Frejus to a Sumitomo Ti/Chorus aluminum 10s (10x2), plus one non-susp mtn bike I use as my commuter

Mentioned: 138 Post(s)
Tagged: 1 Thread(s)
Quoted: 5620 Post(s)
Liked 2,241 Times in 1,256 Posts
If you saw it first and were asking if you should buy it, I'd have said pass. But that ship has sailed, and you're now the proud owner of this gem. So my answer is now, build it up and ride it to your hearts content.

Odds are the wheelbase is only slightly shorter, and it might still track true, so you can ignore the issue entirely. OTO - if it doesn't track, you can invest a bit more effort and deal with it.
__________________
FB
Chain-L site

An ounce of diagnosis is worth a pound of cure.

Just because I'm tired of arguing, doesn't mean you're right.

“One accurate measurement is worth a thousand expert opinions” - Adm Grace Murray Hopper - USN

WARNING, I'm from New York. Thin skinned people should maintain safe distance.
FBinNY is offline
Old 05-13-16, 09:16 PM
  #7
Senior Member

exmechanic89's Avatar

Join Date: May 2015
Location: Richmond VA area
Posts: 2,713

Bikes: '00 Koga Miyata Full Pro Oval Road bike.

Mentioned: 17 Post(s)
Tagged: 0 Thread(s)
Quoted: 475 Post(s)
Likes: 0
Liked 7 Times in 6 Posts
I agree, build it and ride it. Might ride just fine.
exmechanic89 is offline
Old 05-14-16, 03:26 AM
  #8
Senior Member
Thread Starter

Andy_K's Avatar

Join Date: Jan 2008
Location: Beaverton, OR
Posts: 14,772

Bikes: Yes

Mentioned: 517 Post(s)
Tagged: 0 Thread(s)
Quoted: 3221 Post(s)
Liked 3,815 Times in 1,426 Posts
Originally Posted by ThermionicScott
I've been riding a frame with worse damage without crashing and dying for a couple of years now. This post probably contributes to confirmation bias, though.
Are you talking about the bike in this thread? https://www.bikeforums.net/classic-vi...rame-gulp.html

I came across that this evening as I was obsessing about my options. I'm going to take my frame in to an LBS tomorrow for a hands-on assessment. I spent twice as much on pizza today as I did on this frame, so I figure I can spend a little bit on repair before I'm in the red.
__________________
My Bikes
Andy_K is offline
Old 05-14-16, 09:03 AM
  #9
Touring Enthusiast

Join Date: Apr 2012
Location: USA
Posts: 278

Bikes: 23" Schwinn High Plains, 20" Trek 830 Antelope

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Likes: 0
Liked 1 Time in 1 Post
Unless it was a frame that i was *very* infatuated with, i'd see what it would cost to straighten (if possible) and go from there.

It's rarely a good thing to throw good money at a bad investment.
PolarBear007 is offline
Old 05-14-16, 09:32 AM
  #10
Senior Member

Join Date: Apr 2009
Location: New Rochelle, NY
Posts: 38,384

Bikes: too many bikes from 1967 10s (5x2)Frejus to a Sumitomo Ti/Chorus aluminum 10s (10x2), plus one non-susp mtn bike I use as my commuter

Mentioned: 138 Post(s)
Tagged: 1 Thread(s)
Quoted: 5620 Post(s)
Liked 2,241 Times in 1,256 Posts
Originally Posted by PolarBear007
Unless it was a frame that i was *very* infatuated with, i'd see what it would cost to straighten (if possible) and go from there.

It's rarely a good thing to throw good money at a bad investment.
No offense intended, but this is self-contradictory. If I really cared about a frame, I might look into the cost of a repair. But otherwise, I wouldn't toss dough at it, and either ride it as is, or scrap it.
__________________
FB
Chain-L site

An ounce of diagnosis is worth a pound of cure.

Just because I'm tired of arguing, doesn't mean you're right.

“One accurate measurement is worth a thousand expert opinions” - Adm Grace Murray Hopper - USN

WARNING, I'm from New York. Thin skinned people should maintain safe distance.
FBinNY is offline
Old 05-14-16, 10:29 AM
  #11
feros ferio

John E's Avatar

Join Date: Jul 2000
Location: www.ci.encinitas.ca.us
Posts: 21,719

Bikes: 1959 Capo Modell Campagnolo; 1960 Capo Sieger (2); 1962 Carlton Franco Suisse; 1970 Peugeot UO-8; 1982 Bianchi Campione d'Italia; 1988 Schwinn Project KOM-10;

Mentioned: 44 Post(s)
Tagged: 0 Thread(s)
Quoted: 1372 Post(s)
Liked 1,254 Times in 801 Posts
I have owned two frames which were bent back and subsequently pulled back into shape. Both eventually ruptured near the front of the downtube, but neither caused a catastrophic failure nor threatened my safety in any way.
__________________
"Far and away the best prize that life offers is the chance to work hard at work worth doing." --Theodore Roosevelt
Capo: 1959 Modell Campagnolo, S/N 40324; 1960 Sieger (2), S/N 42624, 42597
Carlton: 1962 Franco Suisse, S/N K7911
Peugeot: 1970 UO-8, S/N 0010468
Bianchi: 1982 Campione d'Italia, S/N 1.M9914
Schwinn: 1988 Project KOM-10, S/N F804069
John E is offline
Old 05-14-16, 04:40 PM
  #12
working on my sandal tan

ThermionicScott's Avatar

Join Date: Aug 2011
Location: CID
Posts: 22,611

Bikes: 1991 Bianchi Eros, 1964 Armstrong, 1988 Diamondback Ascent, 1988 Bianchi Premio, 1987 Bianchi Sport SX, 1980s Raleigh mixte (hers), All-City Space Horse (hers)

Mentioned: 98 Post(s)
Tagged: 0 Thread(s)
Quoted: 3867 Post(s)
Liked 2,549 Times in 1,570 Posts
Originally Posted by Andy_K
Are you talking about the bike in this thread? https://www.bikeforums.net/classic-vi...rame-gulp.html

I came across that this evening as I was obsessing about my options. I'm going to take my frame in to an LBS tomorrow for a hands-on assessment. I spent twice as much on pizza today as I did on this frame, so I figure I can spend a little bit on repair before I'm in the red.
That's the one. I've touched up the frame with nail polish but left the underside light to make any worrisome cracks easier to spot:



If your shop has the Park Tool straightener thingy or something like it, I bet your frame could be made pretty close to original geo.
__________________
Originally Posted by chandltp
There's no such thing as too far.. just lack of time
Originally Posted by noglider
People in this forum are not typical.
RUSA #7498
ThermionicScott is offline
Old 05-14-16, 05:42 PM
  #13
Touring Enthusiast

Join Date: Apr 2012
Location: USA
Posts: 278

Bikes: 23" Schwinn High Plains, 20" Trek 830 Antelope

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Likes: 0
Liked 1 Time in 1 Post
Originally Posted by FBinNY
No offense intended, but this is self-contradictory. If I really cared about a frame, I might look into the cost of a repair. But otherwise, I wouldn't toss dough at it, and either ride it as is, or scrap it.
No offense taken friend! It's not really self-contradictory if perceived from the view point of a full-on infatuation! If the repair cost is reasonable and i like frame, no problem go ahead and fix it. If the cost is unreasonable, then i'd ride it if possible until i couldn't.

If I'm really taken with the frame then just about anything can be fixed - price be dammed!

By way of illustration, I had (have?) a bit of an obsession with older Minolta 35mm cameras (preferably non-battery except for light-metering). I'd see one of my favorite models and buy it. If it was worthy, i'd then send it off to my favorite Minolta tech and have him work his magic on it. If needed, i had back-ups to swap in nicer bits (which did happen on occasion). I have a couple darlings that need to be sent in (in particular an XE-7 in absolute MINT condition except for having the film advance drive train cleaned up), but that's another expense line Mrs. PolarBear is thankful i'm taking a break from!
PolarBear007 is offline
Old 05-14-16, 06:22 PM
  #14
Senior Member
Thread Starter

Andy_K's Avatar

Join Date: Jan 2008
Location: Beaverton, OR
Posts: 14,772

Bikes: Yes

Mentioned: 517 Post(s)
Tagged: 0 Thread(s)
Quoted: 3221 Post(s)
Liked 3,815 Times in 1,426 Posts
The shop I took t to didn't have the Park tool but they did have a mechanic with a sharp eye who in about 10 seconds spotted problems with the fork that I hadn't noticed, like it wasn't in line with the steerer side-to-side either. It would certainly need more work than a fork that takes a 21.1 stem deserves. There may be a DIY alignment attempt in this frames' future.

I stopped by a local co-op and grabbed a fork that I think doesn't look terrible with the frame. I was wondering where I could get really cheap long reach brakes, then I remembered that I had some center pulls in a junk box in the garage.



This is definitely shaping up to be the kind of bike that no one will weep to see turned into a single speed.
